X548de, X548dte
Technical Reference
April 2012
www.lexmark.com

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the X548de and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Lexmark X548de

Summary of Contents for Lexmark X548de

  • Page 1 X548de, X548dte Technical Reference April 2012 www.lexmark.com...

  • Page 2: Edition Notice

    April 2012 The following paragraph does not apply to any country where such provisions are inconsistent with local law: LEXMARK INTERNATIONAL, INC., PROVIDES THIS PUBLICATION “AS IS” WITHOUT WARRANTY OF ANY KIND, EITHER EXPRESS OR IMPLIED, INCLUDING, BUT NOT LIMITED TO, THE IMPLIED WARRANTIES OF MERCHANTABILITY OR FITNESS FOR A PARTICULAR PURPOSE.

  • Page 3: Table Of Contents

    Contents Contents Edition notice....................2 Introduction....................5 Understanding letters after model numbers....................5 Learning about the printer................7 Finding information about the printer......................7 Printer Control Language (PCL) page formatting...........9 Printable areas............................9 Supported paper and envelope dimensions...................10 Printer Job Language (PJL)................12 PJL commands information........................12 PostScript (PS) emulation................13 Supported paper sizes..........................13 PostScript paper tray support.........................14 PostScript envelope size support......................15...
  • Page 4 Contents Appendix B: PJL support................31 Common variables for both printer languages..................31 Lexmark‑unique PJL variables for both printer languages..............33 Common variables for PCL emulation.....................43 Lexmark‑unique variables for PCL emulation..................43 Common variables for PostScript emulation...................44 Lexmark‑unique variables for PostScript emulation................44 Lexmark‑unique LRESOURCE variables....................44 Status Readback commands........................44...

  • Page 5: Introduction

    Introduction Introduction Overview This edition of the Technical Reference contains information about the following multifunction printers (MFPs): X548de X548dte Understanding letters after model numbers Some Lexmark printers and MFP options may have one or more letters after the model number to indicate features.
  • Page 6 Introduction Acronym Meaning network and ImageQuick network and additional tray Duplex (two‑sided) printing using an optional duplex unit or an internal duplex unit based on the product The additional tray may be part of a drawer.

  • Page 7: Learning About The Printer

    Finding information about the printer What are you looking for? Find it here Initial setup instructions: Setup documentation—The setup documentation came with the printer and is also available on the Lexmark Web • Connecting the printer site at http://support.lexmark.com. •...
  • Page 8 Learning about the printer What are you looking for? Find it here Latest supplemental information, updates, and customer Lexmark Support Web site— support: http://support.lexmark.com • Documentation Note: Select your country or region, and then select your product to view the appropriate support site.

  • Page 9: Printer Control Language (Pcl) Page Formatting

    Printer Control Language (PCL) page formatting Printer Control Language (PCL) page formatting For more information on PCL, see the Printer Languages and Interfaces Technical Reference. It contains a complete listing with descriptions of PCL commands. To determine which PCL commands your printer supports, see “Appendix A: PCL support” on page 22. Printable areas The printable areas and logical pages for PCL emulation (both portrait and landscape orientation) are illustrated below.

  • Page 10: Supported Paper And Envelope Dimensions

    For the Universal paper size, the area dimensions are listed in pel ranges. Paper ID 99 will be supported for backward compatibility with other Lexmark printers. Paper ID 99 has the same logical paper size as ID 100 (compatible with HP LaserJet 5Si/5SiMx) but is 8 pels wider than the Lexmark 4039.
  • Page 11 For the Universal paper size, the area dimensions are listed in pel ranges. Paper ID 99 will be supported for backward compatibility with other Lexmark printers. Paper ID 99 has the same logical paper size as ID 100 (compatible with HP LaserJet 5Si/5SiMx) but is 8 pels wider than the Lexmark 4039.

  • Page 12: Printer Job Language (Pjl)

    Printer Job Language (PJL) Printer Job Language (PJL) PJL commands information Your printer supports complete PJL commands, including certain commands that cause the printer to enter PCL emulation, PostScript emulation, and Personal Printer Data Stream (PPDS). For a complete listing with descriptions of PJL commands, see the Printer Languages and Interfaces Technical Reference. To determine which commands your printer supports, see “Appendix B: PJL support”...

  • Page 13: Postscript (Ps) Emulation

    = Supported X = Not supported Printer Paper sizes models Size Literal name Size (mm) Size (inches) Size (points) X548de, X548dte 11 x 17 11x17 279.4 x 431.8 11 x 17 792 x 1224 17 x 11 ledger 431.8 x 279.4...

  • Page 14: Postscript Paper Tray Support

    Tray selected with tray operators = Supported X = Not supported Printer models Operator Tray selected (corresponding image size is set) X548de, X548dte 11x17tray tray with 11 x 17‑size paper a3tray tray with A3‑size paper a4tray tray with A4-size paper...

  • Page 15: Postscript Envelope Size Support

    PostScript (PS) emulation = Supported X = Not supported Printer models Operator Tray selected (corresponding image size is set) X548de, X548dte a5tray tray with A5-size paper a6tray tray with A6-size paper b4tray tray with B4‑size paper b5tray tray with B5-size paper...

