3. Product Specification

GPS Chip
Frequency
C/A Code
Channels
Antenna (Internal)
Sensitivity
Datum
Position
Accuracy
Velocity
Time
Cold/Warm/Hot Start
Altitude
Velocity
Acceleration
GPS Output Data
Baud Rate
Built-in rechargeable Li-ion battery, Up to 42 hrs after fully charged
Standard
Bluetooth Profile
Size / Weight
Operating
Temperature
Storage Temperature
Charging
.........................................................................................................................................................................
www.Qstarz.com
General
MTK II GPS Module
L1, 1575.42MHz
1.023MHz chip rate
66-CH Performance Tracking
Built-in patch antenna with LNA
Tracking -165dBm
WGS84
Performance Characteristic
Without aid: 3.0m 2D-RMS
<3m CEP(50%) without SA (horizontal)
DGPS (WAAS, ENGOS, MSAS): 2.5m
Without aid: 0.1m/s, DGPS (WAAS, ENGOS, MSAS):
0.05m/s
50 ns RMS
35/33/1 sec, average
Dynamic Condition
<18,000m
<515m/sec
<4g
Protocol
Protocol: NMEA 0183 (V3.01) -GGA, GSA, GSV, RMC
115,200 bps
Power
Bluetooth
Fully compliant with Bluetooth V1.2
Serial Port Profiles (SPP), Up to 10 meters
Others
72.2 (L) X 46.5 (W) X 20 (H) mm / 64.7g (battery
included)
- 10 ℃ to + 60 ℃
- 20 ℃ to + 60 ℃
0 ℃ to + 45 ℃
BT-Q818X Bluetooth A-GPS Receiver
