5-Burner Gas Grill Heavy Duty Gas Grill Parrilla de Gas de Alta Resistencia OWNER’S MANUAL / MANUAL DEL PROPIETARIO ASSEMBLY AND OPERATING IN STRUC TIONS INSTRUCCIONES DE ARMADO Y OPERACIÓN SAVE THIS MANUAL FOR FUTURE REFERENCE GUARDE ESTE MANUAL PARA REFERENCIA FUTURA...
Page 2
IMPORTANT SAFETY WARNINGS WE WANT YOU TO ASSEMBLE AND USE YOUR GRILL AS SAFELY AS POSSIBLE. THE PURPOSE OF THIS SAFETY ALERT SYMBOL IS TO ATTRACT YOUR ATTENTION TO POSSIBLE HAZARDS AS YOU ASSEMBLE AND USE YOUR GRILL. WHEN YOU SEE THE SAFETY ALERT SYMBOL PAY CLOSE ATTENTION TO THE INFORMATION WHICH FOLLOWS! READ ALL SAFETY WARNINGS AND INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING AND OPERATING YOUR GRILL.
GENERAL WARNINGS WARNING • Never use natural gas in a unit designed for liquid propane gas. • Never use charcoal or wood briquets in a gas grill. Flavoring chips must be contained in a metal smoking box to contain ash and prevent fires. •...
WARNING • FOR OUTDOOR USE ONLY. DO NOT operate indoors or in an enclosed area such as a garage, shed or breezeway. • Use your grill OUTDOORS in a well ventilated space away from dwellings or other buildings to prevent dangers associated with gas accumulation and toxic vapors. Although minimum clearance s 36 inches (91 cm), we strongly recommend that you do not operate this appliance within 10 ft.
Page 6
CYLINDER SPECIFICATIONS: When purchasing or exchanging a cylinder for your gas grill, it must be constructed and marked in accordance with the specifications for LP gas cylinders of the U.S. Department of Transportation (DOT) or the National Standard of Canada, CAN/CSA-B339 Cylinders, Spheres and Tubes for Transportation of Dangerous Goods;...
WARNING FILLING THE LP GAS CYLINDER: • Allow only qualified LP gas dealers to properly fill or repair your LP gas cylinder. • New tanks should be purged prior to filling; inform LP gas dealer if you are using a new tank. •...
WARNING • Never use your grill without leak testing all gas connections and hoses. See the section on "Leak Testing" in this manual for proper procedures. WARNING The pressure regulator and hose assembly supplied with your gas grill must be used. •...
DANGER LEAK TESTING: To prevent fire or explosion hazard: • DO NOT smoke or permit ignition sources in the area while conducting a leak test. • Perform test OUTDOORS only in a well ventilated area. • Never perform a leak test with a match or open flame. •...
6. Check each place listed (A–K) for growing bubbles which indicates a leak. 7. Turn off gas supply at cylinder valve. 8. Turn on control knobs to release gas pressure in hose. 9. Turn control knobs to "OFF" position. 10. Tighten any leaking connections. 11.
WARNING Read, understand and follow all warnings and instructions contained in this manual. DO NOT skip any of the warnings and instructions contained in the preceding sections of this manual. WARNING LIGHTING INSTRUCTIONS: Follow the instructions exactly. 1. OPEN THE GRILL LID before attempting to light a burner so that fumes do not accumulate inside the grill.
Page 12
Note: If burner does not light or flame is too low, you may have spider or other insect blockage in burner, or the flow limiting device has been activated. See "Burner Assembly/Maintenance" under Proper Care and Maintenance, or "Regulator Resetting Procedure" under Connecting LP Cylinder and Hose/Regulator to Grill.
WARNING OPERATING THE GRILL: Never use charcoal or wood briquets in a gas grill. Flavoring chips must be contained in a metal smoking box to contain ash and prevent fires. Read and follow all warnings and instructions contained in the preceding sections of this manual. BREAKING IN YOUR GRILL: •...
ROTISSERIE COOKING: • Your grill was pre-drilled from factory to include mounting holes for a rotisserie (sold separately). Do not use a rotisserie not specifically manufactured for this grill. • Read and follow all instructions provided with the rotisserie. Save instructions for future reference. •...
