SATEL i-LINK User Manual Version 1.6 TABLE OF CONTENTS TABLE OF CONTENTS ..........................2 IMPORTANT NOTICE ..........................3 PRODUCT CONFORMITY ........................4 WARRANTY AND SAFETY INSTRUCTIONS ....................5 1 GENERAL .............................. 6 SATEL -LINK P I/O - ..............6 ULSE...
Manual Version 1.6 IMPORTANT NOTICE All rights to this manual are owned solely by SATEL Oy permission from the owner of the rights by printing, copying, recording or by any other means or the full or partial translation of the manual to any other language including all programming languages using any electrical, mechanical, magnetic, optical, manual or other methods or devices is forbidden.
SATEL i-LINK User Manual Version 1.6 PRODUCT CONFORMITY SATEL i-LINK Hereby, SATEL Oy declares that SATEL i-LINK converters are in compliance with the essential requirements and other relevant provisions of Directive 89/336/EEC. Therefore the equipment is labelled with the following CE-marking. 0523...
The radio modem is to be used only on frequencies allocated by local authorities and without exceeding the given maximum allowed output power ratings. SATEL Oy is not responsible, if any products manufactured by it are used in unlawful ways.
1 GENERAL SATEL i-LINK Pulse Counter and I/O -converter The SATEL i-LINK is a Point-to-Point or Point-to-Multipoint transparent I/O-converter with a pulse counter input. The device works together with SATELLINE-1870E radio modems. In Point-to Point transmission the digital status information can be sent through the radio modem to output in the other end.
SATEL i-LINK User Manual Version 1.6 2 SPECIFICATIONS FEATURE min-max typical note Supply Voltage +9...30 Vdc Supply Voltage to i-LINK regulated by the radio modem (5.3 Vdc) Power consumption 0.03...0.1 VA 40 mA @ 12Vdc Serial Interface RS-232 ± 15 Vdc ±...
SATEL i-LINK User Manual Version 1.6 3 FUNCTIONS Screw connector functions 3.1 Supply Voltage, 9 – 30 Vdc o The minus contacts are in parallel. One is for the i-LINK and another can be used for external devices and connections. Plus (+) is for supply voltage.
SATEL i-LINK User Manual Version 1.6 I1…I2, PI1…PI2 o Showing the status of the Input. Illuminated when the consequently pin is activated. 3.7 DIP-Swithces 3.7.1 DIP -switches, 8 pcs 1 MP, Protocol-switch 1= M, for Point-to-Multipoint (Master-Slave) -operation 0= P, for Point-to-Point -operation...
SATEL i-LINK User Manual Version 1.6 4 OPERATION The Operation mode is selected using the PRTCL-switch. The operations are Point-to-Point or Point-to-Multipoint. In Point-to-Point operation mode the system consists of one pair of units. The inputs of the unit are transmitted as outputs of the other unit.
Page 12
SATEL i-LINK User Manual Version 1.6 Please contact local SATEL distributor or visit SATEL’s web site in order to get information of the multipoint commands.
SATEL i-LINK User Manual Version 1.6 5 FACTORY SETTINGS The i-LINK I/O -converter is shipped with the following default settings (unless specifically ordered with settings other than those listed below): FIXED SETTINGS DEFINED AT THE TIME OF ORDER PM, protocol switch, P-to-P or Multipoint...
SATEL i-LINK User Manual Version 1.6 7 ACCESSORIES SATELLINK PC and SATELLINK PC Pro Programs that make it possible to operate a Multipoint system with a PC. Layout of the SATELLINK PC Pro Multipoint-program...
Page 16
SATEL i-LINK User Manual Version 1.6 SATEL Oy P.O. Box 142, FI-24100 SALO, FINLAND Street: Meriniitynkatu 17, FI-24100 SALO, FINLAND Tel. +358 2 777 7800, info@satel.com www.satel.com...