  • Page 16: Postscript Envelope Tray Support

    * For other envelopes, the page is formatted to 215.9 x 355.6 mm (8.5 x 14 in.) unless a size is specified by your software program. Literal names supported = Supported X = Not Supported Literal names Printer models Literal name Compatible literal name X548de, X548dte c5envelope 162x229envelope com10envelope 4.125x9.5envelope dlenvelope 110x220envelope monarcenvelope 3.875x7.5envelope...
  • Page 17 = Supported X = Not supported Tray operators Printer models Operator Tray selected (corresponding image size is set) X548de, X548dte 110x220envelopetray tray with 110 x 220‑size envelopes dlenvelopetray tray with 110 x 220‑size envelopes 162x229envelopetray tray with 162 x 229‑size envelopes c5envelopetray tray with 162 x 229‑size envelopes...

  • Page 18: Printer Specifications

    The room should meet ASHRAE 62—1989 standards. Noise emission levels The following measurements were made in accordance with ISO 7779 and reported in conformance with ISO 9296. X548de, X548dte Status Declared sound pressure level, dBA Declared sound power level, bels...

  • Page 19: Power Requirements

    Width Depth Weight with cartridges (unpackaged) X548de 463 mm (18.23 in.) 440 mm (17.32 in.) 597 mm (23.50 in.) 27.8 kg (61.3 lb) X548dte 597 mm (23.50 in.) 440 mm (17.32 in.) 597 mm (23.50 in.) 32.1 kg (70.7 lb) Optional 550-sheet tray 133 mm (5.2 in.)

  • Page 20: Clearance Requirements

    Air relative humidity (RH) Air relative humidity (RH) Air relative humidity (RH) (unpackaged) (packaged) X548de, 8–80% 8–80% 5–95% X548dte Cartridge air temperature ranges Printer model Shipping and storage value Cartridges (packaged) ‑40°C to 43.3°C (‑40°F to 110°F) X548de, X548dte...

  • Page 21: Altitude And Atmospheric Pressure Specifications

    Altitude and atmospheric pressure specifications Altitude specifications Altitude (above sea level) Printer model Operating value Shipping and storage value X548de, X548dte 0–3048 m (10000 ft) Less than 10300 m (34000 ft) Atmospheric pressure specifications Atmospheric pressure Printer model Operating value X548de, X548dte Less than 74.6 kPa...

  • Page 22: Appendix A: Pcl Support

    Appendix A: PCL support Appendix A: PCL support PCL emulation commands = Supported X = Not supported Printer model Command Function X548de, X548dte Decimal 8 Backspace (BS) Decimal 9 Horizontal Tab (HT) Decimal 10 Line Feed (LF) Decimal 12 Form Feed (FF)
  • Page 23 Appendix A: PCL support = Supported X = Not supported Printer model Command Function X548de, X548dte Character Text Path Direction &c#T Disable Underline &d@ Collation ‑ Collated Copies (QTY) &d#A Select Underline Type &d#D Set Universal Height &f#F Set Universal Width &f#G...
  • Page 24 Appendix A: PCL support = Supported X = Not supported Printer model Command Function X548de, X548dte Job Separation & Left (Long-Edge) Offset Registration & Set Copy Count & Top (Short-Edge) Offset Registration & Alphanumeric ID &n#W [operation] [string id] Palette Control &p#C...
  • Page 25 Appendix A: PCL support = Supported X = Not supported Printer model Command Function X548de, X548dte Secondary Font Stroke Weight )s#B Secondary Font Pitch )s#H Secondary Font Spacing )s#P Secondary Font Style )s#S Secondary Font Typeface Selection )s#T Secondary Font Height (Point Size)
  • Page 26 Appendix A: PCL support = Supported X = Not supported Printer model Command Function X548de, X548dte Picture Frame Horizontal Size (in Decipoints) *c#X Picture Frame Vertical Size (in Decipoints) *c#Y Logical Operation Pixel Placement Color Lookup Tables #W[data] Download Dither Matrix...
  • Page 27 Appendix A: PCL support = Supported X = Not supported Printer model Command Function X548de, X548dte Render Algorithm *t#J Scale Algorithm *t#K Set Resolution *t#R Raster Height (Destination) *t#V Set Raster Configuration *g#W Color Component One *v#A Color Component Two...

  • Page 28: Gl/2 Commands

    Appendix A: PCL support GL/2 commands = Supported X = Not supported Printer model Command Function X548de, X548dte Arc Absolute Anchor Corner Define Alternate Font Arc Relative Arc Absolute Three Point Bezier Relative Bezier Absolute Character Fill Circle Comment Character Plot...
  • Page 29 Appendix A: PCL support = Supported X = Not supported Printer model Command Function X548de, X548dte Fill Polygon, Non-Zero Winding Fill Type Fill Type - 22 Fill Type - 9 Initialize Input P1 and P2 Input Relative P1 and P2...
  • Page 30 Appendix A: PCL support = Supported X = Not supported Printer model Command Function X548de, X548dte Rotate Coordinate System Fill Rectangle Relative Arc Relative Three Point Select Alternate Font Scalable/Bitmapped Fonts Scale Define Standard Font Absolute Character Size Character Slant...

