User Instructions
7/03
American DJ
4295 Charter Street
Los Angeles Ca. 90058
www.americandj.com
Energy One™
Unpacking:
Thank you for purchasing the Energy One™ by Ameri-
can DJ
. Every Energy One™ has been thoroughly tested and has
®
been shipped in perfect operating condition. Carefully check the ship-
ping carton for damage that may have occurred during shipping. If the
carton appears to be damaged, carefully inspect your unit for damage
and be sure all accessories necessary to operate the unit have arrived
intact. In the event damage has been found or parts are missing, please
contact our toll free customer support number for further instructions.
Please do not return this unit to your dealer without first contacting
customer support at the number listed below.
Introduction:
To optimize the performance of this product, please
read these operating instructions carefully to familiarize yourself with
the basic operations of this unit. The Energy One™ is a 200 watt
strobe, and is light weight and compact. Up to 16 units may be linked
together and controlled by single controller. A manual dimmer is built
in to the unit, allowing the unit's intensity to be customized. The unit
also has an adjustable flash rate knob built on to the unit.
Customer Support:
American DJ
support line, to answer any questions should you encounter problems
during your set up or initial operation. You may also visit us on the web
at www.americandj.com for any comments or suggestions. For service
related issue please contact American DJ
through Friday 9:00 a.m. to 5:00 p.m. Pacific Standard Time.
Voice:
(800) 322-6337
Fax:
(323) 582-2610
E-mail:
support@americandj.com
Warning!
To prevent or reduce the risk of electrical shock or fire, do
not expose this unit to rain or moisture.
Caution!
There are no user serviceable parts inside this unit. Do not
attempt any repairs yourself, doing so will void your manufactures
warranty.
Please do not discard the shipping carton in the trash. Please recycle
when ever possible.
American DJ
www.americandj.com - Energy One™ Instruction Manual Page 2
©
® -
Introduction
provides a toll free customer
®
. Service Hours are Monday
®
Advertisement
Related Manuals for American DJ Energy One
Summary of Contents for American DJ Energy One
- Page 1 To optimize the performance of this product, please read these operating instructions carefully to familiarize yourself with the basic operations of this unit. The Energy One™ is a 200 watt strobe, and is light weight and compact. Up to 16 units may be linked together and controlled by single controller.
- Page 2 Warranty Registration Safety Issues: This unit may blow a fuse if the maximum allotted The Energy One™ carries a one year (365 days) limited warranty. load of 15 amps (7 amps 220v version) is reached. If the fuse needs Please fill out the enclosed warranty card to validate your purchase.
- Page 3 Duty Cycle: Strobe Lamp Warning! This fixture is fitted with a Because the Energy One™ can be used for continuous output (ie strobe lamp which are highly susceptible to dam- while simulating lightning), it can build up intense heat. Due to this age if improperly handled.
- Page 4 PCB. Unscrew and disconnect the three wires from the PCB. Reassemble in reverse order. American DJ www.americandj.com - Energy One™ Instruction Manual Page 7 American DJ www.americandj.com - Energy One™ Instruction Manual Page 8 © ® - ©...
-
Page 5: Warranty
® tive parts at its expense, and will absorb all expenses for warranty service and repair labor by reason of defects in material or workmanship. The sole responsibility of American DJ ® under this warranty shall be limited to the repair of the product, or replacement thereof, including parts, at the sole discretion of American DJ .