GRILL COOKING TIPS CLEANLINESS • Always wash hands thoroughly with soap and hot water prior to handling food and after handling raw meat, uncooked poultry or seafood. • When using a platter to carry raw meat, uncooked poultry or seafood to the grill, make sure to wash the platter thoroughly with soap and hot water before placing cooked foods back on the platter or use different platters for raw and cooked foods.
CLEANING AND MAINTENANCE: • Keep the appliance free and clear of combustible materials, gasoline and other flammable vapors and liquids. • Keep the ventilation openings of the cylinder enclosure free and clear of debris. • Visually check burner flames for proper operation (see pictorial in "Burner Assembly/Maintenance" under Proper Care and Maintenance).
BURNER ASSEMBLY/MAINTENANCE CONTINUED Note: Follow the "Gas Leak Testing" section of this manual. Relight burners to verify proper operation. 12. Replace heat distribution plates and cooking grills. PROPER BURNER OPERATION COOKING GRILLS • Clean with mild soap detergent and water. A brass bristled brush or a nylon cleaning pad can be used to remove residue from the stainless steel surfaces.
BEFORE STORING YOUR GRILL: • Ensure that the cylinder valve is fully closed. • Clean all surfaces. • Lightly coat the burners with cooking oil to prevent excess rusting. • If storing the grill indoors, disconnect the LP tank and leave the LP tank OUTDOORS. •...
FREQUENTLY ASKED QUESTIONS These questions and answers are for your general knowledge, and may not be applicable to your model grill. Your grill's serial number and model number, and the contact information for Brinkmann Customer Service, are listed on a silver label found beneath the control panel, on the back of the grill or on the side of the grill body, under the side shelf.
FREQUENTLY ASKED QUESTIONS Cleaning Stainless Steel Cooking Grills: Wash grills with a mild detergent and rinse with hot water before initial use and as needed. DO NOT use a commercial oven cleaner. For stubborn food residue, use a degreaser and fiber or brass cleaning brush. Cleaning Porcelain-Finished Cast-Iron Cooking Grills: Wash grills with a mild detergent and rinse with hot water before initial use and as needed.
PARTS BAG CONTENTS Make sure you have all items listed under PARTS LIST and PARTS BAG CONTENTS before you begin the installation process. Your Parts Bag will include: Qty. Qty. 20 M6 Star Washers (Black) 32 M6 X 12 mm Bolts (Black) M6 X 12 mm Bolts (Silver) M6 Lock Washers (Silver) M6 X 30 mm Bolts (Black)
ASSEMBLY INSTRUCTIONS READ ALL SAFETY WARNINGS & ASSEMBLY INSTRUCTIONS CAREFULLY BEFORE ASSEMBLING OR OPERATING YOUR GRILL. WE RECOMMEND TWO PEOPLE WORK TOGETHER WHEN AS SEM BLING THIS UNIT. The following provided tools are required to assemble this Brinkmann 5 Burner Gas Grill: •...
Page 23
FOR COVERS, ACCESSORIES AND OTHER PRODUCTS, PLEASE VISIT US ONLINE AT: Inspect contents of the box to ensure all parts are included and undamaged.
Page 24
Choose a good, cleared assembly area and get a friend to help you put your grill together. Lay card board down to protect grill finish and assembly area. CAUTION: Some parts may contain sharp edges. Wear protective gloves if necessary. Step 1 Attach lower cart brace to legs using four M6 X 30 mm bolts (black).
Page 25
Step 5 Attach the upper cart brace to the side frame using four M6 X 12 mm bolts (black). Tighten securely. Note: With the help of a friend, turn the cart assembly over. Try to minimize the stress to the legs.
Page 26
Step 7 To attach the door handle to the door, insert two M4 X 10 mm bolts (black) through the door and onto the door handle. Align the bolts to the holes which are located on the door panel. Then tighten the two bolts securely.
Page 27
Grill Body Assembly Note: When performing Step 10, Lift grill body from front and rear panels to avoid injury to hands and fingers. Step 10 With the help of a friend, place grill body assembly on grill cart. Secure using four M6 X 12 mm bolts (black) and M6 star washers (black) on each side of the frame.
Page 28
Step 11 Insert the two bolts with pre- attached nuts on the left side table into the keyholes on the side table front panel. Tighten the nuts with wrench. Insert one M6 X 12 mm bolt (black) from side table to side table front panel.