  • Page 31: Appendix B: Pjl Support

    Appendix B: PJL support Appendix B: PJL support Common variables for both printer languages = Supported X = Not supported Printer model Variable name X548de, X548dte AUTOCONT AUTOSELECT BINDING BITSPERPIXEL CLEARABLEWARNINGS CONTEXTSWITCH COPIES CPLOCK DENSITY DISKLOCK DUPLEX ECONOMODE FORMATTERNUMBER FORMLINES...
  • Page 32 Appendix B: PJL support = Supported X = Not supported Printer model Variable name X548de, X548dte INTRAY1SIZE INTRAY2SIZE INTRAY3SIZE INTRAY4SIZE INTRAY5SIZE IOBUFFER IOSIZE JOBATTR JOBNAME JOBOFFSET LANG LOWTONER MANUALFEED MEDIASOURCE MEDIATYPE MPTRAY ORIENTATION OUTBIN PAGEPROTECT PAPER PARALLEL PASSWORD PERSONALITY POWERSAVE...

  • Page 33: Lexmark-Unique Pjl Variables For Both Printer Languages

    Variable name X548de, X548dte REPEATJOBTIMEOUT REPRINT RESERVEJOBTIMEOUT RESOLUTION RESOURCESAVE RESOURCESAVESIZE STRINGCODESET TIMEOUT USERNAME VERIFYJOBTIMEOUT WIDEA4 Lexmark‑unique PJL variables for both printer languages = Supported X = Not supported Printer model Variable name X548de, X548dte LACTIVEBINRESET LADVANCEDSTATUS LALARMCONTROL LAUTOCRLF LAUTOLFCR LBAYERSCREENLIMIT LBLANKPAGES...
  • Page 34 Appendix B: PJL support = Supported X = Not supported Printer model Variable name X548de, X548dte LBONDWEIGHT LBOTTOMMARGINOFFSET LBWLOCK LCANCEL LCARDSTOCKLENGTH LCARDSTOCKLOADING LCARDSTOCKOUTBIN LCARDSTOCKTEXTURE LCARDSTOCKWEIGHT LCOLLATION LCOLORBALANCEBLACK LCOLORBALANCECYAN LCOLORBALANCEMAGENTA LCOLORBALANCEYELLOW LCOLORCORRECTION LCOLOREDLENGTH LCOLOREDLOADING LCOLOREDOUTBIN LCOLOREDTEXTURE LCOLOREDWEIGHT LCOLORMODEL LCOLORSAVER LCOLORTRAPPING LCUSTOMPAPERUNITS...
  • Page 35 Appendix B: PJL support = Supported X = Not supported Printer model Variable name X548de, X548dte LCUSTOMTYPE1LOADING LCUSTOMTYPE1MEDIA LCUSTOMTYPE1NAME LCUSTOMTYPE1OUTBIN LCUSTOMTYPE1TEXTURE LCUSTOMTYPE1WEIGHT LCUSTOMTYPE2LENGTH LCUSTOMTYPE2LOADING LCUSTOMTYPE2MEDIA LCUSTOMTYPE2NAME LCUSTOMTYPE2OUTBIN LCUSTOMTYPE2TEXTURE LCUSTOMTYPE2WEIGHT LCUSTOMTYPE3LENGTH LCUSTOMTYPE3LOADING LCUSTOMTYPE3MEDIA LCUSTOMTYPE3NAME LCUSTOMTYPE3OUTBIN LCUSTOMTYPE3TEXTURE LCUSTOMTYPE3WEIGHT LCUSTOMTYPE4LENGTH LCUSTOMTYPE4LOADING LCUSTOMTYPE4MEDIA LCUSTOMTYPE4NAME...
  • Page 36 Appendix B: PJL support = Supported X = Not supported Printer model Variable name X548de, X548dte LCUSTOMTYPE5LOADING LCUSTOMTYPE5MEDIA LCUSTOMTYPE5NAME LCUSTOMTYPE5OUTBIN LCUSTOMTYPE5TEXTURE LCUSTOMTYPE5WEIGHT LCUSTOMTYPE6LENGTH LCUSTOMTYPE6LOADING LCUSTOMTYPE6MEDIA LCUSTOMTYPE6NAME LCUSTOMTYPE6OUTBIN LCUSTOMTYPE6TEXTURE LCUSTOMTYPE6WEIGHT LDOWNLOADTARGET LDRYTIMEDELAY LDUPLEXLEFTMARGINOFFSET LDUPLEXTOPMARGINOFFSET LDUPLICATEHELDJOBS LECOMODE LENVELOPEENHANCE LENVELOPELENGTH LENVELOPEOUTBIN LENVELOPETEXTURE LENVELOPEWEIGHT...
