user manual

SUPPORT

Thank you for purchasing this Samsung product.

To receive more complete service, please register

your product at

www.samsung.com/register

Model _____________ Serial No. _____________

Table of Contents

Need help?

Do you have a question about the Plasma TV and is the answer not in the manual?

Questions and answers

Summary of Contents for Samsung Plasma TV

Page 1: User Manual
Contact SAMSUNG WORLDWIDE If you have any questions or comments relating to Samsung products, please contact the SAMSUNG customer care centre. Country Customer Care Centre Web Site Plasma TV AUSTRALIA 1300 362 603 www.samsung.com NEW ZEALAND 0800 SAMSUNG (0800 726 786) www.samsung.com...
Page 2 • A still image displayed too long may cause permanent damage to the PDP Panel. Watching the Plasma TV in 4:3 format for a long period of time may leave traces of borders displayed on the left, right and centre of the screen caused by the difference of light emission on the screen.
Page 3: List Of Features
• AllShare Play: AllShare Play connects your TV and compatible Samsung mobile phones/devices through a network. • Anynet+ (HDMI-CEC): Allows you to control all connected Samsung devices that support Anynet+ with your Samsung TV’s remote. • e-Manual: Allows you to read on screen full manual. (p. 19) Accessories Please make sure the following items are included with your TV.
Page 4: Selecting The Sources
Viewing the Control Panel (Panel Key) TV Controller is a multi directional button that helps navigate without remote control. Some functions which require a PIN code may not be available. ✎ The product colour and shape may vary depending on the model. ✎...
Page 5: Remote Control Buttons
Remote Control Buttons Learn where the function buttons are on your remote. Especially note SOURCE, MUTE, Y, ✎ < P > , MENU, TOOLS, E, INFO, LIST, RETURN, and EXIT. This remote control has Braille points on the Power, Channel, and Volume buttons and can be used ✎...
Page 6: Installing Batteries (Battery Size: Aaa)
✎ connections, you do not need to connect the ANT IN jack to an antenna or a cable connection. The Plasma TV may interfere with an amateur radio or AM radio. ✎ Using two-way radio mobile and portable units or amateur radio or AM radio near your TV may cause ✎...
Page 7 Setup When you turn the TV on for the first time, a sequence of on-screen prompts will assist in configuring basic settings. To turn on the TV, press the button. Setup is available only when the input source is set to TV. ✎...
Page 8: Wireless Network
Wireless Network 1. The TV searches for and then displays all the wireless networks within range. When done, it displays a list of the networks. In the list of networks, move the Highlight to select a network, and then select Next.
Page 9 Software Update: When Network Settings is complete, your TV will check for a new Update the software software version automatically. If new software is available, the TV to the latest version downloads and installs the new software. When the download is complete, select Next.
Page 10 Auto Tuning (3): The TV will start memorising channels. Channel memorisation can take up to 45 minutes, depending on your cable system. For more Memorising information, refer to Auto Tuning (Channel Menu → Memorising channels. Channels) in the e-Manual. Select Stop at any time to Interrupt the memorisation progress. ✎...
Page 11: Connecting To An Av Device
Connecting to an AV Device Using an HDMI Cable: HD connection (up to 1080p) We recommend using the HDMI connection for the best quality HD picture. Available devices: DVD player, Blu-ray player, HD cable box, HD STB (Set-Top-Box) satellite receiver. Device HDMI Cable (Not Supplied) HDMI OUT...
Page 12 Using a Component Cable (up to 1080p HD signals) or an Audio/Video Cable (480i analogue signals only) Available devices: DVD player, Blu-ray player, cable box, STB satellite receiver, VCR Blue Green Video Cable Audio Cable (Not Supplied) Component Cable Audio Cable (Not Supplied) (Not Supplied) (Not Supplied) White...
Page 13: Connecting To An Audio Device
Connecting to an Audio Device Using an Optical (Digital) Connection Available devices: Digital Audio System, Amplifier, DVD home theatre Digital Audio System Optical Cable (Not Supplied) OPTICAL DIGITAL AUDIO OUT (OPTICAL) ✎ • When you connect a Digital Audio System to the DIGITAL AUDIO OUT (OPTICAL) jack, decrease the volume of both the TV and the system.
