IN CASE OF TROUBLE

If a problem occurs, make sure that all connections are
properly made and clean. If a problem exists in one loud-
speaker, reverse the connection wires to the left and right
system. If the problem remains in the same speaker, then the
fault is with the loudspeaker. If the problem appears in the
opposite speaker, the cause is in another component or
cable.

SPECIFICATIONS

Outrigger Speakers
Frequency Response: 60 Hz ~ 20 kHz
Crossover Frequency: 3.2 kHz
Sensitivity: 88 dB @ 2.8 V, 1 meter
Nominal Impedance: compatible with 8 ohms
Power Rating: 10 ~ 80 watts (rms)
Outrigger jr. Speakers
Frequency Response: 80 Hz ~ 20 kHz
Crossover Frequency: 5.2 kHz
Sensitivity: 86 dB @ 2.8 V, 1 meter
Nominal Impedance: compatible with 8 ohms
Power Rating: 5 ~ 60 watts (rms)
In the event that your Outrigger or Outrigger Jr. ever needs
service, contact your local Infinity dealer or distributor or
www.infinitysystems.com for a service center near you.
Drivers: 5 1/4" (133mm) polypropylene
cone w/ rubber surround woofer
1" (25mm) Polycell
Cabinet Finish: White
Cabinet Dimensions*: 8" x 10" x 7"
(WxHxD) 20.3 x 25.4 x 17.8 cm
* Not including bracket
Drivers: 5" (127mm) polypropylene
cone w/ rubber surround woofer
1⁄2" (13mm) balanced-dome tweeter
Cabinet Finish: White
Cabinet Dimensions*: 6.26" x 7.91" x 5.75"
(WxHxD) 15.9 x 20.1 x 14.6 cm
* Not including bracket
We, Harman Consumer Group International
2, route de Tours
72500 Chateau-du-Loir
France
declare in own responsibility that the products
described in this owner's manual are in compliance
with technical standards:
EN 61000-6-3:2001
EN 61000-6-1:2001
™ dome tweeter
Declaration of Conformity
Laurent Rault
Harman Consumer Group International
Chateau-du-Loir, France 08/05
5