  • Page 37 Appendix B: PJL support = Supported X = Not supported Printer model Variable name X548de, X548dte LFAXREDIALFREQUENCY LFAXRESOLUTION LFAXTRANSMISSIONLOG LFOLD LFEEDERPAPERTYPE LGLOSSYLOADING LGLOSSYOUTBIN LGLOSSYTEXTURE LGLOSSYWEIGHT LHEAVYGLOSSYLOADING LHEAVYGLOSSYOUTBIN LHEAVYGLOSSYTEXTURE LHEAVYGLOSSYWEIGHT LHEAVYPAPERLOADING LHEAVYPAPEROUTBIN LHEAVYPAPERTEXTURE LHEAVYPAPERWEIGHT LHELDJOBPRTORDER LHOLEPUNCHALARM LHOLEPUNCHMODE LHONORINIT LIMAGEESS LIMAGEBRIGHTNESS LIMAGECONTRAST...
  • Page 38 Appendix B: PJL support = Supported X = Not supported Printer model Variable name X548de, X548dte LINFEEDERSIZE LINKALERT LINMPFEEDERSIZE LJAMRECOVERY LJOBPARKPERSIST LJOBWAITFORSUPPLIES LLABELSLENGTH LLABELSLOADING LLABELSOUTBIN LLABELSTEXTURE LLABELSWEIGHT LLASTTRAYRENUMBER LLEFTMARGINOFFSET LLETTERHEADLENGTH LLETTERHEADLOADING LLETTERHEADOUTBIN LLETTERHEADTEXTURE LLETTERHEADWEIGHT LLIGHTPAPERLOADING LLIGHTPAPEROUTBIN LLIGHTPAPERTEXTURE LLIGHTPAPERWEIGHT LLINEDETAIL LMANUALCOLORRGBTEXT...
  • Page 39 Appendix B: PJL support = Supported X = Not supported Printer model Variable name X548de, X548dte LMANUALCOLORCMYKIMAGE LMANUALENVELOPESIZE LMANUALENVELOPETYPE LMANUALPAPERSIZE LMANUALPAPERTYPE MICRJOB LMAXSTATUSMSG LMPFEEDERPAPERTYPE LMPFEEDERRENUMBER LMULTIPAGEBORDER LMULTIPAGEORDER LMULTIPAGEPRINT LMULTIPAGEVIEW LNPAP LOPTIONALOUTBIN1NAME LOPTIONALOUTBIN2NAME LOPTIONALOUTBIN3NAME LOPTIONALOUTBIN4NAME LOPTIONALOUTBIN5NAME LOPTIONALOUTBIN6NAME LOPTIONALOUTBIN7NAME LOPTIONALOUTBIN8NAME LOPTIONALOUTBIN9NAME LOPTIONALOUTBIN10NAME...
  • Page 40 Appendix B: PJL support = Supported X = Not supported Printer model Variable name X548de, X548dte LPAPERSOURCE LPICTUREGRADE LPLAINLENGTH LPLAINOUTBIN LPLAINTEXTURE LPLAINWEIGHT LPOWERSAVER LPPDS LPPDSFORMLINES LPPDSLINESPERINCH LPREPRINTEDLENGTH LPREPRINTEDLOADING LPREPRINTEDOUTBIN LPREPRINTEDTEXTURE LPREPRINTEDWEIGHT LPRINTBUFFER LPRINTSCREENS LPRINTHEADIDLETIME LPRINTERUSAGE LPRINTMENUSBUTTON LPRINTQUALITY LPUNCH LQUIETMODE LREAROUTBINNAME...
  • Page 41 Appendix B: PJL support = Supported X = Not supported Printer model Variable name X548de, X548dte LREPEATPRINTLIMIT LRESET LRESOURCESAVE LRIGHTMARGINOFFSET LROUGHENVELOPELOADING LROUGHENVELOPEOUTBIN LROUGHENVELOPETEXTURE LROUGHENVELOPEWEIGHT LROUGHPAPERLOADING LROUGHPAPEROUTBIN LROUGHPAPERTEXTURE LROUGHPAPERWEIGHT LSCREENING LSEPARATORSHEETS LSEPARATORSOURCE LSMALLFONTENHANCER LSSGALVO LSTANDARDOUTBINNAME LSTAPLE LSTAPLESEMPTYALARM LSTAPLETESTBIN LSTAPLETESTSOURCE LSTROKEWIDTH LSUBSTITUTESIZE...
  • Page 42 Appendix B: PJL support = Supported X = Not supported Printer model Variable name X548de, X548dte LTRAY1AUTOSIZE LTRAY2AUTOSIZE LTRAY3AUTOSIZE LTRAY4AUTOSIZE LTRAY5AUTOSIZE LTRAY1PAPERTYPE LTRAY2PAPERTYPE LTRAY3PAPERTYPE LTRAY4PAPERTYPE LTRAY5PAPERTYPE LTRAY1RENUMBER LTRAY1SENSEDTYPEPAPER LTRAY1SENSEDTYPETRANSPARENCY LTRAY2SENSEDTYPEPAPER LTRAY2SENSEDTYPETRANSPARENCY LTRAY3SENSEDTYPEPAPER LTRAY3SENSEDTYPETRANSPARENCY LTRAY4SENSEDTYPEPAPER LTRAY4SENSEDTYPETRANSPARENCY LTRAYINSERTMESSAGEDELAY LTYPE1FONTS LUSDEFAULTS LVINYLLABELSLOADING LVINYLLABELSOUTBIN...

