REMOTE KEY WITH PCC* – PERSONAl CAR COMMuNICATOR
PCC*
1
Green light: vehicle is locked.
2
Yellow light: vehicle is unlocked.
3
Red light: alarm has been triggered.
4
Alternatively flashing red lights: the alarm
was triggered less than 5 minutes ago.
STARTING THE ENGINE
– Holding the end of the remote key with the base of
the key blade, insert the remote key into the ignition
slot and press it in as far as possible.
– Press the START/STOP/
ENGINE button briefly to start
the engine.
the doors and tailgate and arms
Locks
the alarm
.
A
the doors and tailgate, and
Unlocks
disarms the alarm
Tailgate: press to unlock the tailgate.
Approach lighting illuminates lights in door
mirrors, cabin, footwells, license plates. Turn
signals and parking lights illuminate.
"Panic" alarm.
Press and hold to sound the alarm.
–
Turn off alarm with unlock button.
nformation about the vehicle can be
I
gathered within a range of 300 ft.
(100 m).
Press the button and wait for 7 sec-
–
onds.
If the vehicle is out of range when the
button is pressed, the most recently
stored status information will be shown.
A
The accessory inclination and movement alarm sensors
can be turned off. See the "Alarm" section of your owner's
manual for information.
B
Automatic relock occurs if no door/tailgate is opened within
.
2 minutes after unlock
– Press the brake pedal.
COlDSTART
NOTE
After cold starts, your engine will idle at a
higher speed for a short time.
B
