- Page 1 Model No. 831.15948.1 Serial No. Write the serial number in the space WEIGHT BENCH above for reference. User’’s Manual Serial Number Decal •• Assembly •• Operation •• Maintenance •• Part List and Drawing Sears, Roebuck and Co. Hoffman Estates, IL 60179...
-
Page 2: Table Of Contents
TABLE OF CONTENTS WARNING DECAL PLACEMENT ............. . . 2 IMPORTANT PRECAUTIONS . -
Page 3: Important Precautions
IMPORTANT PRECAUTIONS WARNING: To reduce the risk of serious injury, read all important precautions and instructions in this manual and all warnings on your weight bench before using your weight bench. Sears assumes no responsibility for personal injury or property damage sustained by or through the use of this product. -
Page 4: Before You Begin
BEFORE YOU BEGIN Thank you for selecting the WEIDER PRO™™ 450 L reading this manual, please see the back cover of this weight bench. The versatile 450 L weight bench is manual. To help us assist you, note the product model designed to develop every major muscle group of the number and serial number before contacting us. -
Page 5: Part Identification Chart
PART IDENTIFICATION CHART Use the drawings below to identify the small parts needed for assembly. The number in parentheses below each drawing is the key number of the part, from the PART LIST near the end of this manual. The number following the key number is the quantity needed for assembly. -
Page 6: Assembly
ASSEMBLY •• To watch an assembly •• Place all parts in a cleared area and remove the video, go to packing materials. Do not dispose of the packing http://productvideo.co/ materials until you nish all assembly steps. assembly/sears/wei- der or use your mobile ••... - Page 7 2. Identify the Left Upright (39), and orient it as shown. Next, orient the Crossbar (2) as shown. Attach the Crossbar (2) to the Left Upright (39) with two M10 x 80mm Screws (27); do not tighten the Screws yet. Attach the Crossbar (2) to the Right Upright (3) in the same way.
- Page 8 4. Identify the Right Seat Frame (8), the Left Seat Frame (9), and the Seat Bracket (10). Orient the three parts as shown. Attach the Left Seat Frame (9) to the Seat Bracket (10) with two M8 x 42mm Bolts (34), two M8 Washers (35), and two M8 Locknuts (36);...
- Page 9 6. Pull the Bracket Knobs (13), insert the Seat Bracket (10) and the Backrest Bracket (7) into the two slots in the Frame (1), and release each Bracket Knob into an adjustment hole in the Seat Bracket or the Backrest Bracket. Next, align the brackets on the Seat Frames (8, 9) and the brackets on the Backrest Frames (5, 6) with the welded tube on the Frame (1), as...
- Page 10 8. Attach the Seat (18) to the Seat Frames (8, 9) with four M6 x 65mm Screws (32) and four M6 Washers (33). Start all four Screws, and then tighten them. 9. Attach the Backrest (19) to the Backrest Brackets (5, 6) with four M6 x 65mm Screws (32) and four M6 Washers (33).
- Page 11 10. Attach the Right Squat Weight Rest (11) and the Left Squat Weight Rest (12) to the Uprights (3, 39) as shown. Make sure that both Squat Weight Rests (11, 12) are at the same height. 11. Attach the Curl Pad (17) to the Curl Post (4) with four M6 x 20mm Screws (31).
-
Page 12: Adjustment
ADJUSTMENT The steps below explain how the weight bench can be adjusted. Make sure that all parts are properly tightened each time the weight bench is used. Replace any worn parts immediately. The weight bench can be cleaned with a damp cloth and a mild, non-abrasive detergent; do not use solvents to clean the weight bench. ADJUSTING THE BACKREST AND THE SEAT To adjust the angle of the Backrest (19), pull the indicated Bracket Knob (13), raise or lower the... - Page 13 USING THE SQUAT WEIGHT RESTS To perform squat exercises, attach the Squat Weight Rests (11, 12) to the Uprights (3, 39) at the desired height. Make sure that both Squat Weight Rests (11, 12) are at the same height. WARNING: Do not place more than 310 lbs.
-
Page 14: Exercise Guidelines
EXERCISE GUIDELINES FOUR TYPES OF STRENGTH WORKOUTS workout, and the numbers of repetitions and sets to complete. Progress at your own pace and be sensitive Note: A ““repetition”” is one complete cycle of an to your body’’s signals. Follow each workout with at exercise, such as one sit-up. - Page 15 EXERCISE LOG Make copies of this page, and use the copies to schedule and record your strength and aerobic workouts. Scheduling and recording your workouts will help you to make exercise a regular and enjoyable part of your life. Strength Exercise Lbs.
- Page 16 NOTES...
- Page 17 NOTES...
-
Page 18: Part List
PART LIST Model No. 831.15948.1 R0913A Key No. Qty. Description Key No. Qty. Description Frame Rectangular Cap Crossbar Crossbar Cover Right Upright M4 x 19mm Screw Curl Post M12 x 132mm Bolt Right Backrest Frame M12 Locknut Left Backrest Frame... -
Page 19: Exploded Drawing
EXPLODED DRAWING Model No. 831.15948.1 R0913A... -
Page 20: 90 Day Full Warranty
90 DAY FULL WARRANTY If this Sears Weight Bench Exerciser fails due to a defect in material or workmanship within 90 days of the date of purchase, call 1-800-4-MY-HOME® (1-800-469-4663) to arrange for free repair (or replace- ment if repair proves impossible). This warranty does not apply when the Weight Bench Exerciser is used commercially or for rental pur- poses.
