FIRE ALARM SYSTEMS
Description
Wheelock's Series CVX/CSX Explosion-Proof Bells have earned the
reputation for rugged, reliable performance over years of service in
hazardous environments. They are ideal as loud appliances or alarms
in mining, chemical process plants, grain storage and refineries, to
name only a few.
Features
•
CSA Approved
•
Rugged cast mechanism enclosure
•
Available in single stroke and vibrating models
•
Available in 24 VDC and 115 VAC versions.
•
High sound output with large 10" bell shell
•
Outdoor models include protective hood and guard
Listed for Hazardous Atmospheres
