American DJ
SPECIFICATIONS: MODEL - MINI-Gressor II™
Weight:
Dimensions:
Lamp:
Fuse:
Supply Voltage:
Working Position:
Duty Cycle:
Colors:
Lenses:
Thank you for purchasing the MINI-Gressor II™ by American DJ
nience the MINI-Gressor II™ has been lamped and is ready to be used, there is no
assembly required. Please read the following instructions before installing or
operating your new MINI-Gressor II™.
Operating Instructions:
This unit is ready to be hung or set on a flat surface. This unit requires a sound source to oper-
ate. The unit will react to the beat of music via its internal microphone. Be sure not to
obstruct the cooling vents. Keep in a well ventilated area. For best results, fog or special
effects smoke must be used in order to see the beams of light.
Caution! Never open this unit when in use. Always disconnect main power before replacing
the lamps and fuse. Remember to always replace with the exact same type lamp and fuse,
unless otherwise specified by an authorized American DJ
Lamp replacement: Disconnect the units main power. Remove the thumb screws on trap
door located on the top of the unit. Carefully remove and replace lamps. Be sure to follow
the handling instructions that are included with your new lamps. Replace the cover and
reconnect the main power.
©
American DJ
8 Lbs.
12"H x 12"W x 5.5"L
2 x ZB-LL200 120v/200w
10A
120V
Any Safe position
NONE
Multiple
14 Colored
Los Angeles, CA 90058 USA - www.americandj.com - Mini Gressor II™
®
User Instructions
®
HALOGEN LAMP WARNING!
This fixture is fitted with halogen
lamps which are highly suscepti-
ble to damage if improperly
handled. Never touch lamp with
bare fingers as the oil from your
hands will shorten lamp life. Also,
never move fixture until lamp
has had ample time to cool.
Remember, lamps are not cov-
ered under warranty conditions.
®
. For your conve-
®
service technician.
