Communications Systems | PLE‑2CS Plena Two-zone Call Station
PLE‑2CS Plena Two-zone Call Station
www.boschsecurity.com
The Plena two-zone call station is a modern, high-
quality call station with a stable metal base design, a
flexible microphone stem and a unidirectional
condenser microphone. It can make calls to selected
zones in a public address system built with the PLE
series two-zone mixer and mixer amplifiers. In addition
to tabletop use, the Plena design allows neat flush-
mounting in desktops.
Functions
Gain, speech filter and intelligibility
This call station features selectable gain, a selectable
speech filter, and a limiter for improved intelligibility.
Range
The call station has a balanced line level output, giving
it a maximum range of 200 meters from the mixer,
when using CAT-5 extension cables.
Loop-through
With the loop-through RJ-45 connector, it is possible
to daisy chain multiple call stations.
Modern two-zone call station for the PLE series
u
Selectable gain
u
Speech filter and limiter
u
Output level control
u
Loop-through option for up to 8 call stations
u
Priority
The priority is automatic i.e. the call station nearest
the mixer has priority and can override a call station
further from the mixer. When a call is being made by a
higher priority call station, a yellow light will display on
the lower priority call stations.
Dip switches and status
DIP switches at the base of the call station select
different microphone gain levels, chimes, and the
speech filter. A service accessible rotary control
provides microphone level attenuation. LEDs on the
call station show which zones have been selected. An
additional LED give visible feedback on the active state
of the microphone and the system:
• Green flashing means standby (chime is sounding)
• Green indicates microphone active
• Amber indicates a higher priority call
Controls and indicators
• 2 x status LEDs
• PTT key
• 2 x zone selection keys
• 2 x zone selection LEDs
• DIP switches
• Rotary volume control
