Business (519) 650-5775 Fax (519) 650-3773 Toll Free Phone: 1-877-650-5775 Toll Free Fax: 1-800-327-5609
Installation and Operating Instructions
SAVE THESE
INSTRUCTIONS FOR
FUTURE USE.
Note: Please read these
instructions thoroughly
before attempting to install
this unit.
SAFETY NOTICE: If this stove is not properly installed, a
house fire may result, for your safety, follow the
installation directions, contact local building or fire officials
about restrictions and installation inspection requirements
in your area.
IMPORTANT: Check around oven chamber on a weekly
basis for soot and creosote accumulation. Clean the
chamber thoroughly from the top, side and bottom with
the rake provided. Burn the stove hot daily to reduce
creosote accumulation. Use only dry wood aged for one
year. Failure to do so could result in chimney fire and
void the warranty.
ATTENTION INSTALLER: Leave this manual with the appliance.
PLEASE NOTE: Specifications contained in this manual are subject to change without notice
1050 Fountain St N. Cambridge, Ontario, Canada N3H-4R7
The Artisan
The Artisan is listed to
ULC Standard S-627 &
UL 1482 by Warnock
Hersey Professional
Services Ltd
© 2006 HEARTLAND APPLIANCES INC.
WOODSTOVES
The temperature registered by the oven door
thermometer may not necessarily correspond with the
reading taken with a thermometer inside the oven
OVERFIRING CAUTION
Repeated or extended overfiring
will void warranty on this
appliance. See page 18 for
details.
01/07 EINS 515000
Advertisement
Table of Contents
Related Manuals for Heartland Wood Stove
Summary of Contents for Heartland Wood Stove
- Page 1 SAFETY NOTICE: If this stove is not properly installed, a house fire may result, for your safety, follow the installation directions, contact local building or fire officials about restrictions and installation inspection requirements in your area.
-
Page 2: For Your Safety
Any openings in the wall behind the stove or in the floor under the stove must be sealed. Do not set unopened glass or metal containers on the stove. - Page 3 2. Warranty applies to product only in the country in which it was purchased. 3. Heartland is not liable for any claims or damages resulting from any failure of the Wood Cookstove or from service delays beyond their reasonable control.
-
Page 4: Table Of Contents
TABLE OF CONTENTS 1) Welcome ... Pg 5 2) Installation ... Pg 6 3) Installation Requirements ... Pg 7 4) Clearances Single Wall Connector ... Pg 8 5) Clearances Double Wall Connector ... Pg 9 6) Installing the Chimney Connector ... Pg 10 7) Chimney and Draft ... -
Page 5: Getting Acquainted
Save These Instructions Keep the manual available for future reference. The manual is an important part of your stove. If your stove is sold, deliver the manual to the new owner along with the stove. The quality of the installation (especially the chimney... -
Page 6: Installation
Place the stove in the intended position and lift out the hotplate, checking that the joint between the underside of the hob and the top of the stove is intact. Any joints which have opened should be made good with the fire cement provided. -
Page 7: Installation Requirements
Installation Requirements Due to continuing product improvements, Heartland Appliances reserves the right to amend specifications without notice. Please contact Heartland for the most up to date information, as it applies to product being purchase, or download latest Site Preparation Specifications from... -
Page 8: Clearances Single Wall Connector
Clearances to Combustibles Single Wall Chimney Connector All measurements must be done before starting the installation. Dimensions All drawings are for reference only, showing approximate dimensions for rough-in purposes. In some installations, two or more clearances to combustible walls may contradict each other. The clearances with the greater numerical value is to be used. -
Page 9: Clearances Double Wall Connector
Clearances to Combustibles Listed Double Wall Chimney Connector All measurements must be done before starting the installation. Dimensions All drawings are for reference only, showing approximate dimensions for rough-in purposes. In some installations, two or more clearances to combustible walls may contradict each other. The clearance with the greater numerical value must be used. -
Page 10: Installing The Chimney Connector
