Outdoor Lifestyles Twilight II Mod Installation Manual

Twilight ii mod
Hide thumbs
Table of Contents

Advertisement

Quick Links

Download this manual
INSTALLER: Leave this manual with party responsible for use and operation.
OWNER: Retain this manual for future reference.
NOTICE: DO NOT discard this manual!
Model:
TWILIGHT-II-MOD
This appliance may be installed as an OEM
installation in manufactured home (USA
only) or mobile home and must be installed
in accordance with the manufacturer's
instructions and the Manufactured Home
Construction and Safety Standard, Title 24
CFR, Part 3280 in the United States, or the
Standard for Installation in Mobile Homes,
CAN/CSA Z240 MH Series, in Canada.
This appliance is only for use with the type(s)
of gas indicated on the rating plate. This
appliance is not convertible for use with other
gases, unless a certifi ed kit is used.
Outdoor Lifestyles by Hearth & Home Technologies • Installation Manual TWILIGHT-II-MOD • 2290-970 Rev. F • 11/13
Installation Manual
Installation and Appliance Setup
WARNING: If the information in these
instructions is not followed exactly, a fi re
or explosion may result causing property
damage, personal injury, or death.
• DO NOT store or use gasoline or other fl am-
mable vapors and liquids in the vicinity of this
or any other appliance.
• What to do if you smell gas
- DO NOT try to light any appliance.
- DO NOT touch any electrical switch. DO
NOT use any phone in your building.
- Immediately call your gas supplier from a
neighbor's phone. Follow the gas suppli-
er's instructions.
- If you cannot reach your gas supplier, call
the fi re department.
• Installation and service must be performed
by a qualifi ed installer, service agency, or the
gas supplier.
WARNING
DO NOT TOUCH GLASS
NEVER ALLOW CHILDREN
A barrier designed to reduce the risk of burns
from the hot viewing glass is provided with this
appliance and shall be installed.
In the Commonwealth of Massachusetts installation must be
performed by a licensed plumber or gas fi tter.
See Table of Contents for location of additional Commonwealth
of Massachusetts requirements.
HOT GLASS WILL
CAUSE BURNS.
UNTIL COOLED.
TO TOUCH GLASS.
1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Twilight II Mod and is the answer not in the manual?

Questions and answers

Related Manuals for Outdoor Lifestyles Twilight II Mod

Summary of Contents for Outdoor Lifestyles Twilight II Mod

  • Page 1 Installation Manual Installation and Appliance Setup INSTALLER: Leave this manual with party responsible for use and operation. OWNER: Retain this manual for future reference. NOTICE: DO NOT discard this manual! WARNING: If the information in these instructions is not followed exactly, a fi re or explosion may result causing property damage, personal injury, or death.

  • Page 2: Table Of Contents

    Safety Alert Key: • DANGER! Indicates a hazardous situation which, if not avoided will result in death or serious injury. • WARNING! Indicates a hazardous situation which, if not avoided could result in death or serious injury. • CAUTION! Indicates a hazardous situation which, if not avoided, could result in minor or moderate injury. •...

  • Page 3: Installer Standard Work Checklist

    Installer Standard Work Checklist Attention Installer: Follow this Standard Work Checklist This standard work checklist is to be used by the installer in conjunction with, not instead of, the instructions contained in this installation manual. Customer: Date Installed: Lot/Address: Location of Fireplace: Installer: Model (circle one): Twilight-II-MOD Dealer/Distributor Phone #...

  • Page 4: Product Specifi C And Important Safety Information

    Product Specifi c and Important Safety Information A. Appliance Certifi cation C. Thermal Performance Data Model: TWILIGHT-II-MOD MODEL: TWILIGHT-II-MOD Sound Transmission Thermal Resistance Thermal Conductivity Class (STC) (R Value) (K Value) LABORATORY: Underwriters Laboratories, Inc. (UL) TYPE: Direct Vent Gas Appliance 0.8hr-sq ft-ºF/BTU 1.25 BTU-in/hr-sq ft-ºF STANDARD: ANSI Z21.50-2007/CSA 2.22-2007, Addenda...

  • Page 5: High Altitude Installations

    F. High Altitude Installations NOTICE: If the heating value of the gas has been reduced, these rules do not apply. Check with your local gas utility or authorities having jurisdiction. When installing above 2000 feet elevation: • In the USA: Reduce input rate 4% for each 1000 feet above 2000 feet.

