- Page 1 PHY1000P DVI with Audio KVM Extender Installation and User’s Manual For Sales and Service please contact ICP Global Pty Ltd Phone - 02 9314 2092 Fax - 02 9344 9537 Suite 603, Level 5, 152 Bunnerong Road PAGEOOD NSW 2035...
-
Page 2: Package Contents
Introduction The PHY1000P is the perfect solution to extend WUXGA (1920 x 1200) DVI-D with audio and USB keyboard/mouse across single CATx UTP cable. The extender contains a PHY1000T transmitter unit and a PHY1000R Receiver unit. Based on video... - Page 3 Connection PHY1000R Receiver PHY1000T Transmitter...
- Page 4 Installation 1. Attach DVI display, USB keyboard/mouse, microphone, headset (or speaker) to the PHY1000R’s DVI-Out, USB-A, Mic-In, Line-Out ports. 2. Attach PC DVI-D to the PHY1000T’s DVI-In port by a DVI-to-DVI cable. 3. Connect PHY1000T’s mini USB port to PC USB by a mini USB-to-USBA cable. 4.
