- Page 1 ® CONVERTER FOR MONITORING STATION SMET-256 USER MANUAL Program version v1.07 smet256_en 04/11...
- Page 2 SATEL's goal is to continually improve the quality of its products, which may lead to alterations in their technical specifications and firmware. Current information on the introduced modifications is available on our website. Please visit us: http://www.satel.pl...
-
Page 3: Converter Features
SATEL SMET-256 The SMET-256 converter is a solution offered to firms engaged in the monitoring of security alarm systems. It receives events sent through the TCP/IP network by devices manufactured by the SATEL Company (Ethernet module, GSM module with GPRS reporting support). -
Page 4: Converter Installation
SMET-256 SATEL Explanations for Fig. 1: 1 – LED indicators: PWR – power indicator – ON when power supply is connected – status indicator: − ON – RS-232 port working in RC4000 VISONIC, SurGuard (MLR2/MLR2E) or RSM-02 receiver emulation mode −... -
Page 5: Configuring The Converter
There are two methods to configure the converter settings: 1. Through the TCP/IP network, by means of a web browser or the SMET-256 Soft program. 2. Through the RS-232 port, by means of the SMET-256 Soft program. In both cases, the Java Virtual Machine, which can be found on the CD delivered with the device, must be installed on the computer. - Page 6 RS-232 port will be only available on condition that it is connected after power-up to the computer on which the SMET-256 Soft program is running. If the converter fails to establish connection with the program within 10 seconds of the power-up, the RS-232 port will be reserved for communication with the monitoring station.
- Page 7 10 - failure indication icon. To see description of the failure hover the cursor over the icon. The grayed out icon means lack of failure. Fig. 3. Main window of SMET-256 Soft program. 11 - icon changes depending on the state of the telephone connection with reporting station: –...
- Page 8 SMET-256 SATEL...
- Page 9 SATEL SMET-256 Note: Be careful when selecting parameters to be entered in the fields "Test period" and "Number of missing tests". Entering small values in both fields may result in loss of communication being frequently reported, which not necessarily must indicate actual communication troubles.
- Page 10 Displayed in the tab is information on receiving transmissions which are not coming from defined subscribers, but meet the following criteria: – have been received after the connection with the converter and the SMET-256 Soft program was established; – have been sent to the port and are coded with the key, both indicated in the "Reporting"...
-
Page 11: Configuration Window
Fig. 5. The "Network" tab, "Configuration" window in the web browser (the window available in the SMET-256 Soft program differs only in graphic details). Dynamic IP – select this option, if the data regarding the IP address, subnet mask and gateway are to be automatically downloaded from the DHCP server. - Page 12 "RTC" tab Fig. 6. The "RTC" tab, "Configuration" window in the web browser (the window available in the SMET-256 Soft program differs only in graphic details). Summer/winter time – the converter can automatically correct the real-time clock settings when the time is changed from summer time to winter time or vice versa. You can choose from the following time correction schemes: −...
- Page 13 "RS port" tab Fig. 7. The "RS port" tab, "Configuration" window in the web browser (the window available in the SMET-256 Soft program differs only in graphic details). The settings in the tab apply to communication with the monitoring station.
- Page 14 "Reporting" tab Fig. 8. The "Reporting" tab, "Configuration" window in the web browser (the window available in the SMET-256 Soft program differs only in graphic details). Extended Parameters defined in this area apply to subscribers served in the extended mode, i.e.
- Page 15 By default: 54321. Note: In the case of the simple mode, the SMET-256 converter version 1.07 or higher, after receiving every event, will check whether the subscriber from which the event has been received, is on the list of subscribers assigned to the extended mode.
- Page 16 Fig. 9. The "Login details" tab, "Configuration" window in the web browser (the window available in the SMET-256 Soft program differs only in graphic details). Enabled – select this box to enable the device to be configured in the web browser. At the same time it will activate all the fields relating to login via the web browser.
- Page 17 "Advanced" tab Fig. 10. The "Advanced" tab, "Configuration" window in the web browser (the window available in the SMET-256 Soft program differs only in graphic details). Restoring factory default settings The parameters defined in this area will restore the converter factory settings.
- Page 18 (see: the "Reporting" tab), the trouble will be audibly signaled. The converter restart will not follow if there is an active connection with the SMET-256 Soft program, used for configuration of the device. IP address – the field is available if the ping command sending option is enabled. Enter in this field the IP address or domain name to which the ping command will be sent by the converter.
-
Page 19: Specifications
Appearance and style Parameters defined in this area are used for programming the appearance of windows displayed in the SMET-256 Soft program. There are two graphic styles available in the program, i.e. "BusinessBlackSteel" and "Windows". For the changes to take effect, select the appropriate field, click on the "Apply"... - Page 20 SATEL sp. z o.o. ul. Schuberta 79 80-172 Gdańsk POLAND tel. + 48 58 320 94 00 info@satel.pl www.satel.pl...