Page 14 Connecting to a PC Using an HDMI cable or an HDMI to DVI cable Your PC may not support an HDMI connection. ✎ Use your PC speakers for audio. ✎ HDMI Cable (Not Supplied) HDMI OUT HDMI to DVI Cable (Not Supplied) DVI OUT AUDIO OUT...
Page 15 Changing the Input Source Source → Source ™ Use to select TV or an external input source such as a DVD player / Blu-ray player / cable box / STB satellite receiver. ■ TV / HDMI1/DVI / HDMI2 / HDMI3 / AV / Component 1.
Page 16: Network Connection
• Encryption Type: WEP, TKIP, AES If you select Pure High-throughput (Greenfield) 802.11n mode and the Encryption type is set to WEP or TKIP on your AP or wireless router, Samsung TVs will not support a connection in compliance with new Wi-Fi certification specifications.
Page 17 Configuring a Wireless Network Connection The instructions below are for networks that use the Dynamic Host Configuration Protocol (DHCP) to configure network connections automatically. Most wireless networks use DHCP. If you have a Static IP network, see your user’s manual for configuration instructions. To configure the network connection for a network that uses DHCP, follow these steps: 1.
Page 18 The Modem Port on the Wall External Modem IP Router that has a TV Rear Panel (ADSL / VDSL / Cable TV) DHCP Server Modem Cable LAN Cable LAN Cable (Not Supplied) (Not Supplied) (Not Supplied) TV Rear Panel The LAN Port on the Wall LAN Cable (Not Supplied) It is not supported when the network speed is below or equal to 10Mbps.
Page 19: How To View The E-Manual
How to view the e-Manual You can fi nd instructions for your TV’s features in the e-Manual. To open the e-Manual, press the SUPPORT button on your remote. You can also access it through the menu: Menu → Support → e-Manual Access the e-Manual To use the e-Manual, follow these steps: 1.
Page 20 Using the coloured and function buttons with e-Manual • Scroll bar: Scroll up or down the e-Manual screen. / r: Moves the previous or next chapter. • • Try now: Move the OSD menu that corresponds to the topic. To return to the e-Manual screen, select Support using your remote.
Page 21: Troubleshooting
Some of above pictures and functions are available at specific models only. ✎ You can keep your TV as optimum condition to upgrade the latest firmware on web site (samsung. ✎ com → Support → Downloads) by USB.
Page 22: Installing The Wall Mount Kit
We do not advice you to do it yourself. Samsung Electronics is not responsible for any damage to the product or injury to yourself or others if you elect to install the wall mount on your own.
Page 23: Securing Tv To Wall
Securing the TV to the wall Caution: Pulling, pushing, or climbing on the TV may cause the TV to fall. In particular, ensure your children do not hang over or destabilize the TV. Doing so may cause the TV to tip over, causing serious injuries or death. Follow all safety precautions provided in the included Safety Flyer with your TV.
Page 24: Storage And Maintenance
Failing to do so may result in fire or a problem with the product due to an increase in the internal temperature of the product. When using a stand or wall-mount, use parts provided by Samsung Electronics only. ✎ • If you use parts provided by another manufacturer, it may result in a problem with the product or an injury due to the product falling.
Page 25: Specifications
Specifications Display Resolution 1920 x 1080 1920 x 1080 (Black & White) 1920 x 1080 Environmental Considerations Operating Temperature 50°F to 104°F (10°C to 40°C) Operating Humidity 10% to 80%, non-condensing Storage Temperature -4°F to 113°F (-20°C to 45°C) Storage Humidity 5% to 95%, non-condensing Stand Swivel (Left / Right) -20˚...
Page 26: Video Codec
Video Codec Frame rate Bit rate File Container Video Codec Resolution Audio Codec Extension (fps) (Mbps) *.avi DIVX 3.11/4.x/5.x/6.1 *.mkv *.asf MPEG4 SP/ASP 1920 x 1080 *.wmv LPCM H.264 BP/MP/HP *.mp4 ADMPCM(IMA, MS) *.3gp Motion JPEG 640 x 480 *.vro HE-AAC *.mpg Window Media Video v9...
Page 27: Display Resolution
Display Resolution You can also select one of the standard resolutions listed in the Resolution column. The TV will automatically adjust to the resolution you choose. Horizontal Frequency Vertical Frequency Pixel Clock Frequency Sync Polarity Mode Resolution (KHz) (Hz) (MHz) (H / V) 640 x 350 31.469...
