Universal Electronics MILLENNIUM 4 User Manual

Hide thumbs Also See for MILLENNIUM 4:
Table of Contents

Advertisement

Quick Links

Download this manual See also: User Manual
Enlarged version
Millennium 4 Mnl M4094
2/29/00 6:21 PM
Page 1
MILLENNIUM
™
4
Universal Remote Control
User's Guide

Advertisement

Table of Contents
loading

Related Manuals for Universal Electronics MILLENNIUM 4

Summary of Contents for Universal Electronics MILLENNIUM 4

  • Page 1 Millennium 4 Mnl M4094 2/29/00 6:21 PM Page 1 MILLENNIUM ™ Universal Remote Control User’s Guide...

  • Page 2: Table Of Contents

    Millennium 4 Mnl M4094 2/29/00 6:21 PM Page 2 TABLE OF CONTENTS Introduction ....... . 3 Features And Functions .

  • Page 3: Introduction

    Before you can use your new remote control, you will need to program it to operate the specific home enter- tainment components you wish to control. Follow the instructions detailed in this manual to set up your Millennium 4 and enjoy your new remote control.

  • Page 4: Features And Functions

    Millennium 4 Mnl M4094 2/29/00 6:21 PM Page 4 FEATURES AND FUNCTIONS Use the illustration below to locate Millennium 4 features and then study the Key Charts (on the next two pages) to learn how they function.

  • Page 5: Key Charts

    Millennium 4 Mnl M4094 2/29/00 6:21 PM Page 5 Key Charts The LED (red light) blinks to show that the remote control is working and is sending signals. Press AUDIO, VCR, TV, or CBL once to select a home entertainment component to control.
  • Page 6 Millennium 4 Mnl M4094 2/29/00 6:21 PM Page 6 Key Charts (continued) Use cursor keys to move the cursor in the program guide and menu screens. Use SELECT/OK to choose options, PPV events, and to tune programs from the program guide.

  • Page 7: Installing Batteries

    LED will blink once. NOTE: Whenever batteries need replacement, the Millennium 4 will blink twice with every key press. Simply replace the batteries and the Millennium 4 will be restored to its full functionality, complete with your favorite settings.

  • Page 8: Programming Tv Control

    (see Searching For Your Code on page 26). Write your TV code in the boxes below for future reference. NOTE: Remember, to use the Millennium 4 to operate your TV, press TV first. Setup Codes for TVs:...
  • Page 9 Millennium 4 Mnl M4094 2/29/00 6:21 PM Page 9 Anam 0180 Anam National 0055 Archer 0003 Audiovox 0451, 0180, 0003, 0092, 0623 Baysonic 0180 Belcor 0019 Bell & Howell 0154, 0016 Bradford 0180 Brockwood 0019 Broksonic 0236, 0463, 0003 0180...
  • Page 10 Millennium 4 Mnl M4094 2/29/00 6:21 PM Page 10 Setup Codes for TVs (continued): 0053 Janeil 0046 0180 0180, 0030, 0039, 0185, 0280 Kaypani 0052 Kenwood 0030, 0019 Kloss 0024, 0046 0056 0047, 0054, 0154, 0156, 0178 Logik 0016 Luxman...
  • Page 11 Millennium 4 Mnl M4094 2/29/00 6:21 PM Page 11 Rhapsody 0185 Runco 0017, 0030, 0497 0180, 0019 Sampo 0030, 0039, 0032, 0052 Samsung 0060, 0030, 0178, 0019, 0056, 0032 Samsux 0039 Sansei 0451 Sansui 0463 Sanyo 0154, 0146, 0159 Scimitsu...

  • Page 12: Programming Vcr Control

    , try searching for the code (see Searching For Your Code on page 26). Write your VCR code in the boxes below for future reference. NOTE: Remember, to use the Millennium 4 to operate your VCR, press VCR first. Setup Codes for VCRs: Admiral...
  • Page 13 Millennium 4 Mnl M4094 2/29/00 6:21 PM Page 13 Audiovox 0037 Beaumark 0240 Bell & Howell 0104 Broksonic 0184, 0121, 0209, 0002, 0479 0072, 0278 Calix 0037 Canon 0035 Capehart 0020 Carver 0081 Cineral 0278 Citizen 0037, 0278 Colt 0072...
  • Page 14 Millennium 4 Mnl M4094 2/29/00 6:21 PM Page 14 Setup Codes for VCRs (continued): Magnavox 0035, 0039, 0081, 0000, 0149 Magnin 0240 Marantz 0035, 0081 Marta 0037 Matsushita 0035, 0162 Memorex 0035, 0037, 0048, 0039, 0047, 0240, 0000, 0104, 0162, 0046,...
  • Page 15 Millennium 4 Mnl M4094 2/29/00 6:21 PM Page 15 Shintom 0072 Shogun 0240 Singer 0072 Sony 0035, 0032, 0000, 0033, 0034 Sylvania 0035, 0081, 0000, 0043 Symphonic 0000 0240, 0208 Tatung 0041 Teac 0000, 0041 Technics 0035, 0162 Teknika 0035, 0037, 0000...

  • Page 16: Programming Tv/Vcr Combo Control

    TV/VCR Combo Brand: ________________________ The brands are listed in alphabetical order with popular codes listed first.You will use one of these codes to pro- gram the Millennium 4 to operate your TV/VCR Combo: Turn on your TV/VCR Combo and insert a video cassette.