  • Page 43: Common Variables For Pcl Emulation

    Common variables for PCL emulation = Supported X = Not supported Printer model Variable name X548de, X548dte FONTNUMBER FONTSOURCE PITCH PTSIZE SYMSET Lexmark‑unique variables for PCL emulation = Supported X = Not supported Printer model Variable name X548de, X548dte LA4WIDTH LASSIGNFEEDER LASSIGNMANUALENVELOPE LASSIGNMANUALPAPER LASSIGNMPFEEDER...

  • Page 44: Common Variables For Postscript Emulation

    Common variables for PostScript emulation = Supported X = Not supported Printer model Variable name X548de, X548dte JAMRECOVERY PRTPSERRS ADOBEMBT Lexmark‑unique variables for PostScript emulation = Supported X = Not supported Printer model Variable name X548de, X548dte LPICTUREGRADE LPSFONTPRIORITY Lexmark‑unique LRESOURCE variables...

  • Page 45: Ustatus Unsolicited Status Variables

    Appendix B: PJL support = Supported X = Not supported Printer model Command X548de, X548dte USTATUS USTATUSOFF USTATUS unsolicited status variables = Supported X = Not supported Printer model Variable name X548de, X548dte DEVICE PAGE TIMED PJL messages for auto-continuable conditions...
  • Page 46 Appendix B: PJL support = Supported X = Not supported Printer model Message Status code Return string X548de, X548dte Intervention Required - 30016 37 Insufficient memory for Flash Insufficient Defragment Memory Defragment Memory operation Intervention Required - 30016 37 Insufficient...
  • Page 47 Appendix B: PJL support = Supported X = Not supported Printer model Message Status code Return string X548de, X548dte Intervention Required - 30018 56 Parallel Port Disabled Parallel Port Error Intervention Required - 30018 56 Serial [slot #] Port Disabled...
  • Page 48 Appendix B: PJL support = Supported X = Not supported Printer model Message Status code Return string X548de, X548dte Intervention Required - 30036 51 Defective Flash Defective Flash Intervention Required - 30036 53 Unformatted Flash Unformatted Flash Intervention Required -...
  • Page 49 Appendix B: PJL support = Supported X = Not supported Printer model Message Status code Return string X548de, X548dte Intervention Required - 30112 54 Network [x] software error Network [x] Software Error Intervention Required - 30112 54 Ser [x] Fax...
  • Page 50 Appendix B: PJL support = Supported X = Not supported Printer model Message Status code Return string X548de, X548dte Intervention Required - 32030 58 Too many flash options installed Too Many Flash Options Installed Intervention Required - 32052 53 Unformatted flash...

  • Page 51: Pjl Messages For Attendance Conditions

    Appendix B: PJL support = Supported X = Not supported Printer model Message Status code Return string X548de, X548dte Intervention Required - 40038 80 Fuser Exhausted Fuser Exhausted Intervention Required - 40038 80 Fuser/Belt Life Warning Fuser/Belt Life Warning Intervention Required -...
  • Page 52 Appendix B: PJL support = Supported X = Not supported Printer model Message Status code Return string X548de, X548dte Intervention Required - 32030 58 Too many bins attached Too Many Bins Attached Intervention Required - 32030 58 Too many flash...
  • Page 53 Appendix B: PJL support = Supported X = Not supported Printer model Message Status code Return string X548de, X548dte Intervention Required - 40021 Change Cartridge Invalid Refill Change Cartridge Invalid Refill Intervention Required - 40021 Close cover [x] Close Cover [x]...
  • Page 54 Appendix B: PJL support = Supported X = Not supported Printer model Message Status code Return string X548de, X548dte Intervention Required - 40021 Close surface H Close Surface Intervention Required - 40021 Close top access cover Close Cover Intervention Required -...
  • Page 55 Appendix B: PJL support = Supported X = Not supported Printer model Message Status code Return string X548de, X548dte Intervention Required - 40021 31.xx Replace defective cartridge Defective Print Cartridge Intervention Required - 40021 31.xx Replace defective print Defective Print Cartridge...
  • Page 56 Appendix B: PJL support = Supported X = Not supported Printer model Message Status code Return string X548de, X548dte Intervention Required - 40027 Install tray [x] Install Tray [x] or Cancel Job Intervention Required - 40027 Install Tray [x] or...
  • Page 57 Appendix B: PJL support = Supported X = Not supported Printer model Message Status code Return string X548de, X548dte Intervention Required - 40036 58 Too Many Disks Installed Too Many Disks Installed Intervention Required - 40037 31 PerfectFinish Missing PerfectFinish Missing...
  • Page 58 Appendix B: PJL support = Supported X = Not supported Printer model Message Status code Return string X548de, X548dte Intervention Required - 40038 88 Toner is low Toner Low Intervention Required - 40038 88 Toner Low Toner Low Intervention Required -...
  • Page 59 Appendix B: PJL support = Supported X = Not supported Printer model Message Status code Return string X548de, X548dte Intervention Required - 40087 59 Incompatible Bin [x] Incompatible Bin [x] Intervention Required - 40087 59 Incompatible output bin [x] Incompatible Output Bin [x]...
  • Page 60 Appendix B: PJL support = Supported X = Not supported Printer model Message Status code Return string X548de, X548dte Intervention Required - 40129 84 Replace color PC Units Replace Color PC Units Intervention Required - 40129 84.xx Replace [Color] photoconductor...
  • Page 61 Appendix B: PJL support = Supported X = Not supported Printer model Message Status code Return string X548de, X548dte Intervention Required - 40202 88.xx Magenta cartridge low Cartridge Low Intervention Required - 40202 88.1x magenta cartridge nearly low Cartridge Nearly Low...
  • Page 62 Appendix B: PJL support = Supported X = Not supported Printer model Message Status code Return string X548de, X548dte Intervention Required - 40204 84.xx [color] photoconductor nearly Photoconductor Nearly Low Intervention Required - 40215 83.xx Transfer module life warning Transfer Module Life Warning...
  • Page 63 Appendix B: PJL support = Supported X = Not supported Printer model Message Status code Return string X548de, X548dte Intervention Required - 40309 40 Black invalid refill, change Invalid Refill, Change Cartridge cartridge Intervention Required - 40310 32.xx Cyan cartridge...
  • Page 64 Appendix B: PJL support = Supported X = Not supported Printer model Message Status code Return string X548de, X548dte Intervention Required - 40316 80.xx Replace fuser Replace Fuser Intervention Required - 40316 87.xx Replace fuser Replace Fuser Intervention Required -...
  • Page 65 Appendix B: PJL support = Supported X = Not supported Printer model Message Status code Return string X548de, X548dte Intervention Required - 40409 31.xx Defective black cartridge Defective Cartridge Intervention Required - 40409 31.41 Missing or defective black Missing or Defective Cartridge...

