Summary of Contents for Clarke PUMP PSP125
- Page 1 PUDDLE PUMP PUDDLE PUMP MODEL No: PSP125 Part No: 7230692 OPERATION & MAINTENANCE INSTRUCTIONS 0308...
-
Page 2: Specifications
Part Number ............7230692 Please note that the details and specifications contained herein, are correct at the time of going to print. However CLARKE International reserve the right to change specifications at any time without prior notice. Always consult the machine’s data plate... -
Page 3: Table Of Contents
GUARANTEE • This CLARKE product is guaranteed against faulty manufacture for a period of 12 months from the date of purchase. Please keep your receipt as proof of purchase. -
Page 4: Safety Instructions
SAFETY INSTRUCTIONS KEEP CHILDREN AWAY: Do not allow children to touch the puddle pump, cables or connections. Visitors should be kept away from the work area. STORE IDLE TOOLS: When not in use, the puddle pump should be stored in a dry, secure place out of the reach of children. -
Page 5: Electrical Connections
ELECTRICAL CONNECTIONS Connect the mains lead to a standard, 230 Volt (50Hz) electrical supply through an approved 13 amp BS 1363 plug, or a suitably fused isolator switch. WARNING! THIS APPLIANCE MUST BE EARTHED IMPORTANT: The wires in the mains lead are coloured in accordance with the following code: Green &... -
Page 6: Parts Identification
PARTS IDENTIFICATION Multi hose fitting Control Switch Carry Handle Automatic (A) / Manual (M) Open (O) - See Maintenance Water Outlet Motor Housing Suction Base... -
Page 7: Recommended Uses
RECOMMENDED USES The recommended uses for this pump are: • Drainage after flooding • The transfer of liquids • Drainage of containers • Taking water from wells and shafts Liquids that CAN be pumped: • Clean water • Contaminated water (maximum particle size 3 mm) Note: always consider the outlet hose diameter •... -
Page 8: Preparation
PREPARATION CONNECTING THE OUTLET HOSE WARNING! ENSURE THAT THE PUDDLE PUMP IS DISCONNECTED FROM THE MAINS POWER SUPPLY BEFORE CONNECTING THE HOSE. NOTE: The outlet hose is not supplied with the puddle pump. The puddle pump is supplied with a multi hose adapter(as illustrated), for use with 25 mm (1“) and 32 mm (1 -1 /4”) hoses, IMPORTANT! When screwing on the adapter,... -
Page 9: Using The Puddle Pump
USING THE PUDDLE PUMP WARNING! BEFORE USING THE PUDDLE PUMP, CHECK TO MAKE SURE THAT IT IS NOT DAMAGED. DO NOT USE A DAMAGED PUMP. REFER TO QUALIFIED SERVICE PERSONNEL. Connect an outlet hose. See page 8. • Make sure the outlet hose is clear of obstructions and not kinked. The pumps are completely submersible, and should be placed in a vertical position, on a solid flat surface. -
Page 10: Cleaning And Maintainence
CLEANING AND MAINTENANCE WARNING! MAKE SURE THAT THE PUDDLE PUMP IS DISCONNECTED FROM THE MAINS SUPPLY BEFORE STARTING ANY CLEANING, OR MAINTENANCE PROCEDURES. • Always keep the body of the pump, clean and free from dirt, sediment and debris. • If the base becomes clogged it must be disconnected from the mains and clean the base.
