MarkBass MB Mini Boost Owner's Manual

GETTING STARTED

BOOST - To set up the Level Boost, plug your instrument into the Input Jack (5), and
connect the Output Jack (6) to your ampli er, after connecting a +9/+12VDC power
supply to the DC IN to the DC IN (7). Turn the boost on using the footswitch (3), making
sure the LED (4) is ON (this indicates that the e ect is active). Next, adjust the Boost
Level slider while toggling the footswitch (3) on and o , comparing the volume of the
direct signal with the boosted signal. Match the gain level as closely as you can to the
direct signal, then adjust the Level Boost slider to the desired amount of added boost
or cut. A suggested use of the boost is to leave it turned o until it's time to solo, then
switch it on (3) for a quick level boost when you begin your solo. You can easily apply
this to ANY situation where you need two di erent, quickly accessible playing volumes.
VPF (Variable Pre-shape Filter) - This lter boosts lows and highs, and cuts mids.
Some call this kind of e ect a scoop, a smiley-shape EQ, or an enhance knob. It's very
e ective for slap bass, pick playing, and driving eighth-note rock. It's o when it is all
the way counterclockwise—we suggest you start in that position and turn the lter up
gradually, to hear and understand what it does.

TECHNICAL SPECS

INPUT IMPEDANCE:
OUTPUT IMPEDANCE:
BOOST:
POWER REQUIREMENTS- DC INPUT:
DIMENSIONS:
WEIGHT:
In

BLOCK DIAGRAM

1 Mohm / 6 Vpp
470 ohm / 6 Vpp
0 to +20dB (maximum gain)
+9/+12VDC
48.4 x 38.2 x 104.2 mm
1.91" x 1.5" x 4.1"
174 g
0.38 lbs
Level VPF
booster
Out
OWNER'S MANUAL