MUST be fully relined with a listed solid fuel chimney liner. Horizontal Connection The Heartland Artisan has the ability to connect stove pipe out the top of the flue box vertically or out the back of the flue box horizontally. -
Page 11: Chimney And Draft
Recommended Chimney Clearances The chimney must: 1. extend at least 14 ft. above the collar of the stove. 2. extend at least 3 ft. above the point where it passes through the roof. 3. be at least 2 ft. above anything within 10 ft. radius of the top of the pipe. -
Page 12: User Instructions
Any air inlet grilles must be maintained and free from blockage. Failing to maintain your stove properly can lead to a chimney fire. Combustible deposits (called creosote) are a natural by-product of woodburning. A fire hazard exists if 1/4”... -
Page 13: Door Operation
Close and lock the firebox door. The secondary air slide setting is normally full open with this stove. j. With the fire established, open the firebox door and fill with fuel. Push the flue chamber damper back to the position which gives the desired burning rate. -
Page 14: Refuelling
Refuelling The firebox should be filled to the recommended level at the middle of the firebox door opening. When correctly fuelled, the stove will maintain the maximum rated output for a minimum of 2 hours, including intermittent cooking. Once completed, close the firebox door immediately and open only for re-fuelling charges. -
Page 15: Break-In Fire
This results in most of the heat being wasted up the chimney. The flue chamber box has a removable door on the front for cleaning access to the flueway. The stove is not to be operated with this door removed. This could result in a dangerous backdraft condition. -
Page 16: Flueway Cleaning
Damaged firebricks should be replaced as soon as possible but it may be temporarily repaired with the stove cement. The firebricks fitted to the Heartland Artisan are of first quality manufacture, and providing the stove has been installed and used correctly will have a reasonable life. -
Page 17: Spares List
JPAD301221 Insulation board firebrick side 1 JPAD301220 Insulation board firebrick front 1 Please contact your Heartland dealer for information. Servicing Always use a qualified service/heating engineer when servicing is required. Use only authorised replacement parts. Do not make unauthorised modifications. -
Page 18: Over Firing
Clean your chimney regularly to remove creosote build-up. A chimney fire is a fire hazard and will overfire your stove. See page 20, “What to do if you have a chimney fire”. -
Page 19: Trouble Shooting
This competition for air supply can make a fire slow to kindle or cause a stove to smoke when its door is opened. Chimneys are often blamed for this type of performance. Stack Effect in houses In winter, the air intake is much warmer and, therefore more buoyant than the outside air. -
Page 20: Safety Practices
Masonry chimneys should be checked for deterioration including damaged bricks, crumbling and missing mortar, cracks in the drip cap at the top of the chimney, and loose flashings at the roof line. The liner should be checked for cracks and mis-alignment. It must be at least 6” in size. An existing factory-built chimney needs a careful inspection. -
Page 21: Cooking Instructions
1050 Fountain St N. Cambridge, Ontario, Canada N3H-4R7 Business (519) 650-5775 Fax (519) 650-3773 Toll Free Phone: 1-877-650-5775 Toll Free Fax: 1-800-327-5609 The Artisan Cooking Instructions The temperature registered by the oven door thermometer may not necessarily correspond with the reading taken with a thermometer inside the oven WOODSTOVES ATTENTION INSTALLER: Leave this manual with the appliance. -
Page 22: Cooking Instruction
Save These Instructions Keep the manual available for future reference. The manual is an important part of the stove. If the stove is sold, deliver the manual to the new owner along with the stove. - Page 23 Once the stove has about 4” of red hot coals in the firebox, it will become stable. The entire stove and the chimney system is heated and running at a fairly constant temperature.
-
Page 24: Fresh Air Kit
519-650-5775. Our office hours are from 8:30 am to 5.00 pm. est. For our complete line of kitchen appliances, visit our website at www.heartlandapp.com or phone 1-877-650-5775 and ask to speak to a sales representative For pricing please call your dealer, or call Heartland Appliances (519) 650-5775 or Fax (519) 650-3773...