Page 29
Step 13 Attach side table to left side of cart frame assembly. Place keyholes over pre-attached bolts and slide toward back of grill, then tighten securely. Fasten side table front panel to grill body with one M6 X 12 mm bolt (silver). Step 14 Burner Venturi Assembly...
Page 30
Burner Venturi Step 16 Firmly seat the valve nozzle into the burner venturi. Hold in place while Side you perform Step 17. Burner Valve Step 17 Insert the two screws that are Valve Nozzle already attached on the side burner valve through the corresponding key holes on the side burner front panel and bezel, from the back of...
Page 31
Step 19 Attach side burner igniter lead wire Side Burner to the electrode as illustrated. Igniter Lead Electrode Step 20 Hang grease cup from brackets on bottom of grill body assembly. Grease Cup...
Page 32
Step 21 Place the heat distribution plates on Warming Rack lower level of grill body assembly directly above burners. Cooking Grills Heat Distribution Plates Step 22 Place cooking grills on support ribs directly above heat distribution plates. Grooves Step 23 Place warming rack in grooves so that it sits above the cooking grills.
Page 34
IMPORTANTES ADVERTENCIAS DE SEGURIDAD ES NUESTRO DESEO QUE ARME Y UTILICE SU PARRILLA EN LA FORMA MÁS SEGURA POSIBLE. EL PROPÓSITO DE ESTE SÍMBOLO DE ALERTA DE SEGURIDAD ES QUE USTED PRESTE ATENCIÓN A LOS POSIBLES PELIGROS CUANDO ARME Y UTILICE SU PARRILLA. ¡CUÁNDO VEA ESTE SÍMBOLO DE ALERTA DE SEGURIDAD PRESTE ESPECIAL ATENCIÓN A LA INFORMACIÓN A CONTINUACIÓN!
Page 35
ÍNDICE Advertencias generales ............35 Instalación, especificaciones y uso seguro del cilindro de propano líquido .
ADVERTENCIAS GENERALES ADVERTENCIA • Nunca use gas natural en una unidad diseñada para gas de propano líquido. • Nunca use briquetas de carbón en una parrilla de gas. Los pedacitos de madera para dar sabor se deben colocar en una cajita de fumar de metal para contener la ceniza y para prevenir fuegos. •...
ADVERTENCIA • PARA USO EXTERIOR ÚNICAMENTE. NO opere la parrilla en áreas interiores o en un área cerrada como un garaje, cobertizo o pasadizo. Use la parrilla AL AIRE LIBRE en un espacio bien ventilado alejado de viviendas u otros edificios para •...
Page 38
ESPECIFICACIONES DEL CILINDRO Cuando compre o cambie un cilindro para la parrilla de gas, debe estar construido y marcado de acuerdo con las especificaciones para cilindros de gas de propano líquido del Departamento de Transporte (DOT) de EE.UU. o la Norma Nacional de Canadá, CAN/CSA-B339: Cilindros, esferas y tubos para el transporte de artículos peligrosos;...
ADVERTENCIA LLENADO DEL CILINDRO DE GAS DE PROPANO LÍQUIDO: • Sólo los distribuidores de gas de propano líquido capacitados deben llenar o reparar su cilindro. • Los tanques nuevos deben ser purgados antes de llenarlos; dígale al distribuidor de gas que está usando un tanque nuevo.
Page 40
ADVERTENCIA • Nunca use la parrilla sin haber verificado que no hay fugas en las conexiones y mangueras de gas. Consulte los procedimientos apropiados en la sección de "Pruebas de detección de fugas" en este manual. ADVERTENCIA Se debe utilizar el conjunto del regulador de presión y manguera suministrado con la parrilla de gas. •...
PELIGRO PRUEBAS DE DETECCIÓN DE FUGAS: Para impedir los peligros de incendio o explosión: • NO fume ni permita que haya fuentes de encendido en el área mientras realiza la prueba de detección de fugas. • Realice la prueba AL AIRE LIBRE únicamente, en un área bien ventilada. •...
6. Inspeccione cada uno de los elementos indicados (A-K) para ver si hay burbujas, lo cual indica una fuga. 7. Cierre el suministro de gas en la válvula del cilindro. 8. Gire las perillas de control para descargar la presión de gas en la manguera. 9.
