GA-7NCSV-RH Motherboard

Chapter 1 Introduction

1.1

Features Summary

Form Factor
CPU
Chipset
Memory
VGA Controller
On-Board LAN
I/O Control
Expansion Slots
SATA RAID Controller
Internal Connectors
12" x 10.5" CEB form factor, 6 layers PCB.
Supports Dual Intel Xeon
® ®
Intel Xeon Quad-Core/Dual -Core processor in LGA 775 socket
®
Supports 1066/1333MHz FSB
Intel 5100 Chipset
®
Intel ICH9 RAID
®
6 x DDR2 DIMM sockets
Supports up to 48GB 533/667 memory
Dual Channel memory bus
ECC Registered DDR2 533/667
Supports 1GB, 2GB memory
Integrated in ServerEngines Pilot II ( Matrox G200e)
Intel 82566DM single-port GbE controllers
®
Intel 82573L single-port GbE controllers
®
Single-port 100BASE-TX (for Management)
I/O Acceleration Technology
Supports WOL
Integrated in ServerEngines Pilot II
1 PCI slots 32-Bit/33MHz
3 PCI-Express x8 slot (at x8 bandwidth)
1 PCI-Express x8 slot (at x1 bandwidth)
1 PCI-Express x1 slot (at x1 bandwidth)
Built in Intel ICH9R with Software RAID 0,1,10, 5
®
(Windows Only)
Optional LSI SW RAID 0/1/10
1 24-pin ATX power connector
1 8-pin ATX power connector
1 front panel connector
1 IDE connector
2 USB 2.0 connectors for additional 4 ports by cables
1 COM connector
6 SATA 3Gb/s connectors
2 CPU fan cable connectors
2 System fan cable connectors
5
processor (Hapertown/Wolfdale)
