Heath Zenith DualBrite Security Light 5630 Owner's Manual

D B
ual rite
Light
Model 5630
Meets the ENERGY STAR
when D
ON-TIME is 1 or 5 minutes.
FEaTurES
• Turns on lighting when motion is detected.
• Automatically turns lighting off.
• D B feature for dusk to dawn low level lighting.
®
ual rite
• Photocell keeps the lighting off during daylight
hours.
This package includes:
Sensor
Wall Light
1 Halogen Lamp
© 2007 HeathCo LLC
Security
®
guidelines
®
B function is off and
®
ual rite
1 Adapter Bracket
3 Wire Connectors
4 Mounting Screws
rEquIrEMENTS
• The light control requires 120 Volts AC, 60 Hz.
• If you want to use Manual Mode, the control must be
wired through a switch.
• Some codes require installation by a
qualified electrician.
OPEraTION
Mode: On-Time:
Test
5 Sec
Normal 1, 5, 20 min.
Manual
Until Dawn*
* resets to Normal Mode at dawn.
Note: When first turned on wait about 1
the circuitry to calibrate.
TEST
Put ON-TIME switch inside wall light
in the TEST position.
NOrMaL
Put the ON-TIME switch in the 1, 5,
or 20 minute position.
MaNuaL MODE
Manual mode only works at night
because daylight returns the sensor
to Normal.
Flip the light switch off for one sec-
ond then back on to toggle between
Normal and MANUAL MODE.
Manual mode works only with the
ON-TIME switch in the 1, 5, or 20
position.
Works: Day Night
x x
x
x
/ minutes for
1
2
ON-TIME
20
5
1
TEST
ON-TIME
20
5
1
TEST
1 Second OFF
then...
... back on.
598-1132-06
