Page 1: User Manual
The most trusted name in power protection. ™ SU-1500-DC USER MANUAL UPS OPERATION Ver 1.0 - Rev. A... - Page 2 TABLE OF CONTENTS Controls and Indicators Configurable Parameters & Settings Limited Product Warranty © 2011 SurgeX...
- Page 3 INTRODUCTION Thank you for purchasing this power protection product. It has been designed and manufactured to provide many years of trouble free service. IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS ! Please read this manual before installing your UPS, as it provides important information that should be followed during installation and maintenance of the UPS and batteries allowing you to correctly set up your system for the maxi- mum safety and performance.
- Page 4 This symbol indicates "Direct Current Supply" This symbol indicates "Equipment Grounding Conductor" CAUTION! Connect the UPS to a two pole, three wire grounding AC wall outlet. The receptacle must be connected to the appropriate branch protection (circuit breaker or fuse). Connection to any other type of receptacle may result in a shock hazard and violate local electrical codes.
-
Page 5: Receiving Inspection
NOTICE: This equipment has been tested and found to comply with the limits for a Class A and/or Class B computing device in accordance with the specifi- cations in Subpart J of Part 15 of FCC Rules and the Class A and/or Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference of the Canadian Department of Communications. -
Page 6: Life Support Policy
Life Support Policy As a general policy, we do not recommend the use of any of our products in life support applications where failure or malfunction of the product can be reason- ably expected to cause failure of the life support device or to significantly affect its safety or effectiveness. -
Page 7: Control Panel
CONTROLS AND INDICATORS CONTROL PANEL The ONLINE (green) LED illuminates in a steady state when the UPS is on and the inverter is providing the output power. The ONLINE LED will extinguish when oper- ating in the Battery mode. The LINE (green) LED illuminates in a steady state when the UPS is connected to Utility Power and there is an acceptable AC voltage present. - Page 8 The ON BATT (green) LED illuminates in a steady state when the UPS is oper- ating in the Battery mode. The ON BATT LED will extinguish when operating in the On-Line and the Bypass modes. The BATT LOW (yellow) LED illuminates in a steady state when the UPS reaches a low battery condition.
-
Page 9: Rear Panel
REAR PANEL 1. The input power cord (120V models). 2. The input circuit breaker will trip in the event the load exceeds the UPS’s power rating. 3. The option slot is for option cards. 4. The Battery Backup output power receptacles. The output receptacles are electrically wir- ed into two segments to support the "Load Shedding Function". -
Page 10: Installation & Placement
INSTALLATION INSTALLATION PLACEMENT This UPS series is intended to be install in a temperature controlled environ- ment that is free of conductive contaminants. Select a location which will provide good air circulation for the UPS at all times. Avoid locations near heat- ing devices, water or excessive humidity, or where the UPS is exposed to direct sunlight. -
Page 11: Rackmount Configuration
RACKMOUNT CONFIGURATION The UPS comes with mounting brackets for the standard 19" (46.5cm) rack. The mounting brackets to fit a 23" (59.2cm) standard rack are also available. The screws for mounting the UPS to the rack are not included (screw size varies with rack size). -
Page 12: Connecting Your Equipment
CONNECTING YOUR EQUIPMENT Plug the equipment into the output receptacles on the rear panel of the UPS. Do not use extension cords, adapter plugs or surge strips on the output of the UPS. Ensure that you do not exceed the maximum output rating of the UPS (refer to the information label on the UPS or the Electrical Specifications in this manual). -
Page 13: System Overview