  • Page 6: Requirements For The Commonwealth Of Massachusetts

    Inspection Note: The following requirements reference various The state or local gas inspector of the side wall horizon- Massachusetts and national codes not contained in this tally vented gas fueled equipment shall not approve the document. installation unless, upon inspection, the inspector ob- serves carbon monoxide detectors and signage installed J.

  • Page 7: Getting Started

    Getting Started A. Design and Installation Considerations B. Tools and Supplies Needed Hearth & Home Technologies direct vent gas appliances Before beginning the installation be sure that the following are designed to operate with all combustion air siphoned tools and building supplies are available. from outside of the building and all exhaust gases expelled Tape measure Framing material...

  • Page 8: Framing And Clearances

    Framing and Clearances A. Appliance Dimension Diagram Dimensions are actual appliance dimensions. Use for reference only. OUTDOOR OUTDOOR OUTDOOR ELECTRICAL ACCESS GAS LINE ACCESS S* = MEASURE TO BOTTOM OF LIP AS SHOWN IN T VENT OPENING INDOOR VIEW OUTDOOR VIEW Location Inches Millimeter...

  • Page 9: Clearances To Combustibles

    B. Clearances to Combustibles NOTICE: Illustrations refl ect typical installations and are FOR DESIGN PURPOSES ONLY. Illustrations/diagrams When selecting a location for the appliance it is important are not drawn to scale. Actual installation may vary due to to consider the required clearances to walls. See Figure individual design preference.
  • Page 10 NOTICE: Install appliance on hard metal or wood surfaces Finishing Material Clearances extending full width and depth. DO NOT install directly on carpeting, vinyl, tile or any combustible material other OVERHANG than wood. FINISHING MATERIALS WARNING! Risk of Fire! Do not install appliance against vapor barriers or exposed insulation.

  • Page 11: Termination Location And Vent Information

    Termination Location and Vent Information A. Chimney Diagram = AREA WHERE APPLIANCE IS NOT PERMITTED = AIR SUPPLY INLET = APPLIANCE OPENING (See Note 2) J or K = 0 in ......clearances above grade, veran- = 9 in. (U.S.A.) 12 in. (Canada) ..clearance to non-mechani- (See Note 1) da, porch, deck or balcony cal air supply inlet to building...

  • Page 12: Appliance Preparation

    Appliance Preparation A. Removing Non-combustible Facing Ma- terial Assembly The non-combustible assembly is located on right-hand side of appliance (when looking from outdoor side of appliance). CAUTION Handle with care. APPLIANCE EXTERIOR • Non-combustible material may be damaged if dropped. METAL HEARTH STRIP UNDER EDGE OF •...
  • Page 13 Placing and Securing Appliance Place the appliance into position. Make sure fl ashing edges APPLY HIGH on the outdoor surround fi t up tight to the framing. TEMPERATURE SILICONE SEALANT The diagram shows how to properly position, level, and TO CORNER EDGES secure the appliance (see Figure 5.2).
  • Page 14 Apply housewrap or building paper * NOTE: All fi nishing materials on top of exterior sheathing For placement of combustible housewrap or building pa- must be non-combustible for a minimum of 10-7/8 inches per and non-combustible sheathing for the outside wall above and 2-3/4 inches on both sides of the exterior face of see Figures 5.5 and 5.6.

  • Page 15: Installing Non-Combustible Facing Material (Outdoor Side)

    C. Installing Non-combustible Facing Mate- NON-COMBUSTIBLE rial (Outdoor Side) FACING MATERIAL WARNING Fire Risk. • Follow these instructions exactly. • Facing materials must be installed properly to prevent fi re. • No materials may be substituted without authorization by Hearth & Home 48-5/8 in.

  • Page 16: Electrical Information

    Electrical Information A. General Information Junction Box Installation If the box is being wired from the OUTSIDE of the appliance: WARNING! Risk of Shock or Explosion! DO NOT wire 110-120VAC to the valve or to the appliance wall switch. • Install the Romex™ connector (not included with Incorrect wiring will damage controls.