ADVERTENCIA Lea, entienda y siga todas las advertencias e instrucciones indicadas en este manual. NO pase por alto ninguna de las advertencias o instrucciones indicadas en las secciones anteriores de este manual. ADVERTENCIA INSTRUCCIONES DE ENCENDIDO: Siga las instrucciones al pie de la letra. ABRA LA TAPA DE LA PARRILLA antes de tratar de encender una hornilla para que no se acumulen vapores dentro de la parrilla.
Page 44
Nota: Si la hornilla no se enciende o la llama es muy baja, quizás esté bloqueada con un insecto o se haya activado el dispositivo limitador de flujo. Consulte "Instalación/Mantenimiento de las Hornillas" en la sección Cuidado y mantenimiento apropiados o el "Procedimiento de Reposición del Regulador"...
ADVERTENCIA OPERACIÓN DE LA PARRILLA: Nunca use briquetas de carbón en una parrilla de gas. Los pedacitos de madera para dar sabor se deben colocar en una cajita de fumar de metal para contener la ceniza y para prevenir fuegos. Lea y siga todas las advertencias e instrucciones indicadas en las secciones anteriores de este manual.
Page 46
COCCIÓN ESTILO ROTISSERIE: • La parrilla viene preparada de la fábrica con agujeros de montaje para instalar un asador estilo rotisserie (vendido aparte). No use un asador estilo rotisserie que no haya sido fabricado especialmente para esta parrilla. • Lea y siga todas las instrucciones incluidas con el asador estilo rotisserie. Guarde las instrucciones para referencia futura.
RECOMENDACIONES PARA COCINAR EN LA PARRILLA LIMPIEZA • Siempre lávese bien las manos con agua caliente y jabón antes de manipular alimentos y después de tocar carne, pollo o mariscos crudos. • Cuando utilice una fuente para llevar carne, pollo o mariscos crudos a la parrilla, asegúrese de lavar bien la fuente con agua caliente y jabón antes de colocar alimentos cocidos en ella, o utilice fuentes distintas para los alimentos crudos y cocidos.
LIMPIEZA Y MANTENIMIENTO: • Mantenga el artefacto alejado de materiales combustibles, gasolina u otros vapores o líquidos inflamables. • Mantenga los orificios de ventilación del gabinete del cilindro sin residuos. • Observe las llamas de las hornillas para verificar que estén funcionando bien (consulte el dibujo en "Instalación/Mantenimiento de las Hornillas"...
CONTINUACIÓN DE INSTALACIÓN/MANTENIMIENTO DE LAS HORNILLAS Nota: Siga la sección “Verificación de Ausencia de Fugas” de este manual. Vuelva a encender las hornillas para verificar la operación apropiada) 12. Reinstale las placas de distribución del calor y las rejillas para cocinar. OPERACIÓN APROPIADA DE HORNILLA REJILLAS PARA COCINAR •...
ANTES DE GUARDAR LA PARRILLA: • Verifique que la válvula del cilindro está bien cerrada. • Limpie todas las superficies. • Aplique una capa ligera de aceite para cocinar a las hornillas para evitar la oxidación excesiva. • Si va a guardar la parrilla en un área interior, desconecte el tanque de propano líquido y déjelo AFUERA.
PREGUNTAS FRECUENTES Estas preguntas y respuestas son para su conocimiento general y podrían no ser aplicables a su modelo de parrilla. El número de modelo y número de serie de la parrilla y la información para contactarse con el Servicio de atención al cliente de Brinkmann se incluyen en una etiqueta plateada abajo del panal de control o en el costado de la caja de la misma, debajo del estante lateral y también atrás del asador en el panal.
Page 52
PREGUNTAS FRECUENTES Limpieza de las rejillas para cocinar de acero inoxidable: Lave las rejillas con un detergente suave y enjuáguelas con agua caliente antes del uso inicial y según sea necesario. NO use un limpiahornos comercial. Para residuos de alimentos persistentes, utilice un desgrasador y un cepillo de limpieza de fibra o latón. Limpieza de rejillas para cocinar de hierro fundido con acabado de porcelana: Lave las rejillas con un detergente suave y enjuáguelas con agua caliente antes del uso inicial y según sea necesario.
CONTENIDO DE LA BOLSA DE PARTES Verifique que tiene todos los artículos indicados en la LISTA DE PARTES y en el CONTENIDO DE LA BOLSA DE PARTES antes de comenzar con el proceso de instalación. La bolsa de partes incluirá lo siguiente: Cant.
