Quick Start Guide
QC Series Digital Network
Video Recorders (NVR)
For more information about your new
system, look for "QC" on our website or
in our online support materials at
www.q-see.com/support
IMPORTANT!

Before You Get Started

A: Gather Your Components.
You will need:
1. An HDMI monitor, 19" or larger VGA PC monitor and VGA cable OR a television of any size.
2. A surge protector
We STRONGLY recommend that you use one that has the following specifications:
• UL-1449 Rated
• Clamping voltage of 330 or lower
• Joule rating of at least 400
• Response time of 10 nanoseconds or less
3. A power screw driver/drill to mount your cameras.
Your NVR can be controlled using the included USB mouse, remote control or the function keys on the front of the unit. For the purposes of this guide, we will be giving instructions using the mouse. Because this guide
covers several models in the QC series of NVRs, components in photos may not exactly match those on your particular model.
Be sure to register your product!
Visit www.Q-See.com,
click SUPPORT
and then select the online registration form.
Complete the product registration form to receive
warranty/technical support benefits and to be notified
of product updates and free downloadable firmware
updates to your NVR.
This walkthrough will allow you to test your cameras and connections before you mount them.
Note:
This poster is intended to help you get your Q-See security system up and running. There are many additional features which
can be customized to your specific needs. More information and instructions are available in the User Manual incuded on the
CD that came with your system or available for download from our website at www.Q-See.com.
For information on how to configure your system for remote monitoring on the Internet or on your smartphone, please refer to
the Remote Monitoring Guide also included on the accompanying CD.
B: Unpack the box...
Check the contents against the "What's in the Box" list that was
packed at the top of your product. If you notice any damage or
missing components, please contact Q-See Customer Support at
www.Q-See.com/Support

Advertisement

loading
Need help?

Need help?

Do you have a question about the QC Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Summary of Contents for Q-See QC Series

  • Page 1: Before You Get Started

    Your NVR can be controlled using the included USB mouse, remote control or the function keys on the front of the unit. For the purposes of this guide, we will be giving instructions using the mouse. Because this guide covers several models in the QC series of NVRs, components in photos may not exactly match those on your particular model.
  • Page 2 Connect the Devices STEP 1 Connect to a Monitor or Television OPTION A: OPTION B: OPTION C: Connecting a VGA PC Monitor Connecting a Television Connecting a HDMI Television (for NVRs equipped with an HDMI port) 1. Plug the VGA cable into the port marked “VGA” on the back of the 1.
  • Page 3: Initial Set Up

    Initial Set Up IMPORTANT! You must follow these steps to enter the current date and time in order to effectively use the video search function described at the end of this guide. Your NVR features a Startup Wizard that will guide you through the initial setup process including connecting your system to your network and the Internet. This Wizard should only be run during initial setup and should be turned off once you’ve completed setup.
  • Page 4: Camera Set Up

    Camera Set Up IMPORTANT! If your bundle came with specialty cameras, such as a PTZ, please consult the instructions for that camera first. STEP 5 Connecting the Cameras 2. Plug the other end of the Ethernet cable into any of There will be a delay of a few seconds while the NVR communicates with the cameras before their video stream appears.
