ASROCK G41M-VS3 R2.0 Datasheet

G41M-VS3 R2.0
®
Intel G41+ ICH7 Chipsets
Product Brief
- Supports FSB1333/1066/800/533 MHz CPUs
- Supports Dual Channel DDR3 1333 (OC)
- Intel ® Graphics Media Accelerator X4500,
Pixel Shader 4.0, DirectX 10, Max. shared
memory 1759MB
- Supports ASRock XFast USB, Instant Boot,
Instant Flash, OC DNA, OC Tuner, IES,
SmartView, APP Charger
- Free Bundle : CyberLink DVD Suite - OEM and
Trial; Creative Sound Blaster X-Fi MB - Trial
The specification is subject to change without notice. The brand and product names are trademarks of their
respective companies. Any configuration other than original product specification is not guaranteed.
w w w. a s rock . co m

Detail Specification

- Micro ATX Form Factor: 8.9-in x 6.7-in, 22.6 cm x 17.0 cm
Platform
- LGA 775 for Intel
CPU
/ Pentium Dual Core / Celeron
®
Penryn Quad Core Yorkfield and Dual Core Wolfdale processors
- Supports FSB1333/1066/800/533 MHz
- Supports Hyper-Threading Technology
- Supports Untied Overclocking Technology
- Supports EM64T CPU
- Northbridge: Intel
Chipset
- Southbridge: Intel
- Dual Channel DDR3 memory technology
Memory
- 2 x DDR3 DIMM slots
- Supports DDR3 1333(OC)/1066/800 non-ECC, un-buffered memory
- Max. capacity of system memory: 8GB
- 1 x PCI Express x16 slot
Expansion Slot
- 1 x PCI slot
- Intel Graphics Media Accelerator X4500
Graphics ®
- Pixel Shader 4.0, DirectX 10
- Max. shared memory 1759MB
- Supports D-Sub with max. resolution up to 2048x1536 @ 75Hz
- 5.1 CH HD Audio (VIA
Audio
- Atheros PCIEx1 LAN AR8152
®
LAN
- Speed: 10/100 Ethernet
- Supports Wake-On-LAN
I/O Panel
Rear Panel I/O
- 1 x PS/2 Mouse Port
- 1 x PS/2 Keyboard Port
- 1 x VGA Port
- 4 x Ready-to-Use USB 2.0 Ports
- 1 x RJ-45 LAN Port with LED (ACT/LINK LED and SPEED LED)
- HD Audio Jack: Line in / Front Speaker / Microphone
- 4 x SATAII 3.0 Gb/s connectors
Connector
(No support for RAID and "Hot Plug" functions)
- 1 x ATA100 IDE connector (supports 2 x IDE devices)
- 1 x Print port header
- 1 x COM port header
- CPU/Chassis FAN connector
- 24 pin ATX power connector
- 4 pin 12V power connector
- Front panel audio connector
- 2 x USB 2.0 headers (support 4 USB 2.0 ports)
- 8Mb AMI Legal BIOS
BIOS Feature
- Supports "Plug and Play"
- ACPI 1.1 Compliance Wake Up Events
- SMBIOS 2.3.1 Support
- VCCM, NB, VTT, GTLRef Voltage Multi-adjustment
- Drivers, Utilities, AntiVirus Software (Trial Version), ASRock
Support CD
Software Suite (CyberLink DVD Suite - OEM and Trial; Creative
Sound Blaster X-Fi MB - Trial)
- ASRock OC Tuner
Unique Feature
- Intelligent Energy Saver
- Instant Boot
- ASRock Instant Flash
- ASRock OC DNA
- ASRock AIWI
- ASRock APP Charger
- SmartView
- ASRock XFast USB
- Hybrid Booster:
- CPU Frequency Stepless Control
- ASRock U-COP
- Boot Failure Guard (B.F.G.)
- CPU Temperature Sensing
Hardware Monitor
- Chassis Temperature Sensing
- CPU Fan Tachometer
- Chassis Fan Tachometer
- CPU Quiet Fan
- Voltage Monitoring: +12V, +5V, +3.3V, CPU Vcore
- Microsoft Windows
®
OS
64-bit compliant
- FCC, CE, WHQL
Certifications
- ErP/EuP Ready (ErP/EuP ready power supply is required)
- Quick Installation Guide, Support CD, I/O Shield
Accessories
- 2 x SATA Data Cables (Optional)
Core 2 Extreme / Core 2 Quad / Core
® TM TM TM
Dual Core / Celeron , supporting
® ®
G41
®
ICH7
®
VT1705 Audio Codec)
®
7 / 7 64-bit / Vista / Vista 64-bit / XP / XP
® TM TM
2 Duo
