RocketFish RF-AC9023 Quick Setup Manual

DSLR Shutter Remote
RF-UNISR1
QUICK SETUP GUIDE

Package contents

• DSLR shutter remote
• Intermediate cables (4)
• Quick Setup Guide

Features

• Works with most DSLR cameras with
remote terminals.
• Use the shutter release button just like
the one on your camera.
• Shutter lock lets you keep the shutter
open for time exposures, or to shoot
continuously.
Cautions:
• Please insert or remove the plug carefully.
Take care to not to force it.
• Don't forget to disable the shutter lock
function by unlocking the shutter release
button lock after shooting.
• Do not leave the device in
high-temperature or high-humidity
environments.
Shutter release
button lock
Shutter release
button
Intermediate cables
C1

Connecting your shutter remote

1 Open the camera's remote terminal
cover.
2 Select an intermediate cable to match
your camera's remote terminal, then
connect the intermediate cable to the
female adapter on the DSLR shutter
remote cord.
3 Insert the plug on the intermediate
cable into the remote terminal on your
Cord
camera.
Female adapter
(Not available in
remote cord for
Terminal Type C1)
4 Adjust settings on the camera. For
details, see the camera's user manual.
C3 N1 S1
