Page 3
1. Slide the PIR Sensor off the bracket (use the bracket as a template for mounting.) 2. Using a small standard screwdriver, press the release clip on the bottom of the PIR Sensor. 3. Separate the two parts. CAD-03 Kit Manual.indd 3 10/15/2009 10:16:01 AM...
3. Remove the battery insulator by pulling black tab from the back of the RF Shock Sensor. Unclip the bracket from the back and mount in desired location. * Pictures shown in white for readability. CAD-03 Kit Manual.indd 4 10/15/2009 10:16:01 AM...
Page 5
6. Continue on to the Advanced Operations to program your dialer or refer to the “CAD-03 Quick Reference Programming” on page 15. * Pictures shown in white for readability. CAD-03 Kit Manual.indd 5 10/15/2009 10:16:01 AM...
Page 6
How to play back the message: Press 1 2 3 4 > PLAY > 1 > ENTER to play back the recorded message. (Notice: 1 = the first message, 2 = the second message). CAD-03 Kit Manual.indd 6 10/15/2009 10:16:01 AM...
Page 7
3. Press ENTER (the display screen will show “505” followed by the telephone # keyed in.) Quick guide: Press 1 2 3 4 > PROGRAM > 9 > ENTER > telephone # > ENTER CAD-03 Kit Manual.indd 7 10/15/2009 10:16:01 AM...
Page 8
6. Key in your new four digit user password code again. 7. The LCD will change to acc. Quick guide: Press 1 2 3 4 > PASSWORD > New Code > Confirm New Code CAD-03 Kit Manual.indd 8 10/15/2009 10:16:01 AM...
Page 9
3. Press N (N = 0 for instant; 3 for 30 seconds; 6 for 60 seconds). Press ENTER. Quick guide: Press 1 2 3 4 > PROGRAM > 4 > ENTER > N > ENTER CAD-03 Kit Manual.indd 9 10/15/2009 10:16:01 AM...
Page 10
3. Press N (N = 0 to enable test; 1 to disable test). Press ENTER. Quick guide: Press 1 2 3 4 > PROGRAM > 0 > ENTER > 2 > ENTER> N > ENTER CAD-03 Kit Manual.indd 10 10/15/2009 10:16:02 AM...
Page 11
ESC. The Auto Dialer will revert to the ‘OFF’ mode and must be re-set to the ‘ON’ mode as above. Quick guide: Press 1 2 3 4 > ESC CAD-03 Kit Manual.indd 11 10/15/2009 10:16:02 AM...
Page 12
2. Remove the battery door and take out the old battery. Insert new 7.2V rechargeable battery pack and make sure it is in the correct polarity. 3. Fit the battery door and mount the Auto Dialer back onto the wall. CAD-03 Kit Manual.indd 12 10/15/2009 10:16:02 AM...
Page 13
Auto Dialer. Switch the power off again. Replace the SIM card, place switch back to NORMAL. Replace the 7.2V battery and place back onto the wall. Power the Auto Dialer back up. The Auto Dialer will then return to factory default setting. CAD-03 Kit Manual.indd 13 10/15/2009 10:16:02 AM...
Page 14
WARRANTY: Dakota Alert warrants this product to be free of defects in material and workman- ship for a period of one year from the date of purchase. This warranty does not cover damage resulting from accident, abuse, act of God or improper operation.
