GA-7NCSV-RH Motherboard
1.2 GA-7NCSV-RH Motherboard Components
1.
Primary CPU
2.
Secondary CPU
3.
Intel 5100
4.
Intel 82801IR ICH9 RAID
5.
ServerEngines SE -SM4210-P01
6.
ServerEngine memory
7.
Intel 82566DM GbE
8.
Intel 82573L GbE
9.
Broadcom BCM5221 BMC
10.
IDE cable connector
11.
Front VGA cable connector**
12.
Front USB cable connector
13.
Internal USB cable connector
14.
SGPIO connector
15.
IPMB connector
16.
SATA1 Connector
17.
SATA2 Connector
18.
SATA3 Connector
19.
SATA4 Connector
20.
SATA5 Connector
21.
SATA6 Connector
22.
Power supply H/W status
monitor connetor
23.
24-pin ATX power connector
24.
8-pin ATX power connector
25.
32bit/33MHz PCI slot #1
26.
PCI Express x1 slot #6
27.
PCI Express x8 slot #5
28.
PCI Express x8 slot #4
29.
PCI Express x8 slot #3
30.
PCI Express x8 slot #1
31.
Channel 1 DDR2 sockets
32.
Channel 2 DDR2 sockets
33.
Keyboard Mouse ports
34.
USB 2.0 ports & Gigabit LAN port
35.
Serial port
36.
Monitor port
37.
Gigabit LAN port
38.
Gigabit LAN port
39.
CPU1 fan cable connector
CPU2 fan cable connector
40.
41.
System fan cable connector
42.
System fan cable connector
43.
Front panel connector
44.
CMOS Battery
7
