Operator's Manual
Gasoline containing up to 10% ethanol (E10) is accept-
able for use in this machine. The use of any gasoline ex-
ceeding 10% ethanol (E10) will void the product warranty.
Owner's Manual
Esta máquina puede utilizar gasolina con un contenido
de hasta el 10% de etanol (E10). El uso de una gasolina
YTH23K46
que supere el 10% de etanol (E10) anulará la garantía
del producto. the product warranty.
Please read the operator's manual carefully and make sure
you understand the instructions before using the machine.
581 36 66-40
Por favor lea cuidadosamente y comprenda
English
estas intrucciones antes de usar esta maquina.
Advertisement
Table of Contents
Related Manuals for Husqvarna YTH23K46
Summary of Contents for Husqvarna YTH23K46
- Page 1 Owner's Manual Esta máquina puede utilizar gasolina con un contenido de hasta el 10% de etanol (E10). El uso de una gasolina YTH23K46 que supere el 10% de etanol (E10) anulará la garantía del producto. the product warranty. Please read the operator's manual carefully and make sure you understand the instructions before using the machine.
-
Page 2: Safety Rules
SAFETY RULES Safe Operation Practices for Ride-On Mowers DANGER: THIS CUTTING MACHINE IS CAPABLE OF AMPUTATING HANDS AND FEET AND THROW ING OBJECTS. FAILURE TO OBSERVE THE FOLLOWING SAFETY INSTRUCTIONS COULD RESULT IN SERIOUS INJURY OR DEATH. • Never leave a running machine unattended. Always turn WARNING: In order to prevent ac ci den tal off blades, set parking brake, stop engine, and remove starting when setting up, trans port ing,... - Page 3 SAFETY RULES Safe Operation Practices for Ride-On Mowers III. CHILDREN • If fuel is spilled on clothing, change clothing immediately. • Never overfill fuel tank. Replace gas cap and tighten securely. WARNING. CHILDREN CAN BE INJURED BY THIS EQUIPMENT. The American Academy GENERAL SERVICE of Pediatrics recommends that children be a •...
-
Page 4: Table Of Contents
PRODUCT SPECIFICATIONS CONGRATULATIONS on your purchase of a new tractor. It has been designed, engineered and manu fac tured to Gasoline Capacity 3.0 Gallons/11,35 L give you the best possible dependability and performance. and type: Unleaded Regular Should you experience any problem you cannot easily Oil Type (API: SG-SL): SAE 10W30 (above 32°F/0°C) remedy, please contact your nearest authorized service SAE 5W30 (below 32°F/0°C) -
Page 5: Assembly
UNASSEMBLED PARTS Keys Slope Sheet Battery (1) Oil Drain Tube (2) Hex Bolts (1) Quick Connect (2) Nut Keps Key(s) ASSEMBLY Your new tractor has been assembled at the factory with the exception of those parts left unassembled for shipping purposes. TOOLS REQUIRED FOR ASSEMBLY A socket wrench set will make assembly easier. - Page 6 ASSEMBLY ✓ CHECKLIST NOTE: You may now roll your tractor off the skid. Follow the instructions below to remove the tractor from the skid. BEFORE YOU OPERATE YOUR NEW TRAC TOR, WE WARNING: Before start ing, read, un der stand and fol low WISH TO ASSURE THAT YOU RECEIVE THE BEST all in struc tions in the Op er a tion section of this man u al.
-
Page 7: Operation
OPERATION These symbols may appear on your tractor or in literature supplied with the product. Learn and understand their meaning. FAST HIGH SLOW REVERSE NEUTRAL CHOKE IGNITION SWITCH ENGINE START REVERSE ENGINE ON PARKING BRAKE MOWER HEIGHT MOWER LIFT ENGINE OFF OPERATION SYSTEM (ROS) CLUTCH/BRAKE... - Page 8 OPERATION KNOW YOUR TRACTOR READ THIS OPERATOR'S MANUAL AND SAFETY RULES BEFORE OPERATING YOUR TRACTOR Compare the illustrations with your tractor to familiarize yourself with the locations of various controls and ad just ments. Save this manual for future reference. Fig.