  • Page 17: Optional Accessories

    Optional Accessories Optional fan and remote control kits require that 110-120 APPLIANCE VAC be wired to the factory installed junction box before LEFT SIDE the appliance is permanently installed. See Figure 6.2. Fan Installation Fan should be positioned on the left side (as viewed from appliance interior side.

  • Page 18: Wiring Requirements

    B. Wiring Requirements Intellifi re Ignition System Wiring • Wire the appliance junction box to 110-120 VAC for proper operation of the appliance. WARNING! Risk of Shock or Explosion! DO NOT wire IPI controlled appliance junction box to a switched circuit. Incorrect wiring will override IPI safety lockout.
  • Page 19 Connecting to the Appliance WARNING Wire 110-120VAC to electrical junction box. Do NOT wire 110-120VAC to valve. Do NOT wire 110-120VAC to wall switch. • Incorrect wiring will damage millivolt valves. • Incorrect wiring will override IPI safety lockout and may cause explosion. Note: To operate the appliance without a wall control or remote control, connect the ON/OFF switch located inside the control cavity of the appliance.

  • Page 20: Gas Information

    Gas Information A. Fuel Conversion C. Gas Connection • Make sure the appliance is compatible with available gas • Refer to Figure 3.1 for location of gas line access in types. appliance. • Conversions must be made by a qualified service •...

  • Page 21: High Altitude Installations

    D. High Altitude Installations NOTICE: If the heating value of the gas has been reduced, these rules do not apply. Check with your local gas utility or authorities having jurisdiction. When installing above 2000 feet elevation: • In the USA: Reduce burner orifi ce 4% for each 1000 feet above 2000 feet.

  • Page 22: Finishing

    Finishing A. Facing Material WARNING Inside Facing Material Risk of Fire • May install combustible materials up to specified • Non-combustible clearances must be clearances on top, front and sides of appliance. maintained. • Seal joints between fi nished wall and appliance top and •...
  • Page 23 HOUSEWRAP COMBUSTIBLE SHEATHING NON-COMBUSTIBLE SHEATHING (SUPPLIED) BRICK LEDGE 10-7/8 in. NON-COMBUSTIBLE FACING REQUIRED FLASHING (SUPPLIED) THERE MUST BE NO GAP BETWEEN BRICK LEDGE, 6 in. FACING MATERIAL AND MAX. APPLIANCE FRONT EXHAUST FRESH AIR INTAKE 6 in. MAXMUM PROJECTION FROM FACE OF FIREPLACE HOOD HOUSE NON-COMBUSTIBLE...

  • Page 24: Mantel And Wall Projections

    SOFFIT SIDING DRAIN PLANE 35-5/16 in. DETERMINED BY MINIMUM CLEARANCE HOUSEWRAP (BUILDING LOCAL CODE TO NON-VINYL PAPER) AND SHEATHING 64-5/16 in. CLEARANCE TO VINYL SOFFIT, OVERHANG, MANTEL, DETAIL - OR CEILING 12 in. SEE FIGURE 10.5 MINIMUM CLEARANCE TO NON-VINYL SIDING 36 in.

  • Page 25: Appliance Setup

    Appliance Setup A. Fixed Glass Assembly WARNING! Risk of Asphyxiation! Handle fi xed glass assembly with care. Inspect the gasket to ensure it is undamaged and inspect the glass for cracks, chips or scratches. • DO NOT strike, slam or scratch glass. •...

  • Page 26: Remove The Shipping Materials

    Removing Fixed Glass Assembly- Exterior B. Remove the Shipping Materials • Remove vanity panel from appliance to expose glass Remove shipping materials from inside or underneath the latches. fi rebox. • Pull glass latch out to release. Grasp glass assembly on C.

  • Page 27: Glass Rock Media Kit

    E. Glass Rock Media Kit WARNING! Risk of explosion! DO NOT place glass rock media directly in front of the pilot assembly or between the WARNING! Choking Hazard! Keep glass rock media burner tracks over the burner ports. Improperly placed out of reach of children.

  • Page 28: Reference Materials

    Reference Materials A. Accessories Install approved accessories per instructions included with accessories. Contact your dealer for a list of ap- proved accessories. WARNING! Risk of Fire and Electric Shock! Use ONLY Hearth & Home Technologies-approved optional acces- sories with this appliance. Using non-listed accessories could result in a safety hazard and will void the warranty.
