Aztech DSL5005EN Specfications page 2

Features
• 6 in 1 Device
• WiFi Alliance standard 802.11n
• TR-069 compliant
• USB 2.0 Host
• Double-layer NAT/SPI firewall
• Wi-Fi Protected Access (WPA2-PSK)
• "One Touch" WPS Button
• Universal Plug and Play Support
Speci cations
ADSL Support
Encapsulation Support
Network Support
WLAN Support
Frequency Band
Management Support
Security Support
Hardware
Platform Support
Power Requirements
LED Indicators
External Connectors
Measurements
Environmental
Head Office Head Office Hong Kong Office Hong Kong Office
Hardware
AZTECH TECHNOLOGIES PTE LTD. AZTECH SYSTEMS LTD. AZTECH SYSTEMS (H.K) LTD. AZTECH SYSTEMS (H.K) LTD.
31 Ubi Road 1, Aztech Building 31 Ubi Road 1, Aztech Building Rooms 2-10, 3rd Floor, Core Building 1 Rooms 2-10, 3rd Floor, Core Building 1
Singapore 408694 Singapore 408694 No. 1 Science Park East Avenue No. 1Science Park East Avenue
Tel: (65) 6594 2288 Fax: (65) 6749 1198 Tel: (65) 6594 2288 Fax: (65) 6749 1198 HongKong Science Park HongKong Science Park
Shatin, New Territories, Hong Kong Shatin,New Territories, Hong Kong
Tel: (852) 2757 1177 Fax: (852) 2753 0578 Tel: (852) 2757 1177 Fax: (852) 2753 0578
Bene ts
Ideal device for for both Wired and Wireless connectivity via a ADSL2+ built in modem for
multi-user sharing
High speed cordless connection with PHY rate at 150Mbps
Auto-configuration, Dynamic service activation, cost-savings on customer support and logistics
Share the files and video clips via NAS, printers and etc.
Provides true firewall capability to ensure security for the network
Filtering for Wireless links
No networking knowledge required to lock the homenet
Makes it easy for users to enable popular applications while ensuring security
ANSI T1.413 issue 2, ITU-T G.992.1 (G.dmt), G.992.2 (G.lite) compliant
Annex A, B, I, J, M Erasure Decoding, Impulse Noise Monitoring
Embedded hardware ATM AAL-5 SAR supports UBR, UBR+, CBR and VBR and GFR tra cs
PCIe gen1 interface for 802.11a/b/g/n WLAN solution
F4 & F5 OAM Loopback/Send and Receive
RFC2684 Bridge, Routed LLC, VC Mux
Transparent Bridge PAP/CHAP/MS-CHAP for Password Authentication
Static IP, Dynamic RIP v1/v2 routing
PVC to VLAN Mapping Port Forwarding/Triggering
NAT Application Level Gateway for popular applications
SIP ALG (Application Layer Gateway)
PPP Dial on Demand with configurable timeout
QoS (DSCP, TOS), Diffserv, IEEE802.1p - Priority bit, IEEE802.1q - VLAN triggering
1x1 Wireless on Board, 2x2 Wireless using Module
Legacy and High Throughput Modes
Direct Sequence Spread Spectrum (DSSS) technology
1T1R Mode with 150Mbps PHY rate for Both Transmit and Receiving for DSL5001EN model
Reverse Direction Grant Data Flow, Frame Aggregation
Wireless Media Access Protocol- CSMA/CA with ACK
MAC Address Filtering, Multiple BSSID
2412 MHz - 2462 MHz (North America/FCC)
2457 MHz - 2472 MHz (France) 2457 MHz - 2462 MHz (Spain)
Web Based HTTP management GUI
Soft Factory Reset Button via Web GUI
Telnet with CLI (Read and Write) con guration
Quick rmware upgrade button (population option)
NAT for basic Firewall Packet Filtering Firewall
Password Authentication to Modem
Ralink TC3162U Processor Ralink TC3086 AFE
Dying Gasp (Population Option)
For Ethernet: OS Independent
Input Voltage : 12V DC +/- 10% Input Current : 1.0A
1 x WIFI DISABLE Button 1 x "WIFI" LED
1 x "Wireless" LAN Link/Activity (Green)
1 x RJ-11 Telephone socket for DSL line
1 x DC Jack for Power Input 1 x Factory Default Reset Button
1 x 180° Fixed 2.4Ghz 3 dBi Antenna
Dimension : 200mm x 125mm x 30mm
Operating : 0°C to 40°C, 30% to 90% Relative Humidity
Malaysia Office Malaysia Office
AZ-TECHNOLOGY SDN BHD. AZ-TECHNOLOGY SDN BHD.
