- Page 1 VGA/USB/PS2 with built-in 2 port KVM switch up to 150 metres Installation and User Manual For Sales and Service please contact ICP Global Pty Ltd Phone - 02 9314 2092 Fax - 02 9344 9537 Suite 603, Level 5, 152 Bunnerong Road...
-
Page 2: Package Contents
150mtr away on a single CATx UTP cable. The AN150P CAT 5 KVM Extender Set comprises two distinct units- The Receiver (Rx) Unit and the Transmitter (Tx) Unit. The Tx Unit and the Rx Unit will be located each on one end of the CATx UTP cable. - Page 3 Front Panel & Rear Panel View Transmitter (Tx) Unit – Front Panel Transmitter (Tx) Unit – Back Panel Connect to the 1st (Local) computer...
-
Page 4: Transmitter Unit
Transmitter Unit [Tx – Front Panel] a. Power LED (ON: Power on / OFF: Power off) b. Link LED (ON: Link OK / OFF: No Link) c. PS/2 keyboard connector (6-pin Mini Din) d. PS/2 mouse connector (6-pin Mini Din) e. -
Page 5: Receiver Unit
Receiver (Rx) Unit – Back Panel Connect to the remote console and optional 2nd (Remote) computer Receiver Unit [Rx – Front Panel] 1. Power LED (ON: Power on / OFF: Power off) 2. Link LED (ON: Link OK / OFF: No Link) 3. -
Page 6: Preparation Before Installation
a special 3-in-1 KVM Combo cable) 13. Console Video port (HDB15, connect to monitor) Preparation before Installation Before you install the two pieces of the CAT5 KVM Extender Set, you should have these items on the checklist ready: 1. The computer for extension should be one with either PS/2 or USB interfaces. 2. - Page 7 Out-of-the-box-Installation Take the package items out of the box and begin installation…. Plan the layout path and deploy the UTP cable for extension Step 1. Plan the path through which the CATx UTP cable will be deployed across the distance between the Transmitter and the Receiver. You should choose the layout path not only base on shortest possible length consideration, but also on least electromagnetic interference.
- Page 8 Step 11. Check the keyboard, mouse, video, audio output and mic input on Console 2 to see if it works fine. At this time, the video might be blurred since it is not yet adjusted and optimized. Step 12. Adjust the video parameters to optimize the display output (Refer to OSD Menu/Video section for details).
- Page 9 OSD Menu On the Receiver Unit, the OSD Menu control is available to facilitate more intuitive operations. Users can configure various settings by the OSD Menu: OSD Menu To evoke the OSD Menu, you should hit the following keyboard hotkeys: Hotkey sequence = [CAPS]* + [CAPS] * + H + (y) (y) = L_Ctrl, R_Ctrl, SCROLL, CAPS, F12 or NUM Hotkey preceding sequence configuration: The hotkey preceding sequence is default...
- Page 10 Main Menu Autologout: [0 ~ 60] Disable / Enable the Logout timeout (0~60min, 0 = Disable). The Autologout time can be configured from 0 (Disable), with an increment of 5, right up to 60 Min. If the password protection is not enabled, the Autologut will not be put into function.
- Page 11 Password: Disable/Enable the password protection feature. After you logout or the timeout of Autologout, you will be prompted for correct password before you can access the console again. Video Settings: Here you can enter a submenu to configure the video settings such as Brightness, Sharpness and skew compensation for Phase Red and Phase Green.
- Page 12 Video Settings Submenu The blue component color is adjusted automatically as in proportion to the red and green. Users have no need to adjust themselves. In order to achieve optimized video output on the console that may be 150 Meters away from the computer, users could adjust these various parameters conscientiously to achieve an optimized video output on the console monitor.
- Page 13 Change the Hotkey Preceding Sequence (Only available on Receiver Unit) To change the hotkey preceding sequence (or trigger sequence) of your hotkeys, please hit the following key commands: Hotkey sequence = [CAPS]* + [CAPS] * + H + (y)* (y) = L_Ctrl, R_Ctrl, SCROLL, CAPS, F12 or NUM Note that the hotkey preceding sequence setting on the Receiver Console will not affect the hotkey preceding sequence on the Transmitter Console, which will always allows CAPS + CAPS as preceding hotkey.
-
Page 14: Optimize The Video Display On The Remote Console
Optimize the Video Display on the Remote Console To achieve an optimized display output on the remote console (i.e. the Receiver) will require you to conscientiously adjust the various video parameters such as Brightness and Sharpness in an optimized combination that could most satisfy your visual requirements. - Page 15 When you have adjusted the Brightness and Sharpness to achieve a passable situation, you can temporarily leave them there and try to work on the Red Delay and Green Delay adjustment so that you can see a cleaner picture for further fine-tuning …...
- Page 16 Switch Between Local / Remote Computer (Hotkey Available only on Receiver Console) On the Receiver Console, one can switch between the 1 computer (connected across 150M via CATx cable) and the 2 computer (connected directly to the Receiver) by the following hotkey command: Hotkey sequence = [CAPS]* + [CAPS] * + (y)** (y) = ←, →...
