- Page 1 Monitoring Converter GPRS-T1 Program version 2.01 gprs-t1_en 11/11 SATEL sp. z o.o. ul. Schuberta 79 80-172 Gdańsk POLAND tel. + 48 58 320 94 00 info@satel.pl www.satel.eu...
- Page 2 Head of Test Laboratory: Michał Konarski The latest EC declaration of conformity and product certificates can be downloaded from our website www.satel.eu SATEL's goal is to continually improve the quality of its products, which may result in alterations of their technical specifications and firmware. Current information on the introduced modifications is available on our website.
-
Page 3: Converter Features
The GPRS-T1 converter is a device dedicated for use in intruder alarm systems for the purpose of reporting and messaging via the GSM networks. The event codes received in the telephone format can be converted to the form transmittable with the use of GPRS technology or to the SMS message format. - Page 4 GPRS-T1 SATEL • Encrypted transmission of events sent with the use of GPRS technology. • Notification by means of SMS messages or CLIP service about 32 selected events. • Periodical test transmissions for checking availability of the converter: – to selected telephone numbers (with the use of SMS message or CLIP service);...
-
Page 5: Installation
3 - RS-232 port (TTL standard) enabling the converter to be connected to the PC computer (connection can be made with cables included in the set manufactured by SATEL and designated DB9FC/RJ-KPL). 4 - antenna socket. 5 - GSM industrial telephone. - Page 6 GPRS-T1 SATEL The GPRS-T1 converter should be installed indoors, in spaces with normal air humidity. When selecting the installation place, take into consideration that thick walls, metal partitions, etc. will reduce the radio signal range. Installation in close vicinity of electrical systems is not recommended, as it may adversely affect the device performance.
- Page 7 SATEL GPRS-T1 Fig. 5. GPRS-T1 module in housing, secured with a plastic strap. Note: Before you begin using the module, remove the plastic strap protecting the device during transport. Be careful when removing the strap, so as not to damage any components on the electronics board.
- Page 8 GPRS-S program is to be effected). The converter will connect to the computer whose address was given in the SMS message. 4.3 D ESCRIPTION OF THE PROGRAM 4.3.1 M AIN MENU Fig. 6. Main menu of GPRS-T1 program.
- Page 9 ONITORING STATIONS Programming GPRS-T1 identifier – a sequence of 1 to 8 alphanumeric characters to identify the converter. Communication between the program and the converter is only possible when the identifier entered in this field is consistent with that stored in the converter. No identifier is preprogrammed in the converter with factory default settings.
- Page 10 GPRS-T1 SATEL Remote programming – enable this option if remote programming of the module with the use of GPRS technology is to be available. Initiating number only from list of telephone numbers for messaging – if this option is enabled, the SMS message initiating the remote programming must be sent from a telephone whose number is stored in the converter memory in the list of telephone numbers for messaging.
- Page 11 SATEL GPRS-T1 DNS server – DNS server IP address which is to be used by the converter. The DNS server address is necessary when GPRS technology is used for sending data, if the address of the device to which the converter is to connect (monitoring station, computer with GPRS-S program) has been entered as a name.
- Page 12 GPRS-T1 SATEL Port (simple mode) – number of TCP port through which communication with the monitoring station will be effected. The port number must be the same as that programmed in the monitoring station for managing subscribers in the simple mode.
- Page 13 SATEL GPRS-T1 line simulated by the converter will be disconnected (the control panel will report a telephone line failure). Kiss-off time – duration of the signal generated by the converter to acknowledge receipt of the events in Ademco Express or Contact ID format from control panel. The entered value must be suitable for the control panel settings (selected reporting format).
- Page 14 GPRS-T1 SATEL Note: If an extra test transmission (using the CLIP service or the GPRS-S program command) is generated, the time before sending the periodical test transmission will be counted from the beginning. SMS test transmission – enter in this field the SMS message body which will be sent as the converter test transmission to the selected telephone numbers.
- Page 15 SATEL GPRS-T1 R – the field refers to the event code to be sent in the Contact ID format. The additional digit in the Contact ID format indicates whether it is a new event/disarming, or a new restore/arming. Select this field, if the event code is to denote new restore/arming (click on the field twice to select/deselect it).
- Page 16 CLIP / SMS messaging The GPRS-T1 converter may be used not only for reporting, but also for notification purposes. The notification is effected by means of SMS messages, CLIP service, or both at the same time. You can define up to 32 events and the SMS message content for each of them.
- Page 17 SATEL GPRS-T1 Programming the "FFFF" identifier value means that receipt of any identifier preceding the event code will result in sending an SMS message. Format – format in which the event code must be received, so that the converter can send an SMS message.
- Page 18 GPRS-T1 SATEL 3. Program the parameters relating to the monitoring station simulation: – enter the telephone number defined in the control panel for the monitoring station which is to be simulated by the converter; – define whether the converter is to simulate a telephone line failure, if the GSM telephone fails to log into the GSM network ("Cut off the telephone line voltage if GSM...
-
Page 19: Restoring Factory Default Settings
SATEL GPRS-T1 2. Program the parameters relating to the monitoring station simulation ("GSM telephone, Monitoring stations" tab): – enter the telephone number defined in the control panel for the monitoring station which is to be simulated by the converter; – define whether the converter is to simulate a telephone line failure, if the GSM telephone fails to log into the GSM network ("Cut off the telephone line voltage if GSM... -
Page 20: Specifications
GPRS-T1 SATEL Fig. 9. "Factory default settings" function in the "Communication" menu. Most parameters in the factory default settings are not defined, and the options are not enabled. Only the following parameters are defined: "GSM telephone, Monitoring stations" tab Monitoring station 1 / 2: Disabled –...
