USER MANUAL
1. DESCRIPTION OF THE APPLIANCE
1. Coffee container position indicator
2. Funnel lid for ground coffee
3. Measuring cup for ground coffee
4. Cover for coffee bean container
5. Container for coffee beans and funnel for
ground coffee
6. Grinding coarseness regulator
7. Control panel
8. Service door
9. Removable water tank with lid
10. Removable container for coffee grounds
11. Cup support grid
12. Removable drip tray
1.1 Description of control panel (7)
24. ON/OFF button 0/I
25. ON/OFF indicator 0/I
26. Washing programme and appliance in shut-
down indicator
27. Descaling programme indicator
28. "Coffee ready/steam ready" temperature indi-
cator
29. Coffee grounds container full or absent indi-
cator
30. No water indicator
31. Coffee strength indicators (mild, regular,
strong)
32. Coffee strength button (mild, regular, strong)
33. Coffee quantity button
34. Coffee quantity indicators
35. Steam indicator
36. Steam button
37. Two cup button
38. One cup button
39. One cup indicator
40. Two cup indicator
41. Button for washing or descaling programme.
DESCRIPTION
Pagina 18
13. Drip tray water level indicator
14. Coffee spout assembly adaptable to cup height
15. Swivelling hot water/steam spout
16. Cappuccino maker
17. Power cable
18. Hot water/steam knob
19. Cup warmer tray
20. Knob for manual cleaning of the spout assembly
21. Cleaning brush
22. Measure for ground coffee
23. Water hardness indicator strip
41
40
39
38
37
36
35
34
33
32
31
24
25
26
27
28
29
30

Advertisement

Table of Contents
loading

Related Manuals for DeLonghi EC 200.CD

Summary of Contents for DeLonghi EC 200.CD

  • Page 1 GB OK 27-09-2002 8:13 Pagina 18 USER MANUAL 1. DESCRIPTION OF THE APPLIANCE 1. Coffee container position indicator 13. Drip tray water level indicator 2. Funnel lid for ground coffee 14. Coffee spout assembly adaptable to cup height 3. Measuring cup for ground coffee 15.
  • Page 2 GB OK 27-09-2002 8:13 Pagina 19 USER MANUAL IF THE INDICATOR… is on flashes 25 ON/OFF I The appliance is ready for use The appliance is warming up or switching off The spout assembly is jammed. Turn the 26 Washing and The washing programme should be run appliance off then on again using the appliance shut-down...

  • Page 3: Safety Warnings

    GB OK 27-09-2002 8:13 Pagina 20 USER MANUAL 2. SAFETY WARNINGS Installation should be carried out according to the manufacturer’s instructions. Read these instructions and keep for future consultation. The power cable must not be replaced by the user Before use, make sure the mains voltage corre- as it requires special tools.
  • Page 4 GB OK 27-09-2002 8:13 Pagina 21 USER MANUAL 4. HOW TO PREPARE COFFEE… … using coffee beans A. Press the ON button (24): the appliance warms up and automatically performs a pre- wash cycle. The appliance on (25) and tem- perature (28) indicators flash during heating.
  • Page 5 GB OK 27-09-2002 8:13 Pagina 22 USER MANUAL …using ground coffee A. Press the ON button (24): the appliance warms up and automatically performs a pre-wash cycle. The appliance on (25) and temperature (28) indicators flash during heating. B. Rotate the container (5) into the position for using ground coffee (check indicator 1).
  • Page 6 GB OK 27-09-2002 8:13 Pagina 23 USER MANUAL 5. CUSTOMISING THE APPLIANCE The appliance is pre-set to average values. You can, however, permanently modify the setting according to your own personal tastes. After you have used the appliance for a while, we therefore recommended that you identify the right quan- tities of coffee for each size cup you prefer then memorise them as follows.
  • Page 7 GB OK 27-09-2002 8:13 Pagina 24 USER MANUAL 5.4 Setting water hardness 2. Immediately after wards, hold down the The appliance is set for average water hardness. washing/descaling button (41) and at the A reactive strip (23) is provided to identify the same time press the coffee quantity button hardness of the water normally used.

  • Page 8: Delivering Hot Water

    GB OK 27-09-2002 8:13 Pagina 25 USER MANUAL 7 DELIVERING HOT WATER • Wait until the appliance is up to temperature, then place a glass or cup directly under the hot water/steam spout (15). The orientation of the hot water/steam spout (15) can be adjusted to facilitate use with various types of container (glass, jug, etc).

  • Page 9: Cleaning And Maintenance

    GB OK 27-09-2002 8:13 Pagina 26 USER MANUAL 9. CLEANING AND MAINTENANCE Before cleaning the appliance, remove the coffee grounds container (10) and empty. You should do this with the appliance tur- ned on as this ensures correct reset of the counter. Then turn off by pressing button 24 and unplug from the mains. NOTE: The appliance must be completely re- 9.1 Daily and weekly cleaning To clean the outside of the appliance, wipe with a...
  • Page 10 GB OK 27-09-2002 8:13 Pagina 27 USER MANUAL 9.4 Manual cleaning of the spout assembly The spout assembly must be cleaned at least once a week or, preferably, whenever you fill the coffee bean container. Proceed as follows: • Turn off the appliance using the ON/OFF but- ton (24).
  • Page 11 GB OK 27-09-2002 8:13 Pagina 28 USER MANUAL 9.5 Descaling The appliance must be descaled at least once every four to six months, depending on the hardness of the local water and frequency of use. Indicator (27) lights up to warn that the appliance must be descaled. Although you can go on making cof- fee, you are recommended to descale immediately.
  • Page 12 GB OK 27-09-2002 8:13 Pagina 29 USER MANUAL 10. HELPFUL HINTS • The quality of the coffee depends not only on Empty the water tank daily and fill with fresh the appliance, but also the water, the type of water. coffee, the grinding, temperature, etc.

  • Page 13: Problems: Troubleshooting

    GB OK 27-09-2002 8:13 Pagina 30 USER MANUAL PROBLEM CAUSE REMEDY • The container (5) is in the • Rotate the container into the • While preparing the coffee ground coffee position or remo- coffee bean position using coffee beans, only val position (indicator 34 fla- hot water is delivered shes)
  • Page 14 GB OK 27-09-2002 8:13 Pagina 31 USER MANUAL PROBLEM CAUSE REMEDY • Coffee grounds container (10) • Empty the container (10) with • The control button functions full. Indicator 29 flashes the appliance turned on are not active • Coffee grounds container (1) •...
