Connecting the monitor
To set up the monitor, first unpack the box, unwrap the components, then make your cable
connections.
Connecting video inputs
To connect video sources to your monitor:
1
2
3
Connecting power
To connect power:
1
2
2
Using Your Gateway Flat-Panel Monitor
Position your computer and the monitor so you can reach the back of each.
If your computer has a digital video connector (DVI), connect a DVI video cable (not included)
to the white connector on the display.
- OR -
Connect the blue VGA video cable to the blue VGA video connector on the display.
- OR -
Connect an HDMI cable to the HDMI port on the display, or connect component video cables
to the component video ports on the display.
Important
For best audio performance, if your video connection uses HDMI, the digital
audio is also conveyed along the same cable, and no additional audio connection is
required. You may need to set your video source's audio mode to PCM or ANALOG
to hear the audio. See your source device's user guide for more information.
HDMI port
Make sure that your computer is turned off, then connect the other end of the video cable
to the matching video port on the back of your computer.
Position your monitor so you can reach the back, then connect the power cord to the power
connector under the back of the monitor.
Plug the power cord into a correctly grounded power outlet. We recommend using a surge
protector to protect your monitor from voltage spikes.
DVI port
VGA port
Component Pr
Component Pb
Component Y
Power connector
