IMPORTANT: Please read the Owner's Guide completely
before proceeding with the installation.

Introduction

Thank you for purchasing Airmar's ultrasonic, WeatherStation Instrument. This
exciting product is actually six different sensors in a single unit—without any
moving parts. The compact housing is waterproof with a single removable cable.
Data is output in digital NMEA 0183 and NMEA 2000® formats.
Functions
• Apparent wind speed
• Apparent wind direction
• Magnetic compass heading
• Air temperature
• Wind chill temperature
• Rate of Turn
• Angle of vessel pitch
• Angle of vessel roll
• Barometric pressure
• Global Positioning System (GPS) with WAAS and EGNOS
• Vessel speed over ground (SOG)
• Vessel course over ground (COG)
• True wind speed
• True wind direction
• Heading relative to true north
• True wind chill temperature
• True wind speed relative to water—requires speed-through-water input
Features
• Waterproof housing
• Waterproof cable system
• Fast response time
• Simultaneously outputs data in digital NMEA 0183 and NMEA 2000® formats
• Stable and accurate data in dynamic conditions
• Can be programed to compensate for an installation that is not aligned to the
bow of the vessel and/or level
• Can be calibrated to compensate for magnetic deviation caused by ferrous
metals and other electro-magnetic fields
