Summary of Contents for Clarke CBB75
- Page 1 Bore Hole Pump Bore Hole Pump Model Nos: CBB75 • CBB100 Part Nos: 7150710 • 7150715 USER INSTRUCTIONS 0506...
-
Page 2: Table Of Contents
Trouble Shooting ..................... 6 Please Note that details and specifications herein, are correct of time of going to print. However CLARKE International reserve the right to change specifications at any time without prior notice. Copyright CLARKE International All rights Reserved 2006. -
Page 3: General Safety Precautions
Any damage should be properly repaired or the part replaced . If in any doubt DO NOT use the machine. Consult your local CLARKE dealer. • ALWAYS keep children away. All visitors should be kept at a safe distance from the work area, especially whilst operating the machine. -
Page 4: Safety Precautions For Bore Hole Pumps
• DO NOT make any modifications to the pump, or tamper with it in any way. • NEVER operate the pump with the delivery port closed or obstructed. TECHNICAL SPECIFICATION Model No: CBB75 CBB100 Part No: 7150710 7150715 Supply Voltage/Frequency:... -
Page 5: Electrical Connections
ELECTRICAL CONNECTIONS This product is provided with a standard 13 amp, 230 volt (50Hz) BS1363 plug, for connection to a standard, domestic electrical supply. Should the plug need replacing at any time, ensure that a plug of identical specification is used. WARNING: Should it ever be necessary to change the plug, the wires in the mains lead should be wired according to the following colour code:... -
Page 6: Setup & Operation
SETUP AND OPERATION This bore hole pump is designed to pump soft water from bore holes, wells, underground springs or storage tanks to supply single sprinkler or irrigation systems. The pump is watertight and must be submerged in water (max depth 15m). Suitable pumping liquids are: •... -
Page 7: Maintenance
MAINTENANCE WARNING: ELECTRIC SHOCK HAZARD! Before carrying out any maintenance or cleaning operations, disconnect the pump from the power supply. This pump does not require any particular maintenance and all repairs must be carried out by an authorised service centre only, however: •...