  • Page 66: Pjl Messages For Paper Handling

    Appendix B: PJL support PJL messages for paper handling = Supported X = Not supported Printer model Message Status code Return string X548de, X548dte Intervention Required - 11xyy Tray [paper source #] Empty Tray [x] Empty Intervention Required - 12x01...
  • Page 67 Appendix B: PJL support = Supported X = Not supported Printer model Message Status code Return string X548de, X548dte Intervention Required - 4100x Check [paper source] orientation or Check [Paper Source] guides Orientation or Guides Intervention Required - 4100x Check [paper source]...
  • Page 68 Appendix B: PJL support = Supported X = Not supported Printer model Message Status code Return string X548de, X548dte Intervention Required - 41xyy Load single sheet feeder with [paper Load Manual [paper type] [paper type] [paper size] size] Intervention Required -...

  • Page 69: Pjl Messages For Paper Jams

    Appendix B: PJL support = Supported X = Not supported Printer model Message Status code Return string X548de, X548dte Intervention Required - 4300x Insert Tray [x] Insert Tray Request PJL messages for paper jams = Supported X = Not supported...
  • Page 70 Appendix B: PJL support = Supported X = Not supported Printer model Message Status code X548de, X548dte Intervention Required - 4208x Paper Jam Intervention Required - 4209x Paper Jam Intervention Required - 4210x Paper Jam Intervention Required - 4211x Paper Jam...
  • Page 71 Appendix B: PJL support = Supported X = Not supported Printer model Message Status code X548de, X548dte Intervention Required - 4241wy Paper Jam Intervention Required - 4241z Paper Jam Intervention Required - 4242wy Paper Jam Intervention Required - 4242z Paper Jam...
  • Page 72 Appendix B: PJL support = Supported X = Not supported Printer model Message Status code X548de, X548dte Intervention Required - 4251wy Paper Jam Intervention Required - 4251x Paper Jam Intervention Required - 4252w Paper Jam Intervention Required - 4253w Paper Jam...
  • Page 73 Appendix B: PJL support = Supported X = Not supported Printer model Message Status code X548de, X548dte Intervention Required - 427zx Paper Jam Intervention Required - 4271 Paper Jam Intervention Required - 4271z Paper Jam Intervention Required - 4272 Paper Jam...
  • Page 74 Appendix B: PJL support = Supported X = Not supported Printer model Message Status code X548de, X548dte Intervention Required - 4283x Paper Jam Intervention Required - 4283z Paper Jam Intervention Required - 4284w Paper Jam Intervention Required - 4284x Paper Jam...

  • Page 75: Service Errors

    X = Not supported Printer model Message X548de, X548dte RDYMSG OPMSG STMSG Lexmark‑unique PJL commands These commands are Lexmark extensions which have been added to the PJL command set to provide the user with remote control of many printer functions.

  • Page 76: File And Device Protection Commands

    Appendix B: PJL support = Supported X = Not supported Printer model Command X548de, X548dte LBEEP LPORTROTATE LPRINT testpage • LPRINTDIRECTORY • LPRINTTESTPAGE • LPRINTMENUS • LPRINTPCLFONTS • LPRINTPSFONTS LESCAPECHAR LFAX PHONENUMBER LOPENFILE LCLOSEFILE LREADFILE LWRITEFILE LRUNFILE LRENAMEFILE LDELETEFILE LFORMAT...
  • Page 77 Appendix B: PJL support = Supported X = Not supported Printer model Command X548de, X548dte LQUERYSEED...

