Flashback 4
Introduction:
The ADJ Flashback 4 is a 4 cluster LED effect. This
fixture is designed for mobile DJ's, clubs, bands, roller rinks and any
arena that requires a compact, light weight, easy to use unit.
General Operation:
This fixture is designed to operate in a master-
slave configuration. Connect the units to one another using the pro-
vided 5 pin cable. Plug the unit in to a matching power outlet and
turn the program knob to your desired show. Use the Audio/Speed
adjustment knob to adjust the program speed. The list of programs
follow:
OFF - Blackout
MIX - Mixed Patterns
C1 - Pattern 1: Single Color Changing
C2 - Pattern 2: Two Color Changing
C3 - Pattern 3: Color Changing with Fade Out
C4 - Pattern 4: Single Color Changing with Fade Out
C5 - Pattern 5: Fast Paced
C6 - Pattern 6: Slow
F4 - Flash 4: Left and Right Single Flash
F3 - Flash 3: Four Time Flash
F2 - Flash 2: Twice Flash
F1 - Flash 1: One Flash
To activate sound active mode, turn the Audio/Speed knob all the
way counter-clockwise until you hear a "click". When you hear the
"click" you are in sound active mode.
ADJ Product, LLC - www.adj.com - Flashback 4 Instruction Manual Page 4
Operation
Flashback 4
1. Audio/Speed Knob
2. Program Knob.
3. 5-pin Slave connection jack.
4. DC Power Supply Input (Optional Power Supply, sold sepa-
rately)
5. AC Power Supply Input and Fuse Holder.
1
2
3
4
5
ADJ Product, LLC - www.adj.com - Flashback 4 Instruction Manual Page 5
Controls and Functions