Page 54
INSTRUCCIONES DE ARMADO LEA DETENIDAMENTE TODAS LAS ADVERTENCIAS DE SEGURIDAD E INSTRUCCIONES ANTES DE ARMAR Y USAR LA PARRILLA RECOMENDAMOS QUE ESTA UNIDAD SEA ARMADA POR DOS PERSONAS Se necesitan las siguientes herramientas incluidas para armar esta Brinkmann Parrilla de Gas: Destornillador •...
Page 55
PARA CUBIERTAS, ACCESORIOS Y OTROS PRODUCTOS, FAVOR DE VISITARNOS POR LA RED MUNDIAL EN: Inspeccione el contenido de la caja para verificar que todas las partes estén incluidas e intactas.
Page 56
Elija un lugar adecuado y despejado para armar la parrilla y pídale a un amigo que le ayude. Tienda cartón sobre el suelo para proteger el acabado de la parrilla y el área de armado. PRECAUCIÓN: Algunas partes pueden tener bordes afilados.
Page 57
Paso 5 Ate el apoyo superior del carro al marco lateral usando cuatro pernos M6 X 12 mm (negros). Apriete con seguridad. Nota: Voltee el conjunto del carro a su posición vertical con la ayuda de un amigo. Paso 6 Ate los ruedillas a la parte inferior de la base del carro usando cuatro pernos M6 X 12 mm (negros) y...
Page 58
Paso 7 Para atar la manija de puerta a la puerta, inserte dos pernos M4 X 10 mm (negros) a través de la puerta y sobre la manija de puerta. Alinee los pernos con los agujeros que se localizan en el panel de la puerta.
Page 59
Montaje del Cuerpo de la Parrilla Nota: Cuando ejecute el Paso 10, levante la caja de la parrilla desde los paneles delanteros y traseros para prevenir lesiones a las manos y dedos. Paso 10 Con la ayuda de un amigo, coloque la caja de la parrilla sobre el bastidor del carro.
Page 60
Paso 11 Inserte los dos pernos con las tuercas pre anexadas de la mesa lateral izquierda dentro de los orificios del panel frontal de la mesa lateral. Ajuste las tuercas con la llave inglesa. Inserte uno perno M6 X12 mm (negros) de la mesa lateral al panel delantero lateral de la mesa.
Page 61
Paso 13 Instale la mesa lateral en el lado izquierdo del asamblaje del carro. Coloque orificios de cerradura sobre los pernos pre-atados y deslícela hacia atrás de la parrilla, luego apriete bien. Conecte el panel frontal de la mesa lateral al cuerpo de la parrilla con un perno M6 X 12 mm (plateado).
Page 62
Paso 16 Venturi de la Hornilla Asiente firmemente el inyector de la válvula en el venturi de la hornilla. Manténgala en su lugar mientras lleva a cabo el Paso 17. Válvula de la Hornilla Lateral Paso 17 Inserte los dos tornillos que se Boquilla de asocian en la válvula lateral de la la Válvula...
Page 63
Paso 19 Conecte el cable conductor del encendedor de la hornilla lateral al electrodo, tal como se ilustra. Conductor del Encendedor del Quemador Lateral Electrodo Paso 20 Cuelgue la taza de la grasa en los soportes en el fondo del cuerpo de la parrilla.
Page 64
Rejilla para Calentar Paso 21 Rejillas para Coloque las placas de distribución Cocinar de calor en el nivel inferior de la caja de la parrilla, directamente Cubiertas sobre las hornillas. Térmicas Revestidas Paso 22 Coloque las rejillas para cocinar sobre las costillas de apoyo directamente sobre las placas de distribución de calor.
Page 66
FOR COVERS, ACCESSORIES AND OTHER PRODUCTS, PLEASE VISIT US ONLINE AT: PARA CUBIERTAS, ACCESORIOS Y OTROS PRODUCTOS, FAVOR DE VISITARNOS POR LA RED MUNDIAL EN: WARRANTY The Brinkmann Corporation warrants to the original pur chas er that the Brinkmann 5 Burner Gas Grill is free from defects due to workmanship or materials for: Five-year: on stainless steel tube burners Three-year: on all other stainless steel parts One-year: on valves, frame, housing, cart, igniter, cooking grates and other related parts...
