Air King AKLC Specifications

70 CFM/2.5 Sones @ 0.10" SP., 120 Volts, 1.6 amps, 60 hz.
Grill
AKLC701 - Oil Rubbed Bronze Finish: 13
AKLC702 - Nickel Finish: 13
AKLC703 - White Finish: 13
Light Lens
Ribbed frosted glass light lens.
Light Housing
Heavy gauge cold rolled steel c/w baked enamel finish; locks
in place on the grill via two integral tabs.
Blower Wheel
One piece polymeric wheel, 4
fins.
Motor
Single coil plug-in, two pole motor, life time lubrication,
thermally protected. Rated 120 volts, 60 hz., 1.6 amps.
Fan Housing
23 ga. Galvanized metal housing, dimensions 8" x 6
double metal thickness mounting tabs.
Duct Collar
Plastic collar for 4" duct connection, comes complete with
built in non-metallic back draft damper for quiet operation.
Lighting
2 - 60 watt maximum light capacity
Air Flow - CFM 81
PROJECT
LOCATION
CONTRACTOR
FAN MODEL
CFM
NUMBER NUMBER
C US
Specifications subject to change without notice.
1 / 2 " diameter.
" diameter.
1 / 2
" diameter.
1 / 2
1 / 2 " diameter, 1" wide, with 10
7 / 8
(bulbs not included).
EXPANDED PERFORMANCE
Static Pressure (inches of w.g.)
0 0.05 0.1 0.125
75 70 67
IN
RPM WATTS
W.G.
4"

Unit Mounting

Rated Type IC for ceilings insulated to R-40. Designed to mount
in ceilings with at least 6" of clearance. The unit will mounts
directly to the joist with a rough in opening of 8
housing will mount through drywall thickness up to
" x 5 ",
1 / 2
Ventilating Area
For bathrooms up to 70 sq. ft. for other rooms up to 85 sq. ft.
Single Pack Shipping Info
Box Dim: 11
1 / 2
AKLC701 - UPC: 0-8316228711-3
AKLC702 - UPC: 0-8316228721-2
AKLC703 - UPC: 0-8316228731-1
0.15 0.2 0.25
64 58 50
ARCHITECT
ENGINEER
SUBMITTED BY
AMPS SONES QTY
U.S.: 820 Lincoln Avenue
West Chester, Pennsylvania 19380-4466
Tel: (610) 692-7400 • 877-304-3785
Fax: (610) 696-8048
SPECIFICATIONS
AKLC
EXHAUST FAN WITH LIGHT
7 "
3 / 8
7 5 / 8 "
5 7 / 8 "
13 1 / 2 "
" x 13 " x 9 "
1 / 4 1 / 2
Sones Sones Fan Speed
@ .1 SP @ .25 SP RPM
2.5 2.5 1375
DATE
OPTIONAL EQUIPMENT
& REMARKS
Canada: 8 Edvac Drive
Brampton, Ontario L6S 5P2
Tel: (905) 456-2033
Fax: (905) 456-1015
" x 7 ". The
3 / 16 1 / 16
".
3 / 4
Power
Watts
33
Updated 6-10
