Bosch LTC 0455 Series Specfications page 2

2 | LTC 0455 Series Dinion Color Cameras
Certifications and approvals
Electromagnetic Compatibility
EMC Immunity According EN50130-4
EMC Emission According EN505022 class B,
According FCC class B part 15
Safety
LTC 0455/11 and LTC 0455/51: EN60065
LTC 0455/21 and LTC 0455/61: UL6500
Region Certification
Europe CE Declaration of Conformity
USA FCC Declaration of Conformity
Parts included
Quantity Components
1 LTC 0455 Series Color Camera
1 Spare male 4-pin lens connector
Lens not included
Technical specifications
Electrical
Model No. Rated
Voltage
LTC 0455/11 12 VDC
24 VAC
50 Hz
LTC 0455/21 12 VDC
24 VAC
60 Hz
LTC 0455/51 230 VAC
50 Hz
LTC 0455/61 120 VAC
60 Hz
Power Consumption
Imager
Active Pixels
PAL Models
NTSC Models
Range System
10.8-39 VDC PAL
12-28 VAC PAL
45‑65 Hz
10.8-39 VDC NTSC
12-28 VAC NTSC
45‑65 Hz
85-265 VAC PAL
45‑65 Hz
85-265 VAC NTSC
45‑65 Hz
4 W, excluding lens
Interline transfer CCD, 1/3-inch
image format
752 H x 582 V
768 H x 494 V
Sensitivity (3200K, F1.2 lens, 89% scene reflectance)
Usable
(30 IRE)
Scene Illumination 0.30 lux
(color mode) (0.03 fc)
Imager Illumination 0.045 lux
(color mode) (0.005 fc)
Scene Illumination 0.12 lux
(night mode) (0.012 fc)
Imager Illumination 0.018 lux
(night mode) (0.002 fc)
Horizontal Resolution
Signal-to-Noise Ratio
Gain
Electronic Shutter
Aperture Correction
Backlight Compensation
White Balance
Video Output
Synchronization
Line-Lock (when powered by
AC only)
Free Running (when DC-
supply or L/L off)
Controls
Video level
Shutter: AES / Off / Flickerless
AGC: On / Off
BLC: On / Off
Auto Black: On / Off
NightSense On / Auto / Forced
ATW: On / Hold
R-offset, B-offset
Vphase Adjustment: 0 – 358 degrees
Usable Full Video
(50 IRE)
0.65 lux 2.6 lux
(0.07 fc) (0.26 fc)
0.10 lux 0.40 lux
(0.010 fc) (0.040 fc)
0.26 lux 1.04 lux
(0.026 fc) (0.104 fc)
0.040 lux 0.16 lux
(0.004 fc) (0.016 fc)
540 TVL
50 dB
21 dB, (max)
Automatic, 1/50 to 1/125000 sec.
(CCIR), 1/60 to 1/150000 sec. (EIA)
Horizontal and vertical, symmetrical
Center window weighting
Automatic sensing (2500–9000 K)
Composite video 1.0 Vpp, 75 Ohm
Synchronizes the camera to the power
line zero crossing for roll-free vertical
interval switching. Vertical phase
delay can be adjusted (0-358
degrees) to allow vertical
synchronization in multi-phase power
installations.
Internal crystal reference is standard
on all models.
