Hardware Setup Hardware Setup

Quick Components Guide

Back Panel,
p.2-12
PCIE, p.2-22
PCI, p.2-22
SYSFAN2,
p.2-15
JSP1,
p.2-17
JAUD1, p.2-19
2-2
JPWR3, p.2-11 CPU, p.2-4
RESET
CPU_CLK1, p.2-21
JCD1, p.2-15
J1394_1, p.2-17 RESET1, p.2-20
POWER1, p.2-20
DDR3, p.2-8
CPUFAN, p.2-15
JUSB1~3, p.2-16
JPWR1, p.2-11
SYSFAN1/3, p.2-15
SATA1~8, p.2-14
JCOM1, p.2-15
JTPM1, p.2-18
JCI1, p.2-16
JFP1, JFP2, p.2-18
