  • Page 1 Operator and Parts Manual Collection System 966406901...
  • Page 2 CAUTION BEFORE ASSEMBLING GRASS CATCHER TO MOWER • Set parking brake. • Place motion control levers in “NEUTRAL” position. • Turn ignition key “OFF” and remove key. • Make sure the blades and all moving parts have completely stopped. • Disconnect spark plug and place wire where it cannot come in contact with plug.

  • Page 3: Table Of Contents

    REPAIR PARTS ............12 KNOW YOUR BLOWER SYSTEM CONGRATULATIONS on the purchase of a new collection system. It has been designed, engineered READ THIS OPERATION MANUAL AND SAFETY and manufactured to give you the best possible RULES BEFORE ASSEMBLING OR OPERATING dependability and performance.

  • Page 4: Safety Rules

    SAFETY RULES SAFE OPERATION PRACTICES FOR RIDE-ON MOWERS DANGER! THIS CUTTING MACHINE IS CAPABLE OF AMPUTATING HANDS AND FEET AND THROWING OBJECTS. FAILURE TO OBSERVE THE FOLLOWING SAFETY INSTRUCTIONS COULD RESULT IN SERIOUS INJURY OR DEATH. GENERAL OPERATION • If front weights are included in the collection • Read, understand and follow all instructions in the system, DO NOT operate mower with the grass manual and on the machine before starting.

  • Page 5: Children

    SAFETY RULES SAFE OPERATION PRACTICES FOR RIDE-ON MOWERS • Never run a machine inside a closed area. • Do not mow on wet grass. Reduced traction could cause sliding. • Keep nuts and bolts, especially blade attachment • Do not try to stabilize the machine by putting your bolts, tight and keep equipment in good foot on the ground. condition. • Never tamper with safety devices. Check regularly CHILDREN for proper operation. Tragic accidents can occur if the operator is not • Keep machine free of grass, leaves, or other alert to the presence of children. Children are often debris buildup. Clean oil or fuel spillage. Allow attracted to the machine and the mowing activity. machine to cool before storing. Never assume that children will remain where you last saw them. • Stop and inspect the equipment if you strike an object. Repair, if necessary, before restarting. • NEVER allow children to operate the machine. • Never make adjustments or repairs with the • Keep children out of the mowing area and under engine running.

  • Page 6: Assembly

    (torque to 90 ft./lbs.). Rotate the blades by hand and check for clearance of all baffles. NOTE: The collection system includes optional deck Make sure all hardware is tight. baffling designed to help prevent blow out when collecting in extremely dry cutting conditions. If cutting conditions are not extremely dry, baffling may not be required.
  • Page 7 ASSEMBLY MOUNTING BLOWER ASSEMBLY INSTALLING DRIVE PULLEY At the rear of the blower, remove the mount pin Using two " wrenches, remove the hardware and retainer that are connected to the blower by and discharge chute from the deck. (Deck the lanyard.
  • Page 8 ASSEMBLY INSTALLING COLLECTOR INSTALLING DRIVE BELT Using two " wrenches, remove the lower ROPS Install drive belt around pulley on blower. bolts on each side, retaining washer and nut for Rotate belt keeper within " of blower pulley and next step. tighten with ½"...
  • Page 9 ASSEMBLY Attach the hitch tubes to the hitch assembly with With the hood/hitch assembly behind the mower, 2¼" bolts and nuts as shown. Tighten using " place the lower slotted portion of the hitch tubes and ¾" wrenches. Install pin mounts through the over the hitch pins attached to the bottom of the hitch tubes and hitch assembly and secure with ROPS.
  • Page 10 ASSEMBLY Attach the hose to the hood assembly and secure with hose clamp. CAUTION • DO NOT operate mower with grass Loosen the retention knob on the outlet end of the blower. catcher partially installed. • Disengage blades and stop engine Slide hose over the blower outlet and against the before leaving mower seat to base of the retention bracket.

  • Page 11: Operation

    OPERATION TIPS FOR IMPROVED BAGGING GENERAL RECOMMENDATIONS Follow the mower operation instructions in the mower Always observe safety rules when performing any operator’s manual. maintenance. When operating your grass catcher on a lawn where • Before each use check for loose fasteners. grass and leaf bagging equipment has not been •...

  • Page 12: Repair Parts

    P/N 115 234827R2 01/08/10...
