Product Information
DESCRIPTION
4 wire system Color Outdoor Station
DIMENSION
95
45
4-Wire Outdoor Station
FEATURES
► Plastic housing with compact design;
► Camera's angle is adjustable;
► Half-flush mounting;
*1 Rain cover for surface wall mounting;
*1 High white led or Infrade night vision;
*1 Depends on models.
VT584 Series
Advertisement
Table of Contents
Related Manuals for V-Tec VT584 Series
Summary of Contents for V-Tec VT584 Series
-
Page 1: Product Information
Product Information VT584 Series 4-Wire Outdoor Station DESCRIPTION FEATURES 4 wire system Color Outdoor Station ► Plastic housing with compact design; ► Camera's angle is adjustable; ► Half-flush mounting; DIMENSION *1 Rain cover for surface wall mounting; *1 High white led or Infrade night vision;... -
Page 2: Parts And Functions
1. Parts and Functions 1. Microphone 2. Camera 3. Night-View LED 4. Call Button 5. Speaker 6. Angle Adjust 7. Monitor Port 8. Unlock Port LB 2. Door Station Mounting 1. Dig a hole in 75mm X 75mm X 35mm in the wall. Insert the mounting bracket and fix with screws. 2. - Page 3 3. Specification • Power Supply : DC 12V (supplied by indoor monitor) • Power Consumption: Standby 50mA; Working status 200mA; • Camera: 1/4” Color CCD/CMOS • Unlocking time: 1-9S, set by monitor; • Talk Time: 90S; • Lock Power supply: 12Vdc, 300mA(Internal Power) •...
