Page 1: User Manual
The most trusted name in power protection. ™ SU-2000Li USER MANUAL UPS OPERATION Ver 1.0 - Rev. A... - Page 2 TABLE OF CONTENTS Controls and Indicators Configurable Parameters & Settings Limited Product Warranty © 2011 SurgeX...
- Page 3 INTRODUCTION Thank you for purchasing this power protection product. It has been designed and manufactured to provide many years of trouble free service. IMPORTANT SAFETY INSTRUCTIONS SAVE THESE INSTRUCTIONS ! This symbol indicates "ATTENTION" This symbol indicates "Risk of Electrical Shock" This symbol indicates "Alternating Current Supply Phase"...
- Page 4 This symbol indicates "Direct Current Supply" This symbol indicates "Equipment Grounding Conductor" CAUTION! Connect the UPS to a two pole, three wire grounding AC wall outlet. The receptacle must be connected to the appropriate branch protection (circuit breaker or fuse). Connection to any other type of receptacle may result in a shock hazard and violate local electrical codes.
-
Page 5: Receiving Inspection
NOTICE: This equipment has been tested and found to comply with the limits for a Class B computing device in accordance with the specifications in Sub- part J of Part 15 of FCC Rules and the Class B limits for radio noise emissions from digital apparatus set out in the Radio Interference of the Canadian Depart- ment of Communications. -
Page 6: Life Support Policy
Life Support Policy As a general policy, we do not recommend the use of any of our products in life support applications where failure or malfunction of the product can be reason- ably expected to cause failure of the life support device or to significantly affect its safety or effectiveness. -
Page 7: Control Panel
CONTROLS AND INDICATORS CONTROL PANEL The AC normal (green) LED illuminates in a steady state when the UPS is on and operating in the AC normal mode. The AC normal LED will extinguish when operating in the Battery mode. The On-Battery (green) LED illuminates in a steady state when the UPS is operating in the Battery mode. - Page 8 The Load Level Bar Graph (AC mode only) operates as follows: LED #10: >10% load (green/red/yellow) LED will be green and illu- minated when there is at least 10% of the rated capacity. LED #30: >30% load (green/yellow) LED will be green and illumi- nated when there is at least 30% of the rated capacity.
-
Page 9: Rear Panel
11. The External Ground Stud is for connecting an external ground wire. 12. The R-J11/R-J45 modular connectors are used for 10/100 Base-T Network/single line Phone/Fax/Modem protection. Input Power Plug Model # Output Power Receptacles (All power cords are 10ft) 6-NEMA 5-15/20R NEMA 5-20P SU-2000Li 1-NEMA L5-20R... -
Page 10: Installation & Placement
INSTALLATION INSTALLATION PLACEMENT This UPS series is intended to be install in a temperature controlled environ- ment that is free of conductive contaminants. Select a location which will provide good air circulation for the UPS at all times. Avoid locations near heat- ing devices, water or excessive humidity, or where the UPS is exposed to direct sunlight. -
Page 11: Rackmount Configuration
RACKMOUNT CONFIGURATION This UPS comes with mounting brackets for the standard 19" (46.5cm) rack. The mounting brackets to fit a 23" (59.2cm) standard rack are also available. The screws for mounting the UPS to the rack are not included (screw size varies with rack size). -
Page 12: Connecting Your Equipment
CONNECTING YOUR EQUIPMENT Plug the equipment into the output receptacles on the rear panel of the UPS. Do not use extension cords, adapter plugs or surge strips on the output of the UPS. Ensure that you do not exceed the maximum output rating of the UPS (refer to the information label or the Electrical Specifications in this manual). -
Page 13: System Overview
OPERATION SYSTEM OVERVIEW This Line-Interactive UPS protects computers, internetworking, and telecom- munications equipment from blackouts, brownouts, overvoltages, and surges. The AVR function continuously corrects the voltages, in-between the brownout and overvoltage transfer points (80 - 164VAC/150 - 271VAC), to a safe usable level. -