No 901, 9th Floor, Block B No 901, 9th Floor, Block B
Kelana Business Centre Kelana Business Centre
97, Jalan SS7/2, Kelana Jaya 47301 97, Jalan SS7/2, Kelana Jaya 47301
Petaling Jaya, Selangor Petaling Jaya, Selangor
Tel: (60)(3) 7804-8450 Fax: (60)(3) 7804-8457 Tel: (60)(3) 7804-8450 Fax: (60)(3) 7804-8457
Con gurable USB2.0 EHCI host or device controller
Spectral compatibility with POTS
RFC2364 PPPoA Client RFC2516 PPPoE Client
IP/TCP/UDP/ICMP/ARP Application
Easy setup of Port Forwarding rules for popular Games/Application
DHCP Server/Relay/client
Multiple Sessions IP Sec and PPTP/L2TP VPN pass through
Universal Plug and Play
IEEE 802.11b/g/n compliant
20MHz/40MHz Bandwidth Low Power and Advanced Power Management
Modulation: OFDM with BPSK, QPSK, 16QAM, 64QAM, DBPSK, DQPSK, CCK
Cisco CCX, Operating Range of >300 Meters (Open Air)
WEP 64/128, WPA, WPA2, TKIP, AES
2412 MHz - 2472 MHz (ETSI/Europe)
TFTP/FTP for Firmware Upgrade
Diagnostic Test (DSL, OAM (ADSL), Network (ADSL), Ping Test)
Syslog Firmware upgrade-able for future feature enhancement
TR-069 (include TR-098, TR-111)
Stateful Packet Inspection
URL ltering/ Parental Control (Option)
Ralink TC2205F 5-Port Ethernet Switch
USB 2.0 Host (Default One and Option for Two)
1 x "Power" LED (Green and Red)
1 x "DSL" (Green) 1 x "Internet" (Green and Red)
2 x USB 2.0 Type A (Default 1)
1 x On/O Push Button Switch
Weight : Approx. 330 g
Non-Operating : -25°C to 70°C, 30% to 95% Relative Humidity
China Office China Office
AZTECH COMMUNICATION DEVICE (DG) LTD. AZTECH COMMUNICATION DEVICE (DG) LTD.
Jiu Jiang Shui Village, Chang Ping Town Jiu Jiang Shui Village, Chang Ping Town
Dong Guan City, Dong Guan City,
Guang Dong Province, China. Guang Dong Province, China.
Tel: (86)(769) 8393-6688 Fax: (86) (769) 8393-1138 Tel: (86)(769) 8393-6688 Fax: (86) (769) 8393-1138
G.992.3 (ADSL2), G.992.5 (ADSL2+), RE-ADSL2(Annex L)
Multiple PVC up to 8 support
TR100 compliant
RFC2225/RFC1577 Classical IP
Network Address Translation (NAT)
DNS Relay Agent
PPP Always on
DDNS (Dynamic DNS) IGMP Proxy (IGMP v1 and v2)
PPP/DHCP Auto Detection (Future release)
Transmit output power up to 20dBm (standard)
WDS (Wireless Distribution System)
QoS-WMM, WMM-PS
2412 MHz - 2484 MHz (Japan)
Web Based Firmware Upgrade (Local)
SNMP v1, v2 TR-143
Protection against Denial of Service attacks
Real-Time Attack and Alert Logs (Option)
Ralink RT5390 (Wireless Mac/BBP)
WPS 4MB SPI flash
4 x Ethernet Link (Green)
1 x "WPS" Status
4 x RJ45 for 10/100Base-T Ethernet (AutoMDI/MDIx)
www.aztech.com
USA Office USA Office Germany Office Germany Office
AZTECH LABS, Inc. AZTECH LABS, Inc. AZTECH SYSTEMS GmBH. AZTECH SYSTEMS GmBH.
4005 Clipper Court, Fremont 4005 Clipper Court, Fremont Kreuzberger Ring 22, 65205 Wiesbaden Kreuzberger Ring 22, 65205 Wiesbaden
CA 94538, U.S.A. CA 94538, U.S.A. Germany. Germany.
Tel: (1)(510) 683-9800 Fax: (1)(510) 683-9803 Tel: (1)(510) 683-9800 Fax: (1)(510) 683-9803 Tel: (49)(0) 611-45020-0 Fax: (49)(0) 611-45020-100 Tel: (49)(0) 611-45020-0 Fax: (49)(0) 611-45020-100
SNTP
DMZ TR-069 Compliant
WPS
TR068 - WAN Access
SSH
16MB SDRAM ITU K.21
1 x "USB" (Green)
1 x WPS Button
