Emergency Cell Phone Power
PowerPort™ SOLAR Portable Charger & Battery
Model PPUS20
PLEASE READ THIS INFORMATION THOROUGHLY BEFORE USING THIS PRODUCT. IT CONTAINS
IMPORTANT OPERATING INSTRUCTIONS FOR YOUR POWERPORT UNIT.
Owner's Manual
Thank you for purchasing the PowerPort Solar Portable Charger and Battery. Take the compact,
lightweight PowerPort with you wherever you go and have a handy charger or rescue battery that works
anywhere! Charge the PowerPort from the Sun or from USB. PowerPort Solar charges your PDA, cell
phone, MP3 player, game system, or any device that can be charged via a USB cable connection.
The following items are included:
Diagram:
Battery Indicator LED:
Charging PowerPort
Red-Solar Charging*
Green-USB Charging
No LED-Fully Charged
CHARGING
POWERING
Mini USB
USB Power
Input Connector
Output Connector
USB Port
Charging Your PowerPort from
or
CHARGING
POWERING
or
or any powered USB port
Mini USB connector on the top of the PowerPort.
3. While charging from USB, the Solar LED Battery Status Indicator will light up GREEN.
4. When the charge has been completed the Charging LED will turn OFF.
5. Once the charge indicator shows the charge has completed, disconnect the battery from
the USB power source. Your PowerPort is ready to go.
Note: When charging your PowerPort unit from a computer, the computer must be powered on.
Powering Device
Blue-PowerPort
is charging device
No LED-Fully Drained
Small End
USB End
OR
Charging Your PowerPort from
AC - USB Adapter
DC - USB Adapter
Optimal charging from direct sunlight.
(see Specifications for details)
Charging Your Device Using
CHARGING
POWERING
Speci cations
Compatibility : Any USB powered device
Charging Speci cations
May be charged up to 500 times
Solar Panel Output : 120mA max.
Solar Panel Type : Polycrystaline Silicon
Output : 5.5VDC, 400-800mA max.
Charge Termination : Automatic
Safety Mechanisms : Max V, Min V, Short Circuit, Current limited
Dimensions: 4.50 x 2.25 x 0.50 in.
Weight: 2.9 oz.
Adapter Tip
Caution:
Disconnect the PowerPort as soon as it is practical after the charge is complete.
the Sun
may leak or explode, causing personal injury.
Note:
*While charging from the sun the LED light turns RED. LED will indicate RED when the Sun is strong enough to charge PowerPort.
This limited warranty starts from the date of original purchase and expires two years thereafter. If, during this period, any part, because of manufacturing defects or
workmanship, fails to function properly under normal use it will be repaired at no charge for parts and labor or, at our option, the product will be replaced. The following
is excluded: damages from delay or loss of use of equipment or damaged batteries, malfunctions resulting from misuse, tampering, unauthorized repairs, modi cations
or accident.
Package the unit and its accessories carefully using ample padding material to prevent damage in transit and ship it prepaid and insured to:
When sending in product for service, your package should include evidence of date and place of purchase. Enclose $10.00 for shipping and handling for addresses in
the U.S. and $15.00 in Canada. For outside the U.S. and Canada, freight will vary depending upon ship-to address.
Proposition 65 Notice (California)
The following statement is required in the state of California pursuant to the settlement of an action brought by the Mateel Environmental Justice Foundation against
multiple electronics and appliance manufacturers
For additional questions, comments or to explore other Lenmar battery solutions, visit our web site at: www.poweredbylenmar.com or
Your PowerPort
2. Choose the appropriate adapter tip for your device and attach it to the small
3. Connect the tip to your device.
4. Your device should indicate that it is receiving power. PowerPort's charging
5. If you are using the PowerPort to recharge your device, be sure to disconnect
as soon as possible after your device is recharged to conserve the power in the
PowerPort, and to avoid overcharging your device's battery.
Limited 2 Year Warranty
LENMAR ENTERPRISES, INC.
4035 Via Pescador
Camarillo, CA 93012 USA
Wash hands after handling.
Lithium-Ion battery must be
recycled or dispose of properly.
