TECHNICAL SPECS
INPUT IMPEDANCE:
OUTPUT IMPEDANCE:
DRIVE:
LEVEL OUTPUT:
GRAPHIC EQ:
POWER REQUIREMENTS- DC INPUT:
DIMENSIONS:
WEIGHT:
BLOCK DIAGRAM
Drive
Level
distortion
In
1.5 Mohm / 6 Vpp
100 ohm / 6 Vpp
+50dB (maximum gain)
0 to Max
Freq. (Hz): 40, 80, 250, 400, 1200, 2000, 4000
Level: (-16dB, +16dB)
+9/+12VDC or standard 9-volt battery
98.8 x 38.3 x 124.2 mm / 3.89" x 1.51" x 4.89"
405 g / 0.89 lbs
40 80
400
2K 4K
250
1.2K
equalizer
Out
OWNER'S MANUAL
Advertisement
Related Manuals for MarkBass MB 7 Distorsore
Summary of Contents for MarkBass MB 7 Distorsore
- Page 1 TECHNICAL SPECS INPUT IMPEDANCE: 1.5 Mohm / 6 Vpp OUTPUT IMPEDANCE: 100 ohm / 6 Vpp DRIVE: +50dB (maximum gain) LEVEL OUTPUT: 0 to Max GRAPHIC EQ: Freq. (Hz): 40, 80, 250, 400, 1200, 2000, 4000 Level: (-16dB, +16dB) POWER REQUIREMENTS- DC INPUT: +9/+12VDC or standard 9-volt battery DIMENSIONS: 98.8 x 38.3 x 124.2 mm / 3.89”...
- Page 2 9V battery compartment on the bottom side For warranty and service information, please contact your local Markbass distributor (contact information available at www.markbass.it). For more technical information, please visit us at www.markbass.it and ll out the form on the of the pedal.
