Summary of Contents for Impex AX-266

  • Page 1 NOTE: Please read all instructions carefully before using this product APEX COMBO BENCH Table of Contents Safety Notice AX-266 Hardware Identifier Assembly Instruction Parts List Warranty Ordering Parts Model AX-266 Retain This Manual for Reference 04-05-05 OWNER'S IMPEX INC. MANUAL 14777 DON JULIAN RD., CITY OF INDUSTRY, CA 91746...
  • Page 2: Table Of Contents

    WARRANTY....................…………. 10 ORDERING PARTS..................………… 10 BEFORE YOU BEGIN Thank you for selecting the APEX AX-266 COMBO BENCH by IMPEX INC. For your safety and benefit, read this manual carefully before using the machine. As a manufacturer, we are committed to provide you complete customer satisfaction.
  • Page 3: Important Safety Notice

    IMPORTANT SAFETY NOTICE PRECAUTIONS This exercise machine is built for optimum safety. However, certain precautions apply whenever you operate a piece of exercise equipment. Be sure to read the entire manual before you assemble or operate your machine. In particular, note the following safety precautions: 1.
  • Page 5: Assembly Instruction

    ASSEMBLY INSTRUCTION Tools Required Assembling the Machine: Two Adjustable Wrenches. NOTE: It is strongly recommended two or more people assembling this machine to avoid possible injury. STEP 1 (See Diagram 1) A.) Connect the two Rear Upright Beams (#1) by the Cross Brace (#2) in the mid-span. Align the holes then secure each end of Cross Brace with one Bracket (#13), two M10 x 2 3/8”...
  • Page 6 STEP 2 (See Diagram 2) A.) Attach the rear of the Main Seat Support (#3) to the Cross Brace (#2). Secure it with one Bracket (#13), two M10 x 2 3/8” Hex Bolts (#25), four ¾” Washers (#33), and two M10 Aircraft Nuts (#30).
  • Page 7 STEP 3 (See Diagram 3) A.) Attach the front holes on the Backrest Supports (#7) to the pivot on the Main Seat Support (#3). Place the other end of the Backrest Supports (#7) on the Backrest Adjustment Bar (#6). Place the Backrest Board (#8) onto the Backrest Supports (#7). Secure it with four M6 x 1 3/8”...
  • Page 8 STEP 4 (See Diagram 4) A.) Attach the Leg Developer (#10) to the front of Main Seat Support (#3). Secure it with a Hex Socket Axle (#23) and Hex Socket Screw (#24). Attach one Spring Clip (#14) onto the weight post on the Leg Developer. B.) Insert the two Foam Roll Tubes (#11) halfway through the holes on the Leg Developer.
  • Page 10: Parts List

    PARTS LIST KEY NO. DESCRIPTION Q’ty Rear Upright Beam Cross Brace Main Seat Support Front Support Diagonal Support Backrest Adjustment Bar Backrest Support Backrest Board Seat Pad Leg Developer Foam Roll Tube Foam Roll Bracket Spring Clip 1” Sleeve Left Safety Hook Right Safety Hook Bushing 1 ½”...
  • Page 11: Impex Inc

    IMPEX INC. LIMITED WARRANTY IMPEX Inc. ("IMPEX") warrants this product to be free from defects in workmanship and material, under normal use and service conditions, for a period of two years on the Frame from the date of purchase. This warranty extends only to the original purchaser. IMPEX's obligation under this Warranty is limited to replacing or repairing, at IMPEX's option.

Table of Contents