  • Page 78: Appendix C: Postscript Support

    Appendix C: PostScript support Appendix C: PostScript support Supplemental operators = Supported X = Not supported Printer model Operator name X548de, X548dte appletalktype buildtime byteorder checkpassword currentfilenameextend currentmanualduplexmode currentuniversalsize defaulttimeouts deletefile devcontrol devdismount devforall devformat devmount devstatus diskonline diskstatus displayoperatormsg...
  • Page 79 Appendix C: PostScript support = Supported X = Not supported Printer model Operator name X548de, X548dte dosysstart duplexer duplexmode enginesync file filenameforall fileposition firstside fontnonzerowinding hardwareiomode idlefonts ignoresize initializedisk jobname jobsource jobtimeout manualfeed manualfeedtimeout newsheet pagecount pagesprinted papertray printername product...
  • Page 80 Appendix C: PostScript support = Supported X = Not supported Printer model Operator name X548de, X548dte ramsize realformat renamefile resolution revision sccbatch sccinteractive setcoverpage setdefaulttimeouts setdoidlefonts setdojamrecovery setdoprinterrors setdoret setdostartpage setdosysstart setduplexmode setenginesync setethernetaddress setfilenameextend setfileposition sethardwareiomode setidlefonts setignoresize setjobtimeout...

  • Page 81: Page Device Parameters

    Appendix C: PostScript support = Supported X = Not supported Printer model Operator name X548de, X548dte setquiet setresolution setsccbatch setsccinteractive setsoftwareiomode settumble setuniversalsize setuserdiskpercent softwareiomode tumble userdiskpercent waittimeout Page device parameters = Supported X = Not supported Printer model X548de, X548dte...
  • Page 82 Appendix C: PostScript support = Supported X = Not supported Printer model X548de, X548dte • TonerSaver • PictureGrade • ImageEnhancement • ImageEnhancementType • PrintDarkness • AutoMediaType • EdgeToEdge • DefaultPoliciesPageSize • SubstituteSize • LineDetail • Type • ColorCorrection • ColorBalance •...
  • Page 83 Appendix C: PostScript support = Supported X = Not supported Printer model X548de, X548dte • 1 - Tray 2 • 2 - Envelope Feeder • 3 - Tray 3 • 4 - Multipurpose Feeder • 5 - Tray 4 •...
  • Page 84 Appendix C: PostScript support = Supported X = Not supported Printer model X548de, X548dte • Orientation • Border • Order • Type • LandscapeOverride OutputAttributes • 0 - Standard Bin • 1 - Optional Bin 1 • 2 - Optional Bin 2 •...

  • Page 85: User Interpreter Parameters

    Appendix C: PostScript support = Supported X = Not supported Printer model X548de, X548dte • PolicyReport PostRenderingEnhance PostRenderingEnhanceDetails • REValue • Type PowerSave ProcessColorModel Punch SlipSheet SlipSheetDetails • SlipSheetSource • Type Staple TraySwitch Tumble UniversalDetails • Type • PageSize •...

  • Page 86: System Interpreter Parameters

    Appendix C: PostScript support = Supported X = Not supported Printer model Default X548de, X548dte IdiomRecognition true JobName JobTimeout JobTimeout system parameter MaxDictStack MaxExecStack 10015 MaxFontItem 12500 MaxFormItem 100000 MaxLocalVM 2147483647 MaxOpStack 100000 MaxPatternItem 20000 MaxScreenItem 48000 MaxSuperScreen 1024 MaxUPathItem...
  • Page 87 Appendix C: PostScript support = Supported X = Not supported Printer model X548de, X548dte CurFontCache CurFormCache CurInputDevice CurOutlineCache CurOutputDevice CurPatternCache CurScreenStorage CurSourceList CurUPathCache DisableFastProcs DoPrintErrors DoStartPage EnableExtraFonts EngineBoot EngineCode EngineSpeed EnvironmentSave FactoryDefaults FatalErrorAddress FontResourceDir FontVersion GenericResourceDir GenericResourcePathSep InstalledRam JobTimeout languagelevel...
  • Page 88 Appendix C: PostScript support = Supported X = Not supported Printer model X548de, X548dte MaxDisplayAndSourceList MaxFontCache MaxFormCache MaxImageBuffer MaxOutlineCache MaxPatternCache MaxPermanentVM MaxRasterMemory MaxScreenStorage MaxSourceList MaxUPathCache PageCount PanelCode PrinterCode PrinterName RamSize RealFormat Revision SearchBuiltinFontsFirst SerialNumber StartJobPassword StartupMode StaticRamSize SystemParamsPassword UseOldcopypage UseOldfonts...

  • Page 89: Devices Supported

    Appendix C: PostScript support = Supported X = Not supported Printer model X548de, X548dte WaitTimeout Devices supported = Supported X = Not supported Printer model Device X548de, X548dte %AppSocketA% %AppSocketB% %AppSocketC% %AppSocketD% %EthernetPhysicalA% %EthernetPhysicalB% %EthernetPhysicalC% %EthernetPhysicalD% %EtherTalkA% %EtherTalkB% %EtherTalkC% %EtherTalkD%...
  • Page 90 Appendix C: PostScript support = Supported X = Not supported Printer model Device X548de, X548dte %LexLinkC% %LexLinkD% %LocalTalkA% %LocalTalkB% %LocalTalkC% %LocalTalkD% %LPR_A% %LPR_B% %LPR_C% %LPR_D% %ParallelA% %ParallelB% %ParallelC% %ParallelD% %PrintServerA% %PrintServerB% %PrintServerC% %PrintServerD% %RemotePrinterA% %RemotePrinterB% %RemotePrinterC% %RemotePrinterD% %SerialA% %SerialB% %SerialC%...