- Page 9 OPERATION The operation of any tractor can result in foreign objects thrown into the eyes, which can result in severe eye dam age. Always wear safety glass es or eye shields while operating your tractor or per form ing any ad just ments or repairs. We rec om mend standard safety glasses or a wide vision safety mask worn over spectacles.
- Page 10 OPERATION TO USE CRUISE CONTROL (J) (See Fig. 7) TO ADJUST GAUGE WHEELS (See Fig. 9) The cruise control feature can be used for forward travel only. Gauge wheels are prop er ly ad just ed when they are slight ly off the ground when mower is at the desired cutting height in operating position.
- Page 11 OPERATION REVERSE OPERATION SYSTEM (ROS) (See TO TRANSPORT (See Figs. 3 and 12) Fig. 11) When pushing or towing your tractor, be sure to disengage transmission by placing freewheel control in free wheel ing Your tractor is equipped with a Reverse Operation System po si tion.
-
Page 12: Before Starting The Engine
OPERATION BEFORE STARTING THE ENGINE TO START ENGINE (See Fig. 3) When starting the engine for the first time or if the engine CHECK ENGINE OIL LEVEL has run out of fuel, it will take extra cranking time to move fuel from the tank to the engine. -
Page 13: Mowing Tips
OPERATION MOWING TIPS PURGE TRANSMISSION • Tire chains cannot be used when the mower hous ing CAUTION: Never engage or disengage is attached to tractor. freewheel lever while the engine is run ning. • Mower should be properly leveled for best mowing performance. -
Page 14: Maintenance Schedule
MAINTENANCE BEFORE EVERY EVERY EVERY EVERY EVERY BEFORE MAINTENANCE EACH SEASON STORAGE SCHEDULE HOURS HOURS HOURS HOURS Check Brake Operation Check Tire Pressure Check Operator Presence & ROS Systems Check for Loose Fasteners Check/Replace Mower Blades Lubrication Chart Check Battery Level Clean Battery and Terminals Clean Debris Off Steering Plate ck Transaxle Cooling... -
Page 15: Maintenance
MAINTENANCE TRACTOR CAUTION: Use only a replacement blade ap- proved by the manufacturer of your tractor. Us- Always observe safety rules when per form ing any ing a blade not approved by the manufacturer main te nance. of your tractor is hazardous, could damage BRAKE OPERATION your tractor and void your warranty. -
Page 16: Engine Oil Filter
MAINTENANCE TRANSAXLE COOLING LOWER DASH The transmission fan and cooling fins should be kept clean COVER to assure proper cooling. Do not attempt to clean fan or transmission while engine is running or while the transmission is hot. To prevent pos - FASTENER si ble damage to seals, do not use high pressure water or SLOTS... -
Page 17: Clean Air Screen
MAINTENANCE CLEANING AIR FILTER • Clean engine, battery, seat, finish, etc. of all foreign Your engine will not run properly using a dirty air filter. matter. Service air cleaner more often under dusty conditions. • Clean debris from steering plate. Debris can restrict CLEAN AIR SCREEN clutch/brake pedal shaft movement, causing belt slip Air screen must be kept free of dirt and chaff to prevent... - Page 18 MAINTENANCE DECK WASHOUT PORT (See Fig. 20) Your tractor’s deck is equipped with a washout port on its surface as part of its deck wash system. It should be utilized after each use. 1. Drive the tractor to a level, clear spot on your lawn, near enough to a water spigot for your garden hose to reach.
-
Page 19: Service And Adjustments
SERVICE AND ADJUSTMENTS WARNING: TO AVOID SERIOUS INJURY, BEFORE PERFORMING ANY SER VICE OR AD JUST MENTS: • Depress brake pedal fully and set parking brake. • Place attachment clutch in “DISENGAGED” position. • Turn ignition key to “STOP” and remove key. •... -
Page 20: Service And Adjustments
SERVICE AND ADJUSTMENTS • ATTACH MOWER SIDE SUSPENSION ARMS (A) TO • Insert end of link (E) into hole in front mower bracket CHASSIS - Position hole in arm over pin (B) on outside and secure with washer and retainer spring (J). of tractor chassis and secure with retainer spring. - Page 21 SERVICE AND ADJUSTMENTS TO LEVEL MOWER • If adjustment is necessary, see step in Visual Adjust- ment instructions above. Make sure tires are properly inflated to the PSI shown on • Recheck measurements, adjust if necessary until both tires. If tires are over or under inflated, it may affect the sides are equal.