OPERATION SYSTEM OVERVIEW This On-Line UPS protects computers, servers, internetworking, and telecom- munications equipment from blackouts, brownouts, overvoltages, and surges. This On-Line UPS converts the input AC to DC and then back to a True Sine Wave AC output. The True Sine Wave output is regulated within 2% of the nominal output voltage. -
Page 14: Output Voltage Settings
OFF Button Press the OFF button for 1-beep (2-seconds) to turn the UPS off. SELF TEST The self test feature is useful to verify the correct operation of the UPS and the condition of the batteries. With the UPS in the AC normal mode, press the ON/ Test/Alarm Silencer Button for 1-beep (2-seconds) to perform a battery test. -
Page 15: Option Slot
RJ11 REPO (Remote Emergency Power Off) PORT In the AC or the Battery mode short pin4 to pin5 for approximately 0.5-seconds to shutdown the UPS. The UPS must be turned off and then back on again to restart the UPS. POWER MONITORING SOFTWARE The UPS comes with a Power Monitoring Software CD. -
Page 16: Troubleshooting
TROUBLESHOOTING What To Do Possible Cause Symptom Press and release the On/Off/ On/Off/Test button not UPS will not turn on Test button to start UPS pushed Input AC circuit breaker is Reset circuit breaker by UPS operates in pressing the plunger back in. battery mode only, tripped even though there is... -
Page 17: Replacing The Battery
REPLACING THE BATTERY REPLACING THE BATTERY (QUALIFIED SERVICE PERSONNEL ONLY) The UPS has an easy to replace hot-swappable batteries. Please read all of the WARNINGS and CAUTIONS before attempting to service the batteries. NOTE: If there is a power interruption while replacing the hot-swappable batteries, with the UPS on, the load will not be backed up. -
Page 18: Battery Replacement Procedure
CAUTION: Replace batteries with the same number and type as originally installed in the UPS. These batteries have pressure operated vents. These UPSs contain sealed non-spillable maintenance-free lead acid batteries. 4-12V7.2Ah Battery Qty/Rating GP 1272 F2 CSB Part # LC-R127.2 Panasonic Part # NP-7.2-12 Yuasa Part #... - Page 19 8. Remove the two retaining screws for the battery retaining bracket. (FIG. 3) 9. Remove the battery retaining bracket. (FIG. 3) 10. Disconnect the Battery connectors (red and black). (FIG. 4) 11. Grasp the battery pull tab and gently pull the battery module out of the UPS and set on the floor.
-
Page 20: Obtaining Service
5. Mark the RMA # on the outside of all packages. The factory cannot accept any package without the RMA # marked on the outside. 6. Return the UPS by insured, prepaid carrier to: SurgeX 517 North Industrial Dr. Zebulon, NC 27597... -
Page 21: Specifications
SPECIFICATIONS SYSTEM SPECIFICATIONS Topology Double Conversion On-Line, True Sine Wave Maximum Power Capacity 1500VA/1200W INPUT ∅ 2W +G) Nominal Voltage 120VAC Acceptable Input voltage 0 - 150VAC 90 - 138VAC Voltage Range >97% at Full Load Power Factor Correction Frequency Limits 50 or 60 Hz, +/-6Hz, autosensing Low Voltage Transfer Point 80/90V resets to Utility Power at 86/96V or higher... - Page 22 BATTERY SYSTEM Battery Type Sealed, Non-Spillable, Maintenance Free, Value Regulated Lead Acid Typical Recharge Time 8-hours from total discharge Typical Battery Life 3-5 years, depending on discharge cycles and ambient temp System Voltage 48VDC Battery: Quantity/Rating 4-12V7.2Ah Runtime: Half Load (minutes) Runtime: Full Load (minutes) SURGE PROTECTION AND FILTERING Max.
-
Page 23: Configurable Parameters
CONFIGURABLE PARAMETERS AND SETTINGS (These items may require optional software or hardware) Description User Choices Function Factory Default Use this function to uniquely UPS ID Endeavor Up to 64 charac- identify the UPS in your network Series ters to define configuration the UPS Date of... - Page 24 ™ For a period of 11 years from the date of your purchase of any SurgeX product, SurgeX warrants the product against defects in materials used by SurgeX or workmanship performed by SurgeX (a "Covered Product"). SurgeX's obligations with...
