NOTE:
Please read all instructions
carefully before using this
product
Table of Contents
Safety Notice
Hardware Identifier
Assembly Instruction
Parts List
Computer
Exercise
Warranty
Ordering Parts
Model
ZON
Retain This
Manual for
Reference
05-27-03
OWNER'S
MANUAL
MARCY Elliptical Recumbent
IMPEX FITNESS PRODUCTS
14777 DON JULIAN RD., CITY OF INDUSTRY, CA 91746
Tel: (800) 999-8899 Fax: (626) 961-9966
www.impex-fitness.com
info@impex-fitness.com
ZON

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the ZON and is the answer not in the manual?

Questions and answers

Related Manuals for Impex ZON

Summary of Contents for Impex ZON

  • Page 1 Hardware Identifier Assembly Instruction Parts List Computer Exercise Warranty Ordering Parts Model Retain This Manual for Reference 05-27-03 IMPEX FITNESS PRODUCTS 14777 DON JULIAN RD., CITY OF INDUSTRY, CA 91746 OWNER'S Tel: (800) 999-8899 Fax: (626) 961-9966 MANUAL www.impex-fitness.com info@impex-fitness.com...

  • Page 2: Table Of Contents

    COMPUTER....................…… EXERCISE....................…… WARRANTY....................…. ORDERING PARTS..................… BEFORE YOU BEGIN Thank you for selecting the MARCY Elliptical Recumbent ZON by IMPEX FITNESS PRODUCTS. For your safety and benefit, read this manual carefully before using the machine. As a manufacturer, we are committed to provide you complete customer satisfaction.

  • Page 3: Important Safety Notice

    IMPORTANT SAFETY NOTICE PRECAUTIONS This exercise machine is built for optimum safety. However, certain precautions apply whenever you operate a piece of exercise equipment. Be sure to read the entire manual before you assemble or operate your machine. In particular, note the following safety precautions: 1.

  • Page 4: Hardware Identifier

    HARDWARE PACK Part# Description Identifier M6 x 1 3/8” Philips Screw (Qty 4) M8 x 3/8” Allen Bolt (Qty 4) M6 x 5/8” Philips Screw (Qty 4) M8 x 5/8” Allen Bolt (Qty 12) Ø 5/8” Washer (Qty 16) Allen Wrench (Qty 1)

  • Page 5: Assembly Instruction

    ASSEMBLY INSTRUCTION Tools Required Assembling the Machine: Philips Head Screwdriver and Allen Wrench. NOTE: It is strongly recommended two or more people assembling this machine to avoid possible injury. STEP 1 (See Diagram1) A.) Slide the Seat Support (#3) onto the Chromed Sliding Track (#2). B.) Place the Sliding Track (#2) onto the Main Frame (#1).
  • Page 6 STEP 2 (See Diagram 2) A.) Attach the Left Pedal (#11) to the Left Pedal Support (#5). Secure it with three M8 x 5/8” Allen Bolts (#17) and Ø 5/8” Washers (#18). B.) Repeat Procedure A above to install the Right Pedal (#12) to the Right Pedal Support (#6).
  • Page 7 STEP 3 (See Diagram 3) A.) Attach the Handlebar (#7) to the Seat Support (#3). Secure it with four M8 x 3/8” Allen Bolts (#15) and Ø 5/8” Washers (#18). B.) Connect Motor Wire (#19), Power Wire (#20) and Sensor Wire (#21) from Handlebar to the Main Frame.
  • Page 8 STEP 4 (See Diagram 4) A.) Place the Seat (#9) onto the Seat Support (#3). Secure it with four M6 x 5/8” Philips Screws (#16). B.) Attach the Backrest Board (#10) to the Seat Support. Secure it with four M6 x 1 3/8” Philips Screws (#14).

  • Page 10: Parts List

    PARTS LIST KEY NO. DESCRIPTION QUANTITY Main Frame Chromed Sliding Track Seat Support Front Cap Left Pedal Support Right Pedal Support Handlebar Computer Seat Backrest Board Left Pedal Right Pedal Handlebar Cover M6 x 1 3/8” Philips Screw M8 x 3/8” Allen Bolt M6 x 5/8”...

  • Page 11: Computer

    COMPUTER FUNCTION KEY: ST/SP: Press this key to START or STOP computer. Press and hold down this key for 2 seconds, the Computer will reset all values to zero and reset to initial mode. ENTER/MODE: Use this key to select the mode of TIME, DISTANCE, CALORIES, and PULSE.

  • Page 12: Operating The Computer

    Operating the Computer 1. Select exercise program After turning on the computer, use UP/DOWN key to select exercise program from Manual to Program 6. The default is Manual. Press Enter to confirm the selection. M A N U A L Program 3 Program 6 L oad...

  • Page 13: Exercise

    Program 6 is a unique program which allows the computer to adjust the workout resistance according to your pre-set heart rate. If your heart rate is greater than your target heart rate, the computer will decrease the workout resistance automatically. If your heart rate is less than your target heart rate, the computer will increase the resistance level to help you achieve higher heart rate.

  • Page 14: Maintenance And Storage

    C. Duration: Each workout should consist of warm up, training zone exercise and cool down. Warm up should be one important part of every workout. Prepare the body for strenuous exercise by increasing circulation to deliver more oxygen to the muscles, and raising body temperature.

  • Page 15: Impex Inc

    IMPEX INC. LIMITED WARRANTY IMPEX Inc. ("IMPEX") warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of two years on the Frame from the date of purchase. This warranty extends only to the original purchaser. IMPEX's obligation under this Warranty is limited to replacing or repairing, at IMPEX's option.