  • Page 17: Setup Codes For Tv/Vcrs

    2/29/00 6:21 PM Page 17 Write your TV/VCR Combo code in the boxes below for future reference. NOTE: Remember, to use the Millennium 4 to operate your TV/VCR Combo, press VCR first. Setup Codes for TV/VCR Combos: American High 0035 (for TV use 0051)

  • Page 18: Programming Cable Converter (Or Dbs Receiver) Control

    Page 18 PROGRAMMING CABLE CONVERTER (OR DBS RECEIVER) CONTROL The Millennium 4 is preprogrammed at the factory to operate the cable converter given to you by your cable company. However, if you have another brand or model of cable converter or satellite receiver that you would like to control, then you’ll need to perform the following...

  • Page 19: To Lock The Cable Key

    Searching For Your Code on page 26). Write your Cable Converter or DBS Receiver code in the boxes below for future reference. NOTE: Remember, to use the Millennium 4 to operate your Cable Converter or DBS Receiver, press CABLE first. To lock the Cable key: On the Millennium 4, press CBL once.

  • Page 20: Setup Codes For Dbs Receivers

    Millennium 4 Mnl M4094 2/29/00 6:21 PM Page 20 Setup Codes for Cable Converters (continued): Samsung 0144 Scientific Atlanta 0008, 0477, 0017, 0277, 0774, 0877 Sprucer 0021 Starcom 0003 TV86 0063 Tocom 0012, 0013 Toshiba 0000 Viewstar 0063 Zenith 0000, 0525, 0899...

  • Page 21: Programming Channel Control Lock

    2/29/00 6:21 PM Page 21 PROGRAMMING CHANNEL CONTROL LOCK By activating this feature, the Millennium 4 will only allow access to the channel control capabilities of your cable converter. This will guarantee that you do not inad- vertently change the channel on your TV or VCR.

  • Page 22: Programming Audio Control

    2/29/00 6:21 PM Page 22 PROGRAMMING AUDIO CONTROL Using the Millennium 4’s Audio mode, you can also con- trol an audio component, such as CD or DVD player, a stereo receiver, a stereo amplifier, or a DBS audio service. Locate the brand name of your audio component in the one of accompanying code lists (starting on the next page).Write it in the appropriate space.

  • Page 23: Setup Codes For Cd Players

    Millennium 4 Mnl M4094 2/29/00 6:21 PM Page 23 NOTE: Remember, to use the Millennium 4 to operate your audio component, press AUDIO first. Setup Codes for CD Players: Aiwa 0157, 0124 Burmester 0420 California Audio Lab 0029 Carver 0157, 0179...

  • Page 24: Setup Codes For Dvd Players

    Millennium 4 Mnl M4094 2/29/00 6:21 PM Page 24 Setup Codes for CD Players (continued): Victor 0072 Wards 0157, 0053 Yamaha 0036, 0187 Yorx 0461 Setup Codes for DVD Players: 0558 Kenwood 0534 Magnavox 0503 Mitsubishi 0521 Onkyo 0503 Panasonic...

  • Page 25: Setup Codes For Stereo Amplifiers

    Millennium 4 Mnl M4094 2/29/00 6:21 PM Page 25 0531 Sansui 0189 Sharp 0186 Sony 0158 Soundesign 0670 Teac 0463 Technics 0039, 0309 Victor 0074 Wards 0158, 0014, 0189, 0080 Yamaha 0176, 0186 Setup Codes for Stereo Amplifiers: Carver 0269...

  • Page 26: Searching For Your Code

    SEARCHING FOR YOUR CODE If your TV,VCR, Cable Converter or Audio Component does not respond to the Millennium 4 after trying all of the codes listed for your brand, or if your brand is not listed at all, try searching for your code.

  • Page 27: Checking The Codes

    2/29/00 6:21 PM Page 27 CHECKING THE CODES If you have set up the Millennium 4 using the Searching For Your Code procedure, you may need to find out which four-digit code is operating your equipment: For example, to find out which code is operating your TV: Turn on your TV.

  • Page 28: Programming The Power Key

    Finally, press CABLE once. Now when you press CABLE once and then press POWER once, the Millennium 4 will only direct power to your Cable convert- er and TV, and still leave the remote control in the Cable mode.

  • Page 29: Re-Assigning Device Keys

    2/29/00 6:21 PM Page 29 RE-ASSIGNING DEVICE KEYS The Millennium 4 can be set up to control a second TV or VCR, or any combination of four home entertainment components. For example, to have the Millennium 4 control a TV, a Cable Converter, and two VCRs, you will...

  • Page 30: Changing Volume Lock

    2/29/00 6:21 PM Page 30 CHANGING VOLUME LOCK The Millennium 4 is set to control volume of a component through your TV while in the TV,VCR, or Cable mode. However, in the Audio mode, you have separate control of of your audio component’s volume.

  • Page 31: To Change Volume Lock To The Audio Mode

    LED blinks twice, then release SETUP. Enter 9 - 9 - 3 and then press AUDIO once. The LED will blink twice. Now, whenever you press Volume +,Volume –, or MUTE on the Millennium 4, volume will be controlled by your audio component.

  • Page 32: Troubleshooting

    LED blinks when you press a key, but home entertainment component does not respond. SOLUTION: Make sure you are aiming the Millennium 4 at your home entertainment component and that you are within 15 feet of the component you are trying to control.

  • Page 33: Additional Information

    2/29/00 6:21 PM Page 33 ADDITIONAL INFORMATION The Millennium 4 does not have any user-serviceable parts. Opening the case, except for the battery cover, may cause permanent damage to your Millennium 4. For help via the Internet, visit us at: cable.rcinfo.com...
  • Page 34 Millennium 4 Mnl M4094 2/29/00 6:21 PM Page 34 NOTES...
  • Page 35 Millennium 4 Mnl M4094 2/29/00 6:21 PM Page 35...
  • Page 36 Millennium 4 Mnl M4094 2/29/00 6:21 PM Page 36...