  • Page 91: Device Parameters

    Appendix C: PostScript support = Supported X = Not supported Printer model Device X548de, X548dte %TokenRingPhysicalD% %TokenTalkA% %TokenTalkB% %TokenTalkC% %TokenTalkD% %USB_A% %USB_B% %USB_C% %USB_D% Device parameters = Supported X = Not supported Printer model X548de, X548dte Device Parameters for the Communication Device %Parallel%, %ParallelA%, %ParallelB%,...
  • Page 92 Appendix C: PostScript support = Supported X = Not supported Printer model X548de, X548dte DataBits DelayedOutputClose Enabled Filtering FlowControl HasNames HonorDSR Interpreter Parity PCLSmartSwitch PortLocation PSSmartSwitch RobustXon SerialMode StopBits Type Device Parameters for the Communication Device %LocalTalk%, %LocalTalkA%, %LocalTalkB%, %LocalTalkC%, %LocalTalkD%...
  • Page 93 Appendix C: PostScript support = Supported X = Not supported Printer model X548de, X548dte Type Device Parameters for the Communication Device %EtherTalk%, %EtherTalkA%, %EtherTalkB%, %EtherTalkC%, %EtherTalkD% DelayedOutputClose Enabled EthernetAddress EtherTalkType EtherTalkZone Filtering HasNames Interpreter NodeID PCLSmartSwitch PortLocation PSSmartSwitch Type Device Parameters for the Communication Device %IR%, %IR_A%, %IR_B%, %IR_C%,...
  • Page 94 Appendix C: PostScript support = Supported X = Not supported Printer model X548de, X548dte Device Parameters for the Communication Device %USB%, %USB_A%, %USB_B%, %USB_C%, %USB_D% DelayedOutputClose Enabled Filtering HasNames Interpreter PCLSmartSwitch PortLocation PSSmartSwitch Type Device Parameters for the Communication Device %TokenTalk%, %TokenTalkA%,...
  • Page 95 Appendix C: PostScript support = Supported X = Not supported Printer model X548de, X548dte Device Parameters for the Communication Device %AppSocket%, %AppSocketA%, %AppSocketB%, %AppSocketC%, %AppSocketD% DelayedOutputClose Enabled Filtering HasNames Interpreter PortLocation Type Device Parameters for the Communication Device %RemotePrinter%, %RemotePrinterA%,...
  • Page 96 Appendix C: PostScript support = Supported X = Not supported Printer model X548de, X548dte PortLocation Type Device Parameters for the Communication Device %LPR%, %LPR_A%, %LPR_B%, %LPR_C%, %LPR_D% Enabled Filtering HasNames Interpreter PortLocation Type Device Parameters for the Communication Device %LexLink%, %LexLinkA%, %LexLinkB%,...
  • Page 97 Appendix C: PostScript support = Supported X = Not supported Printer model X548de, X548dte Device Parameters for the Communication Device %EthernetPhysical%, %EthernetPhysicalA%, %EthernetPhysicalB%, %EthernetPhysicalC%, %EthernetPhysicalD% EthernetAddress PortLocation Type Device Parameters for the Communication Device %TokenRingPhysical%, %TokenRingPhysicalA%, %TokenRingPhysicalB%, %TokenRingPhysicalC%, %TokenRingPhysicalD% Address...
  • Page 98 Appendix C: PostScript support = Supported X = Not supported Printer model X548de, X548dte Second Type Year DateTime DayOfWeekLong DayOfWeekNum DayOfWeekShort Device Parameters for the Parameters Device %disk1% BlockSize Free HasNames InitializeAction LogicalSize Mounted PhysicalSize Removable Searchable SearchOrder Type Writeable...

  • Page 99: Postscript Message Keys Commands

    Appendix C: PostScript support = Supported X = Not supported Printer model X548de, X548dte PhysicalSize Removable Searchable SearchOrder Type Writeable Device Parameters for the Parameters Device %rom% BlockSize Free HasNames InitializeAction LogicalSize Mounted PhysicalSize Removable Searchable SearchOrder Type Writeable PostScript message keys commands...

  • Page 100: Index

    GL/2 28 physical page PJL, common variables for both PCL emulation 9 languages 31 physical specifications 19 letter meanings 5 PJL, Lexmark‑unique variables for PJL commands logical page LRESOURCE 44 common variables, both PCL emulation 9 PJL, Lexmark‑unique variables for...
  • Page 101 Index device attendance 75 paper handling 66 paper jams 69 PostScript device parameters 91 devices supported 89 operators, envelope sizes 15 page device parameters 81 supplemental operators 78 supported paper sizes 13 tray operators 14 PostScript commands message keys 99 PostScript operators envelope tray support 16 PostScript parameters...
