Overview

Your Kramer VP-211K is a high performance 2x1 automatic switcher for
computer graphics video (UXGA) and stereo audio signals. The VP-211K
detects the presence of the active VGA-type input signal from either IN 1 (the
1
default ) or IN 2—depending on how the DEFAULT INPUT switch is set, as
section 5.2 describes—and automatically routes it to the acceptor connected
to the UXGA OUT and the AUDIO OUT connectors.
In addition, the VP-211K:
With its video bandwidth of 00MHz, ensures transparent operation at the
highest resolutions
Automatically switches the stereo audio signal with the video signal
(audio-follow-video) when switching the active input to the output
Includes a DEFAULT INPUT switch for selecting the default UXGA
master source signal
Includes a loop UXGA output for connecting an additional display
Comes with contact closure remote control for forced operation
Uses active switching and has flexible sync detection and reconstruction
circuitry
Includes the Kramer innovative integrated sync processing; KRISP™
technology, which lets you achieve a sharp, stable image when the sync
level is too low, by restoring the sync signal waveform
Achieving the best performance means:
Connecting only good quality connection cables, thus avoiding
interference, deterioration in signal quality due to poor matching, and
elevated noise levels (often associated with low quality cables)
Avoiding interference from neighboring electrical appliances and
positioning your VP-211K away from moisture, excessive sunlight and
dust
1 When the DEFAULT INPUT switch is set to IN 1
2 For example, part number 2535-052002
Overview
Caution
– No operator-serviceable parts inside unit.
Warning
– Use only the Kramer Electronics input power
wall adapter that is provided with this unit
Warning
– Disconnect power and unplug unit from wall
before installing or removing device or servicing unit.