Page 14: Dip Switch Settings
SELF TEST The self test feature is useful to verify the correct operation of the UPS and the condition of the batteries. With the UPS in the AC normal mode, press and hold the On/Off/Test Button for four beeps, then release the button. The UPS will perform a ten-second self test. -
Page 15: Option Slot
USB PORT The USB protocol is HID. The HID USB driver is standard in the Windows OS. Simply plug the USB cable into the UPS and the computer then follow the prompts on the screen. RJ11 REPO (Remote Emergency Power Off) PORT Connect one end of the RJ11 cable to the REPO port and the other end of the RJ11 cable to the EPO switch. -
Page 16: Troubleshooting
TROUBLESHOOTING What To Do Possible Cause Symptom On/Off/Test button not Press and release the On/Off/ UPS will not turn on Test button to start UPS pushed Reset circuit breaker by UPS operates in Input AC circuit breaker is tripped pressing the plunger back in. battery mode only, even though there If the AC circuit breaker trips... -
Page 17: Replacing The Battery
REPLACING THE BATTERY REPLACING THE BATTERY (QUALIFIED SERVICE PERSONNEL ONLY) This UPS has an easy to replace hot-swappable batteries. Please read all of the WARNINGS and CAUTIONS before attempting to service the batteries. NOTE: If there is a power interruption while replacing the hot-swappable batter- ies, with the UPS on, the load will not be backed up. -
Page 18: Battery Replacement Procedure
Replace batteries with the same number and type as originally installed in the UPS. These batteries have pressure operated vents. These UPSs contain sealed non-spillable maintenance-free lead acid batteries. Model # SU-2000Li Battery Qty/Rating 6-12V7.2Ah CSB Part # GP 1272 F2 Panasonic Part # LC-R127.2... - Page 19 8. Remove the two retaining screws for the battery retaining bracket. (FIG. 3) 9. Remove the battery retaining bracket. (FIG. 3) 10. Disconnect the Battery connectors (red and black). (FIG. 4) 11. Grasp the battery pull tab and gently pull the battery module out of the UPS and set on the floor.
-
Page 20: Obtaining Service
5. Mark the RMA # on the outside of all packages. The factory cannot accept any package without the RMA # marked on the outside. 6. Return the UPS by insured, prepaid carrier to: SurgeX 517 North Industrial Dr. Zebulon, NC 27597... -
Page 21: Specifications
SPECIFICATIONS SYSTEM SPECIFICATIONS Line-Interactive, Sine Wave Topology 2000VA Maximum Power Capacity 1760W INPUT ∅ 2W +G) Nominal Voltage 120VAC Acceptable Input voltage 0 - 165VAC 80 - 164VAC Voltage Range Frequency Limits 50 or 60 Hz, +/-6Hz, autosensing 80V (150V) resets to Utility Power at 85V (157V) or higher Low Voltage Transfer Point High Voltage Transfer Point 164V (271V) resets to Utility Power at 159V (264V) or lower Resettable Circuit Breaker... - Page 22 BATTERY SYSTEM Battery Type Sealed, Non-Spillable, Maintenance Free, Value Regulated Lead Acid Typical Recharge Time 8-hours from total discharge Typical Battery Life 3-5 years, depending on discharge cycles and ambient temp System Voltage 72VDC Battery: Quantity/Rating 6-12V7.2Ah Runtime: Half Load (minutes) Runtime: Full Load (minutes) SURGE PROTECTION AND FILTERING Surge Energy Rating...
-
Page 23: Configurable Parameters
CONFIGURABLE PARAMETERS AND SETTINGS (These items may require optional software or hardware) User Choices Description Function Factory Default Use this function to uniquely UPS ID Enterprise Up to 64 charac- identify the UPS in your network ters to define the Plus Series configuration Date of... - Page 24 ™ For a period of 11 years from the date of your purchase of any SurgeX product, SurgeX warrants the product against defects in materials used by SurgeX or workmanship performed by SurgeX (a "Covered Product"). SurgeX's obligations with...
