Technical Specifications - Audio Note M8 Line Signature Owner's Information

TECHNICAL SPECIFICATIONS

INPUT IMPEDANCE
INPUT SENSITIVITY
GAIN
OUTPUT IMPEDANCE
OUTPUT NOISE
VALVE COMPLIMENT
FUSE RATINGS
MAX. POWER CONSUMPTION
TOTAL WEIGHT
TOTAL SHIPPING WEIGHT
(ORIGINAL PACKAGING)
UNIT DIMENSIONS
PACKAGING DIMENSIONS
NOTE
47K Ohms
160mV for 1V Output
16dB at 1KHz
600 Ohms
-80dB unweighted (RMS)
1 x 6463 (line stage)
1 x 6189 (line stage)
2 x 5651 (PSU)
2 x 6X5
2 x ECL82 (PSU)
1.6A anti-surge (110 / 120V supply)
800mA anti-surge (220 / 240V supply)
170 VA
30 KG (two units)
40 KG
140mm (h) x 440mm (w) x 410mm (d)
140mm (h) x 440mm (w) x 410mm (d)
235mm (h) x 540mm (w) x 510mm (d)
Due to Audio Note (UK)'s ongoing
research and development program,
specifications are subject to change
without notice.
(PSU)