-
Page 22: To Replace Mower Blade Drive Belt
SERVICE AND ADJUSTMENTS TO REPLACE MOWER BLADE DRIVE BELT TO REPLACE MOTION DRIVE BELT (See Fig. 31) (See Fig. 32) Park the tractor on level surface. En gage parking brake. The mower blade drive belt may be replaced without tools. For as sis tance, there is a belt installation guide decal on Park the tractor on level surface. - Page 23 SERVICE AND ADJUSTMENTS FRONT WHEEL TOE-IN/CAMBER TO REMOVE CABLES, REVERSE ORDER - • BLACK cable first from chassis and then from the fully Your new tractor front wheel toe-in and camber is set at the charged battery. factory and is normal. The front wheel toe-in and camber •...
-
Page 24: Service And Ad Just Ments
SERVICE AND ADJUSTMENTS ENGINE TO REPLACE HEADLIGHT BULB • Raise hood. TO AD JUST THROTTLE CON TROL CABLE • Pull bulb holder out of the hole in the backside of the grill. The throttle control has been preset at the factory and •... -
Page 25: Storage
STORAGE ENGINE Immediately prepare your tractor for storage at the end of the season or if the tractor will not be used for 30 days or more. FUEL SYSTEM IMPORTANT: IT IS IMPORTANT TO PREVENT GUM DEPOSITS WARNING: Never store the trac tor with FROM FORMING IN ES SEN TIAL FUEL SYSTEM PARTS SUCH gas o line in the tank inside a building AS CARBURETOR, FUEL FIL TER, FUEL HOSE, OR TANK... -
Page 26: Troubleshooting
TROUBLESHOOTING PROBLEM CAUSE CORRECTION 1. Out of fuel. 1. Fill fuel tank. Will not start 2. Engine not “CHOKED” properly. 2. See “TO START ENGINE” in Operation section. 3. Engine flooded. 3. Wait several minutes before attempting to start. 4. Bad spark plug. 4. - Page 27 TROUBLESHOOTING PROBLEM CAUSE CORRECTION Engine continues 1. Faulty operator-safety presence control 1. Check wiring, switches and connections. If not system. corrected, contact an authorized service center/ to run when oper- department. ator leaves seat with attachment clutch engaged 1. Worn, bent or loose blade. 1.
- Page 29 (a) Engines and Attachments.Except where otherwise indicated on Exhibit A, all Engines and Attachments are not covered by this Limited Warranty. In most cases, these items are NOT manufactured by Husqvarna in which case they may be covered separately by their respective manufacturer's warranties if one is provided and included with the product at the time of purchase.
- Page 30 10. Authorized Husqvarna Servicing Dealer/Center. In order to obtain warranty coverage it is your responsibility (at your expense) to deliver or ship your Husqvarna unit to an authorized Husqvarna Servicing Dealer/Center and arrange for pick-up or return of your unit after the repairs have been made.
-
Page 31: Warranty
Riding Lawn Tractors: Frame, Chassis, Front Axle 5 Years No Warranty No Warranty Engine* Transmission (if made by Husqvarna/Peerless) 3 Years No Warranty No Warranty Transmission (if third party)** XLS Models only - stamped deck shell. Armor Protected Limited Warranty... - Page 32 ** See reference 1 (b) of the warranty statement. RZ - Two (2) Year Consumer warranty, parts & labor, with Hydro-Gear Distributor network. EZ - One (1) Year Commercial warranty, parts & labor, with Husqvarna. Two (2) Year Consumer warranty, parts & labor, with Hydro-Gear Distributor network.
-
Page 33: Español
07/24/2012 JM...
