Audio Note M8 Line Signature Owner's Information page 12

CONNECTION OVERVIEW continued...
Outputs The M8 Line Signature preamplifier is equipped with two pairs of
Single Ended / RCA outputs, consisting of two colour coded pairs of
RCA / Single Ended sockets. RED is for RIGHT channel connection,
WHITE is for LEFT channel connection.
There are also two pairs of balanced outputs, each consisting of a pair
of 'male' XLR sockets (see 'Balanced' section, below).
XLR / BALANCED OUTPUTS
R L R
L
R L
L
R
BALANCED /
SINGLE ENDED
SWITCH
RCA / SINGLE ENDED
OUTPUTS, LEFT AND RIGHT
