Fire Alarm Systems | SP4‑RMX Remote Microphone Expansion Module
SP4‑RMX Remote Microphone Expansion
Module
The Cooper Wheelock SAFEPATH4 SP4‑RMX Remote
Microphone Expansion Module is an outboard expansion
module used with the SP40/2 or SP40S Facilities
Communications Systems. The module expands the
number of optional remote microphones (SPRM) to three.
Each module provides a line level, 600 Ω auxiliary audio
output.
Two SP4‑RMX modules can be used when connected to an
SP40/2 or SP40S control panel. This provides a maximum
of six remote microphones providing All Call for the entire
system.
Functions
Microphone Priorities
There are two configurations for the priority levels of
remote microphones. One configuration sets the priorities
so that remote microphone 1 (RM1) has priority over the
other two (RM2 and RM3) remote microphones and RM2
has priority over RM3. This means that if RM3 is
broadcasting, either RM1 or RM2 can override it. The other
configuration gives top priority to the first microphone to
broadcast so that neither of the other microphones can
broadcast until the first completes its message.
▶ Expands one remote microphone (SPRM) from the
SP40/2 or SP40S control panel to three
▶ Provides one line level, 600 Ω auxiliary audio output
▶ Provides up to six remote microphones when using two
SP4‑RMX modules
▶ Provides multiple on‑board diagnostics with three
status conditions: standby, alarm, and trouble
▶ Operates on 24 VDC supplied by the SP40/2 or SP40S
control panel
Certifications and Approvals
Cooper Wheelock, Inc. holds these Listings and Approvals:
Region Certification
USA UL UOQY: Emergency Communication and
Relocation Equipment (UL864, 9th
edition), UOXX: Control Unit Accessories,
System (UL864, 9th edition) (Cooper
Wheelock)
CSFM 6911-0785: 157
ADA Complies with Americans with Disabilities Act
OSHA Complies with Occupational Safety and
Health Administration OSHA 1910.165
Installation/Configuration Notes
Compatibility Information
The SP4‑RMX Remote Microphone Expansion Module is
compatible with the SP40/2 or SP40S Facilities
Communications Systems.
